| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0185982 | SPACER ASSEMBLY 5 IN Black | 8M0142779 | SS |
|
$549.99 | $500.56 | 1 | |
| 1 | 8M0228079 | SPACER ASSEMBLY 5 IN Silver | 8M0147047 | SS |
|
$657.49 | $598.40 | 1 | |
| 2 | 8M0042271 | ----GUIDE Water Tube | ACT | $6.69 | $6.54 | 1 | |||
| 3 | 8M0142780 | ----TUBE Water | ACT | $9.79 | $9.56 | 1 | |||
| 4 | 8M0084244 | ----PIN Dowel | ACT | $3.29 | $3.21 | 2 | |||
| 5 | 8M0142781 | ----STUD (M12 x 179) | ACT | $12.19 | $11.90 | 5 | |||
| 6 | 856982 | ----WASHER (.500 x .810 x .09 | ACT | $1.80 | $1.76 | 5 | |||
| 7 | 896895 | ----NUT (M12) | ACT | $2.99 | $2.92 | 5 | |||
| 8 | 8M0142787 | SPACER ASSEMBLY 10 IN Black | ACT | $0.00 | $0.00 | 1 | |||
| 8 | 8M0230292 | SPACER ASSEMBLY 10 IN Silver | 8M0147046 | SS |
|
$916.49 | $834.66 | 1 | |
| 9 | 8M0042271 | ----GUIDE Water Tube | ACT | $6.69 | $6.54 | 1 | |||
| 10 | 8M0142789 | ----WATER TUBE | ACT | $15.69 | $15.31 | 1 | |||
| 11 | 8M0142788 | ----STUD (M12 x 306) | ACT | $18.29 | $17.92 | 5 | |||
| 12 | 8M0084244 | ----PIN Dowel | ACT | $3.29 | $3.21 | 2 | |||
| 13 | 856982 | ----WASHER (.500 x .810 x .09 | ACT | $1.80 | $1.76 | 5 | |||
| 14 | 896895 | ----NUT (M12) | ACT | $2.99 | $2.92 | 5 | |||
| 15 | 8M0168203 | DRIVESHAFT KIT Long | 8M0146062 | SS |
|
$705.49 | $642.11 | 1 | |
| 15 | 8M0168206 | DRIVESHAFT KIT X-Long | 8M0146063 | SS |
|
$685.99 | $624.42 | 1 | |
| 15 | 8M0168209 | DRIVESHAFT KIT XX-Long | 8M0146064 | SS |
|
$699.99 | $637.43 | 1 | |
| 15 | 8M0168204 | DRIVESHAFT KIT Long | 8M0146065 | SS |
|
$772.49 | $703.52 | 1 | |
| 15 | 8M0168208 | DRIVESHAFT KIT X-Long | 8M0146066 | SS |
|
$787.49 | $717.05 | 1 | |
| 15 | 8M0168210 | DRIVESHAFT KIT XX-Long | 8M0146067 | SS |
|
$830.49 | $756.28 | 1 | |
| 16 | 8M0168203 | DRIVESHAFT KIT Long | ACT |
|
$705.49 | $642.11 | 1 | ||
| 16 | 8M0168206 | DRIVESHAFT KIT X-Long | ACT |
|
$685.99 | $624.42 | 1 | ||
| 16 | 8M0168209 | DRIVESHAFT KIT XX-Long | ACT |
|
$699.99 | $637.43 | 1 | ||
| 16 | 8M0168205 | DRIVESHAFT KIT Long | ACT |
|
$724.49 | $659.68 | 1 | ||
| 16 | 8M0168208 | DRIVESHAFT KIT X-Long | ACT |
|
$787.49 | $717.05 | 1 | ||
| 16 | 8M0168210 | DRIVESHAFT KIT XX-Long | ACT |
|
$830.49 | $756.28 | 1 |
