Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
6 826709109 NUT, 1/4 - 28 F7061 SS $3.59 $3.50 4
7 8M0204649 WASHER F2012 SS $1.20 $1.18 4
8 306671 STUD F694210 SS $10.19 $9.95 4
10 803757T BODY, WATER PUMP F694060-2 SS $41.99 $41.16 1
11 F694564-1 INSERT ACT $30.29 $29.71 1
12 89984T3 IMPELLER F694065 SS $45.99 $45.09 1
13 F694498 KEY ACT $17.29 $16.94 1
14 F694031 GASKET ACT $3.69 $3.59 1
15 F699562 PLATE ACT $22.39 $21.93 1
16 F694830 GASKET ACT $2.69 $2.62 1
17 F2234 SCREW, #10 X 1-1/8 NLA $0.00 $0.00 1
20 F695685-1 CONNECTOR, SHIFT ROD NLA $0.00 $0.00 1
22 F695871 SHAFT, SHIFT ROD NLA $0.00 $0.00 1
23 817472 SEAL, SHIFT ROD F338618-1 SS $8.99 $8.78 1
24 818074A1 COVER, GEAR HOUSING W/SEAL NLA $0.00 $0.00 1
25 28668 SCREW, 1/4 - 20 X 7/8 S.S. F1999 SS $1.70 $1.66 4
26 37828 WASHER F8038 SS $0.80 $0.79 4
27 819740 SEAL F694307 SS $8.79 $8.59 1
28 89238 SEAL F694305 SS $21.19 $20.79 1
29 8M0142854 SEAL F74305 SS $1.10 $1.08 1
30 8245191 RETAINER F694961-1 SS $6.99 $6.83 1
31 F707305 O-RING ACT $9.59 $9.37 1
33 FS707628 DRIVESHAFT, LOWER W/PINION GEAR NLA $0.00 $0.00 1
34 F9280 SHIM (.002) NLA $0.00 $0.00 A/R
- F9279 SHIM (.003) NLA $0.00 $0.00 A/R
- F9278 SHIM (.005) NLA $0.00 $0.00 A/R
- F9277 SHIM (.010) NLA $0.00 $0.00 A/R
35 F695705 ROD, LOWER SHIFT NLA $0.00 $0.00 1
36 FA84621-1 ARM NLA $0.00 $0.00 1
37 42647A1 BEARING F694057 SS $65.99 $62.16 1
38 92721 WASHER F694186 SS $1.50 $1.47 1
39 892827 PLUG, PITOT F694226 SS $0.00 $0.00 1
40 79953Q04 PLUG F50109 SS $7.49 $7.32 3
41 191833 WASHER F8186 SS $1.45 $1.42 3
42 25007 SEAL F498618 SS $1.50 $1.47 1
43 826374 PIN F498891 SS $0.00 $0.00 1
44 F1491 SCREW, 5/16 - 3-1/4 NLA $0.00 $0.00 6
45 53166 WASHER F8096 SS $1.80 $1.76 7
46 35047 SCREW, 5/16 - 18 X 1-1/4 F2325 SS $3.79 $3.69 1
47 F9284 SHIM (.002) NLA $0.00 $0.00 A/R
- F9283 SHIM (.003) NLA $0.00 $0.00 A/R
- F9282 SHIM (.005) NLA $0.00 $0.00 A/R
- F9281 SHIM (.010) NLA $0.00 $0.00 A/R
48 816434A5 GEAR, FORWARD (27 TOOTH) FS707023 SS $0.00 $0.00 1
49 F2310 SPACER (.050) NLA $6.83 $6.65 A/R
- F2290 SPACER (.060) NLA $6.16 $6.01 A/R
- F2291 SPACER (.070) NLA $6.16 $6.01 A/R
- F2292 SPACER (.080) NLA $6.16 $6.01 A/R
50 816433T CLUTCH 816433 SS $363.49 $327.32 1
5 8M0029889 SPRING PIN F2419 SS $0.00 $0.00 1
52 F84871-1 SHIFT PIN NLA $0.00 $0.00 1
53 F90619-2 YOKE ACT $61.49 $57.68 1
54 819284A3 SHAFT, PROPELLER 819284A1 SS $0.00 $0.00 1
55 826377 RETAINER, SNOUT F438930 SS $30.43 $29.87 1
56 F523116-4 SNOUT, EXHAUST NLA $0.00 $0.00 1
57 F1856 WASHER NLA $0.00 $0.00 1
58 90073 SCREW, 5/16 - 18 X 1 F1994 SS $1.85 $1.82 1
59 816435 GEAR, REVERSE F707662 SS $0.00 $0.00 1
60 F2423 THRUST RING NLA $0.00 $0.00 1
61 F707278 SEAL NLA $0.00 $0.00 1
62 803906T SPOOL, PROPELLER SHAFT W/BEARING AND SEALS FA707239 SS $332.99 $300.05 1
63 12576 THRUST RING F523901 SS $27.29 $26.76 1
64 14077 SEAL F697555 SS $19.49 $19.07 1
65 12224 SEAL F697118 SS $22.99 $22.51 1
72 803890T SPACER, PROPELLER F698099-1 SS $91.26 $87.80 1
74 F697299 WASHER, PROP SPLINE NLA $0.00 $0.00 1
75 816629Q WASHER, TAB F697140 SS $5.90 $5.80 1
76 52707Q1 STOP NUT, 3/4 - 16 F7000 SS $16.41 $16.12 1
82 FK1203-1 SEAL KIT ACT $114.00 $102.78 1
83 FK1204-1 WATER PUMP KIT ACT $140.49 $126.52 1
84 35924T1 CUP, BEARING F694056 NLA $27.47 $27.21 1
85 35924T1 BEARING F694058 SS $27.47 $27.21 1
86 35921 NUT, PINION F694188 SS $7.99 $7.81 1
87 F707902 RING, THRUST NLA $0.00 $0.00 1
88 12578T BEARING F523143 SS $33.99 $33.23 1
89 F8586 KEY ACT $1.10 $1.08 1
90 30956T BEARING F523058 SS $19.49 $19.07 1
91 F707286 WASHER, TAB NLA $0.00 $0.00 1
92 819217 RETAINER, THREADED F707807 SS $0.00 $0.00 1
93 F698735-1 SEAL, EXHAUST NLA $0.00 $0.00 1
94 F707885 RETAINER NLA $0.00 $0.00 1
95 819231A13 GEAR HOUSING 816949 SS $0.00 $0.00 1
- 817923A6 GEAR HOUSING COMPLETE 819199A1 SS $0.00 $0.00 1
