From engine information to vessel systems, the Mercury VesselView 702’s 7” screen is your information portal for your boat. Mercury VesselView allows boaters to display engine information, genset, sounder info and much more. VesselView702 is Mercury's16:9 HD direct sunlight viewable color touchscreen display.
• Features a bright 16x9 aspect ratio, high definition glass touchscreen with glare reducing coating and dimmable lighting
• Features a built in 10Hz GPS and chart platter capability (regional electronic chart cards purchased separately)
• Unique touch only screen interface that delivers intuitive display interaction (optional remote control button interface is available)
• Auto Notification of software updates through the embedded WiFi and Bluetooth capability
• Can be integrated with all the Simrad accessories for the Go5 product line: Radar, Sonar transducers, Fish Finder transducers, AIS, VHF, Sonic Hub/Fusion Link, C-Zone digital switching and more
• Adaptive screen automatically presents information when it is most important
• Descriptive fault text display provides up-to-date information for 30+ engine parameters Including: Fuel Level & Range, Oil Temperature & Pressure, Battery Voltage, Water Depth, Genset and more
• Simultaneous displays information for up to 4 engines in an easy-to-read interface
• Gateway functionality to allow SmartCraft data to be displayed on NMEA 2000 devices
• Supports 16 languages and multiple unit conversions
• Requires Mercury’s VesselView Link to fully integrate the propulsion system and make your multi-function display truly multi-functional (included in the kit)
Kit includes the new VesselView Link, harnessing and GoFree WiFi module.
Works with all SmartCraft capable engines 40 HP and up, single engine applications only. A NMEA2000 backbone is required, starter kit available separately. (see related items)
Included in kit:
8M0110638 VesselView 702 Display Kit
NSS 702 Monitor (not sold separately)
8M6003704 Sun Cover
8M6003703 Bezel Kit (upper and lower)
8M6003817 Gasket Dash
8M6003929 Door
8M6003966 Fastener Kit (bag of 4 screws)
8M6003930 Plug Reader Door
8M0111668 Power Harness
879171T02 Harness Assembly Extension (1000 mm)
8M6002266 Tee NMEA 2000
8M0110639 VesselView Link Base Kit - Single Engine
8M0109594 VesselView Link Module - Single Engine
8M6003801 WiFi - 1 Module Kit
