Mercury-Mercruiser 8M0110643 Vesselview 502 Kit Single Engine w VesselView Link

8M0110643 Vesselview 502 Single Engine Kit
This is a genuine Mercury Marine factory OEM part, not aftermarket
Please check our current stock level and order below or use the Contact Us form at the bottom of the page for any questions
Availability: Not in stock - will be transferred from factory
Manufacturer part number: 8M0110643
Pickup or normally ships: Warehouse transfer - on 2nd-6th business day
$1,206.79
$1,106.29

Vesselview 502 Kit Single Engine with VesselView Link

From engine information to vessel systems, the Mercury VesselView 502’s 5” screen is your information portal for your boat. The 5" screen is perfect for smaller fishing and family vessels.  Mercury's VesselView allows boaters to display their SmartCraft engine information, genset, sounder info and much more.

The VesselView Link which is included in this kit, enables you to display data from compatible Lowrance® and Simrad® multi-function displays. You can conveniently display your GPS chartplotter, sonar, radar and VHF all on the same screen. It is also capable of integrating digital switching and entertainment systems.

• Features a bright 16x9 aspect ratio, high definition glass touchscreen with glare reducing coating and dimmable lighting
• Features a built in 10Hz GPS and chart platter capability (regional electronic chart cards purchased separately)
• Unique touch only screen interface that delivers intuitive display interaction (optional remote control button interface is available)
• Auto Notification of software updates through the embedded WiFi and Bluetooth capability
• Can be integrated with all the Simrad accessories for the Go5 product line: Radar, Sonar transducers, Fish Finder transducers, AIS, VHF, Sonic Hub/Fusion Link, C-Zone digital switching and more
• Adaptive screen automatically presents information when it is most important
• Descriptive fault text display provides up-to-date information for 30+ engine parameters Including: Fuel Level & Range, Oil Temperature & Pressure, Battery Voltage, Water Depth, Genset and more
• Simultaneous displays information for up to 4 engines in an easy-to-read interface
Gateway functionality to allow SmartCraft data to be displayed on NMEA 2000 devices
• Supports 16 languages and multiple unit conversions
• Requires Mercury’s VesselView Link to fully integrate the propulsion system and make your multi-function display truly multi-functional (included in the kit)

Works with all SmartCraft capable engines 40 HP and up, single engine applications only.

A NMEA2000 backbone is required, starter kit available separately. (see related items)

Kit contains:
8M0110644 VesselView 502 Display Kit
NSS            502 Monitor
8M6003707 Sun Cover (Mercury)
8M6003706 Bezel Kit
8M6003818 Gasket - Dash
8M6003915 Door
8M6003966 Fastener Kit (bag of 4 screws)
8M0111669 Power Harness
8M6002266 Tee NMEA 2000
879171T02  Extension Harness Assembly 1000 mm
8M0110639 VesselView Link Base Kit - Single Engine

Service Bulletins & Instructions
Installation Instructions

Vesselview 502 Kit Single Engine with VesselView Link

From engine information to vessel systems, the Mercury VesselView 502’s 5” screen is your information portal for your boat. The 5" screen is perfect for smaller fishing and family vessels.  Mercury's VesselView allows boaters to display their SmartCraft engine information, genset, sounder info and much more.

The VesselView Link which is included in this kit, enables you to display data from compatible Lowrance® and Simrad® multi-function displays. You can conveniently display your GPS chartplotter, sonar, radar and VHF all on the same screen. It is also capable of integrating digital switching and entertainment systems.

• Features a bright 16x9 aspect ratio, high definition glass touchscreen with glare reducing coating and dimmable lighting
• Features a built in 10Hz GPS and chart platter capability (regional electronic chart cards purchased separately)
• Unique touch only screen interface that delivers intuitive display interaction (optional remote control button interface is available)
• Auto Notification of software updates through the embedded WiFi and Bluetooth capability
• Can be integrated with all the Simrad accessories for the Go5 product line: Radar, Sonar transducers, Fish Finder transducers, AIS, VHF, Sonic Hub/Fusion Link, C-Zone digital switching and more
• Adaptive screen automatically presents information when it is most important
• Descriptive fault text display provides up-to-date information for 30+ engine parameters Including: Fuel Level & Range, Oil Temperature & Pressure, Battery Voltage, Water Depth, Genset and more
• Simultaneous displays information for up to 4 engines in an easy-to-read interface
Gateway functionality to allow SmartCraft data to be displayed on NMEA 2000 devices
• Supports 16 languages and multiple unit conversions
• Requires Mercury’s VesselView Link to fully integrate the propulsion system and make your multi-function display truly multi-functional (included in the kit)

Works with all SmartCraft capable engines 40 HP and up, single engine applications only.

A NMEA2000 backbone is required, starter kit available separately. (see related items)

Kit contains:
8M0110644 VesselView 502 Display Kit
NSS            502 Monitor
8M6003707 Sun Cover (Mercury)
8M6003706 Bezel Kit
8M6003818 Gasket - Dash
8M6003915 Door
8M6003966 Fastener Kit (bag of 4 screws)
8M0111669 Power Harness
8M6002266 Tee NMEA 2000
879171T02  Extension Harness Assembly 1000 mm
8M0110639 VesselView Link Base Kit - Single Engine
