Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 F318342 SEAL, WATERLINE INLET UPPER NLA $0.00 $0.00 1
2 F525244 WATERLINE (STD. LEG) NLA $0.00 $0.00 1
- F526244 WATERLINE (LONG LEG) NLA $0.00 $0.00 1
3 F525453 GASKET LEG MOUNTING NLA $0.00 $0.00 1
4 F525779 BAFFLE IDLE RELIEF NLA $0.00 $0.00 1
5 F525133 MOTOR LEG NLA $0.00 $0.00 1
6 F525707 COVER, SHOCK MOUNT LOWER NLA $0.00 $0.00 2
7 F1972 HEX HD SCREW, 1/4 - 20 X 2 1/2 NLA $0.00 $0.00 2
8 38489 SPRING PIN, 3/32 X 5/8 F8540 SS $5.20 $5.08 1
9 F286461 SPRING LOCK BAR HANDLE NLA $0.00 $0.00 1
10 F286114 HANDLE LOCK BAR NLA $0.00 $0.00 1
11 851924A2 BAR LOCK W/8, 9, 10 FA286113 SS $0.00 $0.00 1
12 F525019 KINGPIN NLA $0.00 $0.00 1
13 26992 LOCKWASHER F8083 SS $1.20 $1.18 2
14 64015 NUT, 1/4 - 20 F1341 SS $2.81 $2.75 2
15 830112A1 SPRING PIN, 1/4 X 1 3/8 F1805 SS $0.00 $0.00 1
16 F286169 BEARING SWIVEL BRACKET NLA $0.00 $0.00 2
17 F286422-1 PIVOT TILT LOCK NLA $0.00 $0.00 2
18 819226 SPACER TILT LOCK F286451 SS $0.00 $0.00 2
19 817964A2 SWIVEL BRACKET W/16, 32 NLA $0.00 $0.00 1
20 F286011 WASHER SWIVEL BRACKET NLA $0.00 $0.00 1
21 F525839 SCREW, STEERING FRICTION NLA $0.00 $0.00 1
22 26856 BEARING F197813 SS $4.20 $4.10 2
23 820095A2 LEVER REVERSE LOCK INTERMEDIATE FA387742 SS $0.00 $0.00 1
24 F1794 SPRING PIN, 3/32 X 3/8 NLA $0.00 $0.00 2
25 F286827 LEVER REVERSE LOCK RELEASE NLA $0.00 $0.00 1
26 F286364T LEVER REVERSE LOCK F286364 SS $0.00 $0.00 1
27 F8538 SPRING PIN, 3/32 X 1/2 NLA $0.00 $0.00 2
28 FA341510 LINK REVERSE LOCK LEVER F341510 SS $0.00 $0.00 1
29 F1806 GROOVE PIN, 5/16 - 3 3/4 NLA $0.00 $0.00 1
30 8301111 BRACKET SHALLOW WATER DRIVE F286433 SS $0.00 $0.00 1
31 F286300 SPRING REVERSE LOCK NLA $0.00 $0.00 1
32 F213274 FITTING GREASE NLA $1.94 $1.90 2
33 850259A1 LOCK REVERSE F286349 SS $0.00 $0.00 1
34 F1467 SCREW SWIVEL BRACKET NLA $0.00 $0.00 1
35 F286544-1 SPRING TILT LOCK NLA $0.00 $0.00 1
36 F429541 LOCK TILT ACT $60.58 $58.27 1
37 F525346 MOUNT LOWER SHOCK NLA $0.00 $0.00 2
38 F286037 BOLT STERN BRACKET NLA $0.00 $0.00 1
39 FS567532 BRACKET STERN STARBOARD W/SCREW CLAMP NLA $0.00 $0.00 1
40 832035T HANDLE CARRYING F286647 SS $0.00 $0.00 1
41 FS567532 BRACKET STERN PORT W/SCREW CLAMP NLA $0.00 $0.00 1
42 24198 SPRING PIN, 3/16 X 3/4 F8554 SS $2.02 $1.97 2
43 F424075T3 HANDLE CLAMP SCREW F424075 SS $0.00 $0.00 2
44 826248A1 SCREW CLAMP W/45, 46, 47 817761A2 SS $0.00 $0.00 2
45 F8537 SPRING PIN NLA $0.00 $0.00 2
46 F24074 FOOT CLAMP SCREW NLA $0.00 $0.00 2
47 F66480 STUD CLAMP SCREW NLA $3.64 $3.55 2
48 FA77395-5 IDENTIFICATION PLATE - U.S.A. W/SCREWS NLA $0.00 $0.00 1
- NSS IDENTIFICATION PLATE - CANADA W/SCREWS $0.00 $0.00 1
49 20314 RD HD DRIVE SCREW, #2 X 3/16 F1447 SS $0.00 $0.00 2
50 34931 PLAIN WASHER F8039 SS $2.60 $2.54 1
51 F7026 NUT, 3/8 - 16 F7005 SS $0.00 $0.00 1
52 69150 WAVE WASHER F1666 SS $3.80 $3.71 1
53 F2037 WASHER F525286 SS $0.00 $0.00 1
54 F286286-1 WASHER NLA $0.00 $0.00 1
55 F286585-2 DECAL, TILT RELEASE - U.S.A. F286585-1 SS $0.00 $0.00 1
- F286585-2 DECAL, TILT RELEASE - CANADA NLA $0.00 $0.00 1
56 819110100 HEX CAP SCREW, 1/4 - 20 X 1 F1833 SS $0.50 $0.49 8
