Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 833137F1 PLATE NLA $0.00 $0.00 1
2 88807A16 CABLE ASSEMBLY (4.00 Inches) Black ACT $5.10 $4.98 1
3 8M0207773 RELAY ASSEMBLY 828151A1 SS $22.49 $22.17 3
4 NSS --------NOT SOLD SEPARATE DECAL-TRIM RELAY $0.00 $0.00 3
5 828102 ----BRACKET ACT $4.99 $4.88 3
6 8M0214955 ----BUSHING 818968 SS $2.90 $2.83 3
7 818967 ----GROMMET ACT $3.20 $3.13 3
8 878084T3 HARNESS ASSEMBLY Engine Wiring ACT $1,135.00 $1,040.48 1
8 878084T4 HARNESS ASSEMBLY Engine Wiring ACT $1,138.00 $1,043.23 1
9 858754 ----COVER Fuse ACT $9.70 $9.46 1
10 879346A49 ----HARNESS ASSEMBLY (DIRECT INJECTOR) 858781A2 SS $27.00 $26.52 1
11 879346A50 ----HARNESS ASSEMBLY (FUEL INJECTOR) 858780A2 SS $28.58 $28.07 1
12 879346A41 ----HARNESS ASSEMBLY (TPS) 878073A2 SS $19.90 $19.41 1
- 879964A2 ----HARNESS ASSEMBLY Encoder Crank Position Sensor ACT $27.17 $26.68 1
- 881262A2 ----HARNESS ASSEMBLY Alternator Alternator ACT $44.08 $43.29 1
13 832969T20 ----FUSE Mini - Yellow - 20 Ampere 83296920 SS $6.60 $6.44 4
13 832969T15 ----FUSE Mini - Blue - 15 Ampere 83296915 SS $4.10 $4.00 1
13 832969T05 ----FUSE Mini - Tan - 5 Ampere 8329695 SS $6.70 $6.54 1
14 8M0204668 NUT (.312-18) 68292 SS $3.80 $3.71 2
15 819514T16 HARNESS ASSEMBLY Trim ACT $122.92 $115.76 1
16 878231A6 HARNESS ASSEMBLY Fuse - 100 Ampere ACT $99.58 $95.78 1
17 858755 CLIP (1.00) ACT $2.30 $2.25 1
18 828991T CLIP 828991 SS $5.10 $4.98 1
19 82129110 SCREW (M6 x 10) ACT $1.80 $1.76 3
20 82129125 SCREW (M6 x 25 MM) ACT $3.40 $3.32 4
21 82129135 SCREW (M6 x 35) ACT $3.70 $3.61 1
22 45076 NUT (#10-32) Brass ACT $1.80 $1.76 2
23 53166 LOCKWASHER (.312) ACT $1.80 $1.76 2
24 91912 BUSHING NLA $0.00 $0.00 1
25 13541 PLUG Male ACT $3.20 $3.13 1
26 816311T TIE STRAP (8.00 Inches) ACT $0.59 $0.58 AR
27 8M0086580 ECM Engine Control Module 85961021 SS $2,617.00 $2,399.06 1
27 8M0086580 ECM Engine Control Module 85961055S SS $2,617.00 $2,399.06 1
27 8M0086581 ECM Engine Control Module 85961056S SS $2,027.50 $1,858.65 1
27 8M0086584 ECM Engine Control Module 85961057S SS $2,689.22 $2,465.26 1
28 82130025 SCREW (M6 x 25) ACT $4.10 $4.00 3
29 856954 BUSHING ACT $7.00 $6.83 3
30 8M0190980 GROMMET 834985 SS $3.60 $3.52 3
31 65567 WASHER (.265 x .750 x .04 ACT $2.90 $2.83 3
32 8590881 CLIP ACT $5.60 $5.47 1
33 82129114 SCREW (M6 x 14) ACT $2.50 $2.44 1
34 82130012 SCREW (M6 x 12) ACT $1.80 $1.76 3
35 817109A2 SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals) ACT $56.99 $54.83 1
36 822179 ----GROMMET ACT $4.50 $4.39 2
37 8M0214955 ----BUSHING 818968 SS $2.90 $2.83 2
38 813938 CAP NUT (#10-32) ACT $3.20 $3.13 1
39 882829A1 CABLE ASSEMBLY Starter ACT $65.25 $62.76 1
40 8M0204649 WASHER (.281 x .500 x .06 29245 SS $1.20 $1.18 1
41 832948A1 CONNECTOR ASSEMBLY 2 POS Male ACT $11.80 $11.51 1
42 13540 CAP Female ACT $3.20 $3.13 2
43 881065A1 CONNECTOR 6 Pin Plug ACT $17.90 $17.46 1
44 8500673 BOOT Insulator - Yellow ACT $6.10 $5.95 1
45 880771T1 CABLE ASSEMBLY (24.00 Inches) Red NLA $0.00 $0.00 1
46 8500671 BOOT Insulator - Red ACT $3.70 $3.61 1
47 881175A1 CAP ASSEMBLY 3 Position-Female Connector (FEMALE) ACT $7.50 $7.41 1
48 881176A1 CAP ASSEMBLY 3 Position-Male Connector (MALE) ACT $2.75 $2.71 1
