| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| - | 2976A2 | CRANKSHAFT | 1319 | SS |
|
$0.00 | $0.00 | ,,,1,,, | |
| - | 20043 | OILER, FELT | NLA |
|
$0.00 | $0.00 | ,,,1,,, | ||
| 1 | 2976A2 | CRANKSHAFT | 1730 | SS |
|
$0.00 | $0.00 | 1,1,1,1,1, | |
| 2 | 20043 | OILER, FELT - DRIVE SHAFT SPLINE (NOT AS SHOWN) | NLA |
|
$0.00 | $0.00 | 1,1,,,,, | ||
| 2 | 29619 | "O"RING, DRIVE SHAFT SPLINE | ACT | $2.70 | $2.64 | ,,1,1,1,1, | |||
| 3 | 5345A4 | CENTER MAIN BEARING ASSEMBLY | 1030A1 | SS |
|
$0.00 | $0.00 | 1,1,1,1,1, | |
| - | 20032 | --DOWEL PIN, CENTER AMIN BEARING | NLA |
|
$0.00 | $0.00 | 2,2,2,2,2, | ||
| 4 | 28666 | --SCREW, CENTER MAIN BEARING CLAMPING | NLA |
|
$0.00 | $0.00 | 2,2,2,2,2, | ||
| 5 | 20046T | --BEARING, NEEDLE | 20046 | SS |
|
$0.00 | $0.00 | 56,56,56,5 | |
| 6 | 20047 | --RACE, OUTER | NLA |
|
$0.00 | $0.00 | 1,1,1,1,1, | ||
| 7 | 20048 | ----RING, SNAP - OUTER RACE CLAMPING | NLA |
|
$0.00 | $0.00 | 1,1,1,1,1, | ||
| - | 20379 | --DOWEL PIN (STEPPED) | NLA |
|
$0.00 | $0.00 | 1,1,1,1,1, | ||
| 8 | 1619A4 | MAIN BEARING ASSEMBLY (VALVE TYPE) | 1436A1 | SS |
|
$0.00 | $0.00 | 2,2,2,2,2, | |
| - | 20032 | --DOWEL PIN, MAIN BEARING | NLA |
|
$0.00 | $0.00 | 20,20,20,2 | ||
| 9 | 22654 | --SCREW, MAIN BEARING CLAMPING | 20049 | SS |
|
$0.00 | $0.00 | 4,4,4,4,4, | |
| 10 | 88498A1 | REED SET, MATCHED - MAIN BEARING | 20888A1 | SS |
|
$101.84 | $95.90 | 2,2,2,2,2, | |
| 11 | 20053 | REED STOP, MAIN BEARING REED VALVES | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| 12 | 26014 | WASHER, REED STOP MOUNTING SCREW | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| 13 | 20055 | SCREW, REED STOP MOUNTING | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| 8 | 1619A4 | MAIN BEARING ASSEMBLY (VALVE TYPE) | 1436A1 | SS |
|
$0.00 | $0.00 | ,,2,2,2,2, | |
| - | 20032 | --DOWEL PIN, MAIN BEARING | NLA |
|
$0.00 | $0.00 | ,,20,20,20 | ||
| 9 | 26184 | --SCREW, MAIN BEARING CLAMPING | NLA |
|
$0.00 | $0.00 | ,,4,4,4,4, | ||
| - | 24652 | --NUT, MAIN BEARING CLAMPING SCREW | NLA |
|
$1.66 | $1.62 | ,,4,4,4,4, | ||
| 10 | 88498A1 | REED SET, MATCHED - MAIN BEARING | 20888A1 | SS |
|
$101.84 | $95.90 | ,,2,2,2,2, | |
| 11 | 20053 | REED STOP, MAIN BEARING REED VALVES | NLA |
|
$0.00 | $0.00 | ,,8,8,8,8, | ||
| 13 | 77280 | SCREW, REED STOP MOUNTING | 29465 | SS |
|
$0.73 | $0.72 | ,,8,8,8,8, | |
| -- | 29469 | NUT, REED STOP MOUNTING SCREW | NLA |
|
$0.00 | $0.00 | ,,8,8,8,8, | ||
| 14 | 1611A2 | PISTON AND PISTON PIN ASSEMBLY | 1193A2 | SS |
|
$0.00 | $0.00 | 4,4,4,4,4, | |
| 15 | 20057 | --LOCK RING, PISTON PIN | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| 16 | 20058 | RING, PISTON | NLA |
|
$0.00 | $0.00 | 12,12,12,1 | ||
| 17 | 2748A3 | CONNECTING ROD AND CAP ASSEMBLY (SEE NOTE BELOW) | 7A1 | SS |
|
$0.00 | $0.00 | 4,4,4,4,4, | |
| 18 | 45379 | --SCREW, CONNECTING ROD | 20060 | SS |
|
$0.00 | $0.00 | 8,8,8,8,8, | |
| 19 | 20061 | --NUT, CONNECTING ROD SCREW | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| 20 | 20046T | --BEARING, NEEDLE - CRANKPIN | 20046 | SS |
|
$0.00 | $0.00 | 100,100,10 | |
| 21 | 20063 | --BEARING, NEEDLE - PISTON PIN | ACT | $0.60 | $0.59 | 88,88,88,8 | |||
| 22 | 20064 | --WASHER, NEEDLE LOCATING | NLA |
|
$0.00 | $0.00 | 8,8,8,8,8, | ||
| -- | 1612A2 | PISTON AND PISTON PIN ASSEMBLY (.015 OVERSIZE) | 1313A1 | SS |
|
$0.00 | $0.00 | 4,4,4,4,4, | |
| -- | 20992A12 | RING, PISTON (.015 OVERSIZE) | NLA |
|
$0.00 | $0.00 | 12,12,12,1 |
