| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8742A22 | TANK ASSY-OIL Complete | 8742A20 | SS |
|
$408.49 | $384.45 | 1 | |
| 1 | 87421 | ----RESERVOIR-OIL Oil | ACT | $90.99 | $87.45 | 1 | |||
| 2 | 12335A1 | ----BRACKET KIT Oil Tank Hold Down | ACT |
|
$110.99 | $104.46 | 1 | ||
| 3 | 12323A1 | --------CORD/HOOK KIT | ACT | $23.49 | $23.08 | 1 | |||
| 4 | 12320 | --------BRACKET Hold Down | ACT | $8.69 | $8.49 | 2 | |||
| 5 | 79968 | --------SCREW | ACT | $2.99 | $2.92 | 4 | |||
| 6 | 43298A2 | ----CAP ASSY Oil Tank | ACT |
|
$31.99 | $31.43 | 1 | ||
| 7 | 11332 | --------O RING Cap | ACT | $4.74 | $4.65 | 1 | |||
| 8 | 816190A4 | ----SENDER ASSY-OIL Adaptor | ACT |
|
$201.99 | $189.84 | 1 | ||
| 9 | 43298A2 | --------CAP ASSY Housing Adaptor | ACT |
|
$31.99 | $31.43 | 1 | ||
| 10 | 11332 | ------------O RING | ACT | $4.74 | $4.65 | 1 | |||
| 11 | 99802 | --------TUBE ASSY Oil Pick Up | ACT | $16.99 | $16.62 | 1 | |||
| 12 | 99439 | ----HOSE ASY-114 INCH Oil Line | ACT | $89.49 | $85.93 | 1 | |||
| 13 | 816311T | ----TIE STRAP | ACT | $0.60 | $0.59 | 5 | |||
| 14 | 8781051 | CHECK VALVE Crankcase | 878105 | SS |
|
$45.99 | $45.09 | 1 | |
| 15 | NSS | NOT SOLD SEPARATE Plug |
|
$0.00 | $0.00 | 1 | |||
| 16 | 994436 | RESERVOIR-OIL Oil | ACT |
|
$233.49 | $219.66 | 1 | ||
| 17 | NSS | --------NOT SOLD SEPARATE Decal - Reservoir Warning |
|
$0.00 | $0.00 | 1 | |||
| 18 | 43300A5 | CAP ASSY Oil Reservoir | ACT |
|
$90.49 | $86.73 | 1 | ||
| 19 | 8M0187298 | ----FLOAT ASSY | 99022A1 | SS |
|
$24.09 | $23.65 | 1 | |
| 20 | 99265 | ----NUT-PUSH | ACT | $1.80 | $1.76 | 1 | |||
| 21 | 43307T | ----GASKET Reservoir Cap | 43307 | SS |
|
$6.09 | $5.95 | 1 | |
| 22 | 816311T | TIE STRAP | ACT | $0.60 | $0.59 | 4 | |||
| 23 | 82381455 | TUBING-25 IN Cut 4.750 Inches | ACT | $23.69 | $23.24 | 1 | |||
| 24 | 690201 | SCREW | 69020 | SS |
|
$2.89 | $2.82 | 3 | |
| 25 | 42118 | WASHER Oil Reservoir Screw | ACT | $3.89 | $3.79 | 6 | |||
| 26 | 42117 | GROMMET Oil Reservoir Screw | ACT | $4.19 | $4.10 | 3 | |||
| 27 | 42116 | BUSHING Oil Reservoir Screw | ACT | $2.99 | $2.92 | 3 | |||
| 28 | NSS | NOT SOLD SEPARATE Plug - Yellow |
|
$0.00 | $0.00 | 1 | |||
| 29 | 8M0207780 | FITTING Special - Oil Tubing | 424254 | SS |
|
$55.99 | $53.79 | 1 | |
| 30 | 8M0108355 | HOSE-57 INCH Cut 6.00 Inches | 830756109 | SS |
|
$52.49 | $50.34 | 1 | |
| 31 | 1938512 | LINK ASSY Throttle Lever To Oil Pump | ACT | $18.99 | $18.66 | 1 | |||
| 32 | 32228 | SCREW | ACT | $1.80 | $1.76 | 1 | |||
| 32 | 41507 | SCREW | ACT | $0.50 | $0.49 | 1 | |||
| 33 | 815699T | PUMP ASSY-OIL | ACT |
|
$385.49 | $368.08 | 1 | ||
| 34 | 11379 | ----O RING | ACT |
|
$4.69 | $4.59 | 1 | ||
| 35 | 8141032 | ----BUSHING | ACT | $40.49 | $39.61 | 1 | |||
| 36 | 859112 | BEARING Drive Gear | ACT | $42.99 | $42.23 | 1 | |||
| 37 | 48462 | O RING | ACT |
|
$1.80 | $1.76 | 1 | ||
| 38 | 8591111 | GEAR-DRIVEN | ACT | $190.49 | $179.01 | 1 | |||
| 39 | 15969A3 | FILL KIT-DECK OIL | ACT |
|
$99.49 | $95.46 | OPT | ||
| 40 | 15969A13 | ----FILL KIT-DECK OIL | 15969A5 | SS |
|
$101.99 | $95.90 | 1 | |
| 41 | 15966 | --------PLATE-OIL FILL | ACT | $14.19 | $13.85 | 1 | |||
| 42 | 815504228 | --------CLAMP | ACT | $17.29 | $16.94 | 2 | |||
| 43 | 15967 | --------ADAPTER Oil Filler | ACT | $51.99 | $49.90 | 1 | |||
| 44 | 11332 | --------O RING | ACT | $4.74 | $4.65 | 1 | |||
| 45 | 850719 | ----HOSE-OILFILL-100 Oil Filler - Cut As Required | ACT | $709.99 | $667.84 | AR | |||
| - | 804986A1 | GASKET/SEAL SET Powerhead | ACT | $418.99 | $400.23 | 1 | |||
| - | 858257R21 | POWERHEAD ASSY | 858257T18 | SS/NLA |
|
$0.00 | $0.00 | 1 |
