Mercury Outboard 8M0056144 Helm Pump Tilt 2.4 CU Inch

Picture of Mercury Outboard 8M0056144 Helm Pump Tilt 2.4 CU Inch Bar codes for Mercury Marine part number 8M0056144
8M0056144 Helm Pump Tilt 2.4 CU Inch
This is a genuine Mercury Marine factory OEM part, not aftermarket
Please check our current stock level and order below or use the Contact Us form at the bottom of the page for any questions
Availability: Not in stock - will be transferred from factory
Manufacturer part number: 8M0056144
GTIN: 745061880412
Normally Ships: Warehouse transfer - on 4th business day
Manufacturer: Mercury Marine
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Shipping specs, pounds and inches
MSRP: $1,078.60
$987.59

8M0056144 Quicksilver Hydraulic Helm Pump Tilt
Front Mount 2.4 cu inches (39 CC) displacement. Approximately 3 turns lock to lock on singles and 6.5 on dual cylinders. Compact design, tilt range of 48 degrees
and 5 locking positions. Built‑in valve for positive rudder lock and integral relief valve for over pressure protection (use compression style fittings and hoses).
Hydraulic Steering for Verado 135 to 175 FourStroke engines. Can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can be used on OptiMax with Mercury hydraulic cylinder and hoses and 75‑115 FourStroke and 1.5L OptiMax 75‑115 HP.

Use cylinder 8M0184533 for standard and 8M0184534 for counter for multiple engine installs.
Hose series is 8M0053474 thru 8M0053492.


8M0056144 Quicksilver Hydraulic Helm Pump Tilt
Front Mount 2.4 cu inches (39 CC) displacement. Approximately 3 turns lock to lock on singles and 6.5 on dual cylinders. Compact design, tilt range of 48 degrees
and 5 locking positions. Built‑in valve for positive rudder lock and integral relief valve for over pressure protection (use compression style fittings and hoses).
Hydraulic Steering for Verado 135 to 175 FourStroke engines. Can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can be used on OptiMax with Mercury hydraulic cylinder and hoses and 75‑115 FourStroke and 1.5L OptiMax 75‑115 HP.

Use cylinder 8M0184533 for standard and 8M0184534 for counter for multiple engine installs.
Hose series is 8M0053474 thru 8M0053492.
