| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 803889T | HEAD ASSEMBLY, COMMUTATOR END | F17543 | SS |
|
$149.58 | $140.87 | 1 | |
| 2 | F17539 | BALL | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 8989 | BRUSH SET | F17504 | SS |
|
$0.00 | $0.00 | 1 | |
| 4 | 2529 | SPRING SET | F17500 | SS |
|
$0.00 | $0.00 | 1 | |
| 5 | F17557 | GASKET | NLA |
|
$0.00 | $0.00 | 2 | ||
| 6 | FK654541 | FIELD AND FRAME ASSEMBLY | F17556 | SS |
|
$0.00 | $0.00 | 1 | |
| 7 | F17555 | ARMATURE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | F500843 | CABLE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 9 | F1741 | THREAD FORMING SCREW, 8 X 3/4 | NLA |
|
$0.00 | $0.00 | 2 | ||
| 10 | F178446 | CLAMP | NLA |
|
$0.00 | $0.00 | 2 | ||
| 11 | F17508 | THRUST WASHER | NLA |
|
$0.00 | $0.00 | A/R | ||
| 12 | F17518 | FILLER CAP | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 627021 | O-RING | F17510 | SS |
|
$1.69 | $1.65 | 1 | |
| 14 | F17505 | RESERVOIR AND BRACKET W/SEAL | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | F1966 | PLUG, SWIVEL BRACKET | NLA |
|
$0.00 | $0.00 | 1 | ||
| 16 | 28668 | HEX CAP SCREW, 1/4 - 20 X 7/8 | F1203 | SS |
|
$1.70 | $1.66 | 1 | |
| 17 | FK654541 | VALVE BODY AND PUMP | F17564 | SS |
|
$0.00 | $0.00 | 1 | |
| 18 | F17566 | IDLE GEAR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | F17565 | DRIVE GEAR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | FK654541 | MOTOR AND RESERVOIR | F17563 | SS |
|
$0.00 | $0.00 | 1 | |
| 21 | 2525 | O-RING | F17522 | SS |
|
$0.00 | $0.00 | 1 | |
| 22 | F1310 | ROUND HD SCREW, 10 - 24 X 5/8 | NLA |
|
$0.00 | $0.00 | 4 | ||
| 23 | F449254 | HYDRAULIC LINE, TRIM CYLINDER, UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | F1959 | SCREW, 1/4 - 20 X 1-3/4, STAINLESS STEEL | NLA |
|
$0.00 | $0.00 | 5 | ||
| 25 | F449354 | THRUST BRACKET | NLA |
|
$0.00 | $0.00 | 1 | ||
| 26 | 34939 | SCREW AND LOCKWASHER, 1/4 - 20 X 1/2 | F1734 | SS |
|
$0.00 | $0.00 | 2 | |
| 27 | 817802A3 | COVER W/SEALS AND RETAINER | FA449149 | SS |
|
$0.00 | $0.00 | 1 | |
| 28 | F449342 | SEAL, PISTON SHAFT | ACT | $1.00 | $0.98 | 1 | |||
| 29 | 803481T | PISTON | FA449015 | SS |
|
$0.00 | $0.00 | 1 | |
| 30 | F449278 | PISTON SEAL | ACT | $3.00 | $2.93 | 1 | |||
| 31 | F40278 | SEAL, CYLINDER | ACT | $3.40 | $3.32 | 2 | |||
| 32 | 803823T | CYLINDER | F449010 | SS |
|
$79.92 | $76.87 | 1 | |
| 33 | 818055F | CYLINDER HOUSING | F449545-2 | SS |
|
$0.00 | $0.00 | 1 | |
| 34 | F7053 | NUT, 5/8 - 18 | F1963 | SS |
|
$13.80 | $13.46 | 2 | |
| 35 | F449362 | BEARING | ACT | $9.90 | $9.66 | 2 | |||
| 36 | F449632 | SHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 37 | F449253-1 | HYDRAULIC LINE, TRIM CYLINDER, LOWER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 38 | F449758 | HYDRAULIC LINE, LIFT CYLINDER, UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 39 | F449754-1 | HYDRAULIC LINE, LIFT CYLINDER, LOWER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 40 | 819365A2 | LIFT CYLINDER COMPLETE | FA17559 | SS |
|
$0.00 | $0.00 | 1 | |
| 41 | F178344 | BUSHING, SHOCK ABSORBER - UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 42 | F2A654983 | ADAPTER FITTING PACKAGE | F17577 | SS |
|
$80.83 | $77.75 | 1 | |
| 43 | F17558 | THRU-BOLT PACKAGE | NLA |
|
$0.00 | $0.00 | 1 | ||
| - | 816311T | TY-RAP (NOT SHOWN) | F1877 | SS |
|
$0.59 | $0.58 | 2 | |
| 44 | F654984 | O-RING | FA17561-1 | SS |
|
$6.80 | $6.64 | 1 | |
| 46 | F654618 | O-RING | F17528 | SS |
|
$1.70 | $1.66 | 1 | |
| 48 | FS719962 | SHOCK ABSORBER W/BUSHING | FA178962 | SS |
|
$0.00 | $0.00 | 1 | |
| 49 | 826709117 | NUT, 1/2 - 20, STAINLESS STEEL | F1931 | SS |
|
$11.00 | $10.73 | 2 | |
| 50 | F1960 | PLAIN WASHER | NLA |
|
$0.00 | $0.00 | 2 | ||
| 51 | F449889 | SHAFT, UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 52 | 28782 | SCREW, 5/16 - 18 X 7/8, STAINLESS STEEL | F1822 | SS |
|
$3.00 | $2.93 | 3 | |
| 53 | FK1083 | SEAL KIT, | NLA |
|
$0.00 | $0.00 | 1 |
