Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 1810A1 CLAMP BRACKET ASSEMBLY NLA $0.00 $0.00 2,2,,
1 3263A1 CLAMP BRACKET ASSEMBLY NLA $0.00 $0.00 ,,2,2
2 22477A4 --THUMB SCREW ASSEMBLY 22477A1 SS $0.00 $0.00 2,2,2,2
3 26227 ----WASHER, THUMB SCREW NLA $0.00 $0.00 2,2,2,2
4 8M0026068 TILT LOCK PIN ASSEMBLY 49930A1 SS $55.49 $52.19 1,1,1,1
5 59624 SPACER, CLAMP BRACKET STUD 20222 SS $0.00 $0.00 1,1,1,
5 53343 SPACER, CLAMP BRACKET STUD NLA $0.00 $0.00 ,,,1
6 59625 STUD, CLAMP BRACKET 20221 SS $0.00 $0.00 1,1,1,1
- 24812 WASHER, STUD SPACER TO CLAMP BRACKET ACT $16.49 $16.09 AR,AR,AR,
7 8M0204647 LOCKWASHER, CLAMP BRACKET STUD 26993 SS $1.80 $1.76 2,2,2,
8 22053 NUT, CLAMP BRACKET STUD 20083 SS $0.20 $0.20 2,2,2,
8 29250 NUT, CLAMP BRACKET STUD 46793 SS $2.89 $2.82 ,,,2
9 8M0041936 TUBE, TILT-CLAMP BRACKET TO SWIVEL BRACKET 30664 SS $29.04 $28.53 1,1,1,1
10 52864 SHIM, CLAMP BRACKET TO SWIVEL BRACKET (.010) 30497A1 SS $0.00 $0.00 2,2,2,
10 52864 WASHER, CLAMP BRACKET TO SWIVEL BRACKET NLA $0.00 $0.00 ,,,6
11 858869 NUT, TILT TUBE 30499 SS $4.99 $4.88 2,2,2,2
12 74316A2 STEERING ARM AND SWIVEL PIN ASSEMBLY (SHORT SHAFT) 39445A1 SS $0.00 $0.00 1,1,1,
12 74316A2 STEERING ARM AND SWIVEL PIN ASSEMBLY (SHORT SHAFT) 52882A1 SS $0.00 $0.00 ,,,1
12 74316A1 STEERING ARM AND SWIVEL PIN ASSEMBLY (LONG SHAFT) 39445A2 SS $0.00 $0.00 1,1,1,
12 74316A1 STEERING ARM AND SWIVEL PIN ASSEMBLY (LONG SHAFT) 52882A2 SS $0.00 $0.00 ,,,1
13 30711 BUMPER, STEERING ARM NLA $0.00 $0.00 1,1,1,1
14 33986 SCREW, UPPER MOUNT TO STEERING ARM NLA $0.00 $0.00 2,2,2,2
15 62297 BUMPER, STEERING ARM 34255 SS $0.00 $0.00 1,1,1,1
16 76535T BRACKET, REMOTE STEERING 39503 SS $39.87 $39.17 1,1,1,1
17 39781 STUD, REMOTE STEERING BRACKET TO STEERING ARM NLA $0.00 $0.00 2,2,2,2
18 8M0204726 NUT, REMOTE STEERING BRACKET STUD 20509 SS $1.80 $1.76 2,2,2,2
19 31830 SCREW, RIDE-GUIDE KIT TO STEERING ARM NLA $1.57 $1.53 1,1,1,1
20 8M0204726 NUT, RIDE-GUIDE KIT SCREW 20509 SS $1.80 $1.76 1,1,1,1
21 23026 DISC, FRICTION-SWIVEL BRACKET NLA $0.00 $0.00 2,2,2,
22 33969 PLATE, FRICTION-CO-PILOT (SWIVEL BRACKET) NLA $0.00 $0.00 1,1,1,
23 69069 SCREW, FRICTION PLATE TO SWIVEL PIN 34439 SS $0.00 $0.00 2,2,2,
24 52865 WASHER, SWIVEL PIN ACT $3.79 $3.69 ,,,1
25 56267 SERIAL PLATE 39784 SS $0.00 $0.00 1,1,1,1
26 25612 SCREW, DRIVE-SERIAL PLATE TO SWIVEL BRACKET NLA $0.00 $0.00 4,4,4,4
27 26483 BOLT, CLAMP BRACKET TO BOAT TRANSOM NLA $0.00 $0.00 2,2,2,2
28 67981 WASHER, CLAMP BRACKET BOLT 26485 SS $3.19 $3.11 2,2,2,2
29 8M0204646 NUT, CLAMP BRACKET BOLT 26484 SS $4.99 $4.88 2,2,2,2
30 53078 CAP, PLASTIC-TILT TUBE 30498 SS $0.00 $0.00 2,2,2,
30 53078 CAP, PLASTIC-TILT TUBE NLA $0.00 $0.00 ,,,2
31 56349 SHAFT, REVERSE LOCK TO SWIVEL BRACKET 20208 SS $0.00 $0.00 1,1,1,1
32 25598 ROLL PIN, REVERSE LOCK SPRING ATTACHING NLA $0.00 $0.00 1,1,1,1
33 26903A2 REVERSE LOCK ASSEMBLY NLA $0.00 $0.00 1,1,1,1
34 29821 SPRING, REVERSE LOCK TENSION NLA $0.00 $0.00 1,1,1,1
35 45882 COTTER PIN, REVERSE LOCK TO SHAFT ACT $2.96 $2.90 1,1,1,1
36 20215 LEVER, TILT STOP-STARBOARD SIDE (NOT AS SHOWN) NLA $0.00 $0.00 1,1,,
36 47912A2 LEVER ASSEMBLY, TILT STOP-STARBOARD SIDE NLA $0.00 $0.00 ,,1,1
37 2693A3 SWIVEL BRACKET ASSEMBLY (SHORT SHAFT) NLA $0.00 $0.00 1,1,,
37 3349A3 SWIVEL BRACKET ASSEMBLY (SHORT SHAFT) NLA $0.00 $0.00 ,,1,
37 7656A1 SWIVEL BRACKET ASSEMBLY (SHORT SHAFT) 3697A1 SS $0.00 $0.00 ,,,1
37 2694A1 SWIVEL BRACKET ASSEMBLY (LONG SHAFT) NLA $0.00 $0.00 1,1,,
37 3350A1 SWIVEL BRACKET ASSEMBLY (LONG SHAFT) NLA $0.00 $0.00 ,,1,
37 7655A1 SWIVEL BRACKET ASSEMBLY (LONG SHAFT) 3701A1 SS $0.00 $0.00 ,,,1
38 32911 --OIL SEAL, SWIVEL BRACKET ACT $15.59 $15.22 2,2,2,2
39 69059 --FITTING, GREASE-SWIVEL BRACKET 23612 SS $0.00 $0.00 1,1,1,1
40 77633Q LUBRICAP, SWIVEL BRACKET GREASE FITTING 29359 SS $6.99 $6.83 1,1,1,
40 77633Q LUBRICAP, SWIVEL BRACKET GREASE FITTING 53216 SS $6.99 $6.83 ,,,1
41 25176 WASHER, SWIVEL PIN TO BOTTOM YOKE (.060) NLA $0.00 $0.00 1,1,1,1
41 26837 WASHER, SWIVEL PIN TO BOTTOM YOKE (.065) NLA $0.00 $0.00 AR,AR,AR,A
42 77416T1 YOKE, BOTTOM 35402 SS $0.00 $0.00 1,1,1,1
43 71956 NUT, RETAINING-SWIVEL PIN 28202 SS $0.00 $0.00 1,1,1,1
44 26864 LEVER, TILT STOP-PORT SIDE NLA $0.00 $0.00 1,1,,
45 29237 SCREW, RETAINING-TILT STOP LEVER NLA $0.00 $0.00 2,2,,
46 NSS SHIM, RETAINING SCREW-PORT SIDE $0.00 $0.00 1,1,,
47 36076 WASHER, WAVE-RETAINING SCREW-PORT SIDE NLA $0.00 $0.00 1,1,,
47 20846 WASHER, WAVE-RETAINING SCREW-STARBOARD SIDE NLA $0.00 $0.00 1,1,,
48 24652 NUT, ANCHOR AND RETAINING SCREW NLA $1.66 $1.62 4,4,,
49 20217 SCREW, ANCHOR-TILT STOP LEVER NLA $0.00 $0.00 2,2,,
50 20216 SPACER, TILT STOP LEVER NLA $0.00 $0.00 2,2,,
51 47913A2 LEVER ASSEMBLY, TILT LOCK-PORT SIDE NLA $0.00 $0.00 ,,1,1
52 69087 SCREW, TILT LOCK AND STOP LEVER TO SWIVEL BRACKET 47981 SS $0.00 $0.00 ,,2,2
53 29250 NUT, TILT LOCK AND STOP LEVER SCREW 46793 SS $2.89 $2.82 ,,2,2
54 47911 BUSHING, TILT LOCK AND STOP LEVER NLA $0.00 $0.00 ,,2,2
55 34632 WASHER, WAVE-TILT LOCK AND STOP LEVER ACT $2.70 $2.64 ,,2,2
56 26825 WASHER, TILT LOCK AND STOP LEVER ACT $1.50 $1.47 ,,2,2
57 29250 NUT, TILT LOCK AND STOP LEVER TO CLAMP BRACKET 46793 SS $2.89 $2.82 ,,2,
57 29250 NUT, TILT LOCK AND STOP LEVER TO CLAMP BRACKET 46793 SS $2.89 $2.82 ,,,4
