| HP / kW | |
|---|
| Maximum RPM (WOT) | |
|---|
| Engine type | - V8, 2-valve/cylinder pushrod
|
|---|
| Displacement (L) | |
|---|
| Displacement (CID/L) | |
|---|
| Bore and stroke | - 4.0" x 3.75" / 101.6mm x 95.25mm
|
|---|
| Recommended fuel | - Unleaded Regular 87 Octane Minimum (R+M/2) or 90 RON 10% Ethanol Maximum
|
|---|
| Fuel ethanol tolerance | |
|---|
| Fuel requirement | - 90 RON 10% Ethanol Maximum
- Unleaded Regular 87 Octane Minimum (R+M/2)
|
|---|
| Engine control system | - Mechanical Shifting with Optional SmartCraft DTS
- Standard SmartCraft with Electronic Throttle Control
|
|---|
| Fuel delivery system | - Computer controlled Multi-Port Electronic Fuel Injection (MPI)
|
|---|
| Air induction | - Performance-Tuned Scroll Intake Manifold
|
|---|
| Ignition | - SmartCraft PCM 112 Digital Inductive
|
|---|
| Alternator amp / Watt | - 70 amp / 882 watt (Belt-Driven)
|
|---|
| Water drain system | - Air Actuated "Season Extender" (Bravo)
|
|---|
| Exhaust system | |
|---|
| Cooling system | - Fresh water cooled available with SeaCore option
- Water-cooled with thermostat
|
|---|
| Lubrication system | |
|---|
| Recommended oil | - NMMA Certified FCW 25W-40 Synthetic Blend
|
|---|
| Engine guardian system | - SmartCraft Engine Guardian
|
|---|
| Dimensions (L x W x H) | - 32 x 30 x 22" / 813 x 762 x 559 mm
|
|---|
| Weight (engine only) | |
|---|
| Compatible drives | - Bravo One
- Bravo Three
- Bravo Two
|
|---|
