Mercury-Mercruiser 8M0225727 383 MAG Stroker Inboard Reman Engine

8M0225727 383 MAG Stroker Inboard Engine
This is a genuine Mercury Marine factory remanufactured OEM engine, not aftermarket
Please check our current stock level and order below. Use the Contact Us form at the bottom of the page for any questions.
Stock status: Not in stock - will be transferred from factory
Manufacturer part number: 8M0225727
Pickup or normally ships: Warehouse transfer - on 2nd-7th business day
Manufacturer: Mercury Marine
$15,456.25
$14,838.00
Product Shipping specifications = pounds and inches

8M0225727 Mercury Remanufacturing 383 MAG MPI Stroker Inboard Engine

Perfect repower option for 350 MAG, 7.4L and 7.4L MPI inboard engines. This 350 HP inboard comes with dry joint exhaust.

Power 350 HP (261 kW)
Full Throttle Range 4600-5000 RPM
Displacement 383 CID (6.3L)
Engine Type Remanufactured GM V8 Marine Iron Block & Gen+ Heads
Bore & Stroke 4.030” x 3.750” (102mm x 95mm)
Compression Ratio 9.0:1 with Hypereutectic Pistons
Rocker Arm Ratio 1.6:1 Full Roller
Fuel Requirement 87 Octane (R+M)/2
Fuel System MPI with Gen 3 Cool Fuel
Induction System 2-piece Long Runner Intake with 75mm Throttle Body
Control System ECM 555 with SmartCraft CAN Capability
Ignition System Crank-fired High Voltage Switch w/Knock Control Platinum Plugs
Charging System 65 Amp / 917 Watt Alternator
Water Drain System Multi-Point Drain – Hand Removable Blue Drain Plugs
Exhaust System Iron Manifold with Dry-Joint Exhaust Elbow
Cooling System Thermostatically Controlled Raw Water - 160 F
Accessory Drive System Serpentine Belt
Lubrication System High Flow Oil Pump
Recommended Engine Oil SAE 25-40 NMMA Certified FC-W Synthetic Blend
AudioWarning System Oil Pressure, Coolant Temperature, Drive Lube, Water Pressure
Compatible Transmissions ZF 68A, ZF 68 IV, ZF 68C, VD 72C, VD 5000A, VD 5000V
Dimensions
(LxWxH)
32” x 30” x 22” (814mm x 740mm x 559mm)
Engine Weight (lbs./kg) 932 / 423
Optional Cooling Fresh Water Dealer Installed Kit
Boat Harness Type 14-pin



8M0225727 Mercury Remanufacturing 383 MAG MPI Stroker Inboard Engine

Perfect repower option for 350 MAG, 7.4L and 7.4L MPI inboard engines. This 350 HP inboard comes with dry joint exhaust.

Power 350 HP (261 kW)
Full Throttle Range 4600-5000 RPM
Displacement 383 CID (6.3L)
Engine Type Remanufactured GM V8 Marine Iron Block & Gen+ Heads
Bore & Stroke 4.030” x 3.750” (102mm x 95mm)
Compression Ratio 9.0:1 with Hypereutectic Pistons
Rocker Arm Ratio 1.6:1 Full Roller
Fuel Requirement 87 Octane (R+M)/2
Fuel System MPI with Gen 3 Cool Fuel
Induction System 2-piece Long Runner Intake with 75mm Throttle Body
Control System ECM 555 with SmartCraft CAN Capability
Ignition System Crank-fired High Voltage Switch w/Knock Control Platinum Plugs
Charging System 65 Amp / 917 Watt Alternator
Water Drain System Multi-Point Drain – Hand Removable Blue Drain Plugs
Exhaust System Iron Manifold with Dry-Joint Exhaust Elbow
Cooling System Thermostatically Controlled Raw Water - 160 F
Accessory Drive System Serpentine Belt
Lubrication System High Flow Oil Pump
Recommended Engine Oil SAE 25-40 NMMA Certified FC-W Synthetic Blend
AudioWarning System Oil Pressure, Coolant Temperature, Drive Lube, Water Pressure
Compatible Transmissions ZF 68A, ZF 68 IV, ZF 68C, VD 72C, VD 5000A, VD 5000V
Dimensions
(LxWxH)
32” x 30” x 22” (814mm x 740mm x 559mm)
Engine Weight (lbs./kg) 932 / 423
Optional Cooling Fresh Water Dealer Installed Kit
Boat Harness Type 14-pin



*
*
*
*
