| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 45907 | PLUG Yellow Flywheel | ACT | $7.09 | $6.93 | 1 | |||
| 2 | 8M0214915 | NUT (.625-18) Flywheel | 22339 | SS |
|
$11.69 | $11.41 | 1 | |
| 3 | 33001 | WASHER (.641 x 1.250 x .190) Flywheel Nut | 68229 | SS |
|
$11.59 | $11.32 | 1 | |
| 4 | 8722A16 | FLYWHEEL ASSEMBLY | 8722A11 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 4 | 8722A17 | FLYWHEEL ASSMEBLY | 8722A9 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 5 | 32417 | ----SCREW (.250-28 x .625) Flexible Plate to Flywheel | NLA |
|
$1.10 | $1.08 | 8 | ||
| 6 | 88755 | ----RATCHET Flywheel (Manual) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 68997 | ----SCREW (.312-24 x .750) Ratchet to Flywheel (Manual) | ACT | $1.23 | $1.21 | 8 | |||
| 8 | 832074A6 | STATOR | 5454A56 | SS |
|
$502.99 | $457.76 | 1 | |
| 8 | 832075A20 | STATOR | 5454A25 | SS |
|
$555.99 | $506.35 | 1 | |
| 9 | 75840 | SCREW (#10-24 x .880) Stator to Upper End Cap | ACT | $1.80 | $1.76 | 4 | |||
| 10 | 96452A4 | TRIGGER ASSEMBLY | ACT | $159.99 | $144.17 | 1 | |||
| 13 | 88721A1 | HARNESS ASSEMBLY Switch Box to Ignition Coil | NLA |
|
$0.00 | $0.00 | 1 | ||
| 14 | 832757A4 | COIL ASSEMBLY Ignition | 7370A13 | ACT | $0.00 | $0.00 | 4 | ||
| 15 | 45076 | NUT (#10-32) Brass Ignition Coil Terminals | ACT | $1.80 | $1.76 | 8 | |||
| 16 | 60466A19 | CABLE ASSEMBLY Coil to Switch Box | NLA |
|
$0.00 | $0.00 | 4 | ||
| 17 | 87554 | COVER Ignition Coil | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 88856 | SCREW (.190-32 x 2.00) Coil Cover | NLA |
|
$0.00 | $0.00 | 5 | ||
| 19 | 30164 | WASHER (.192 x .375 x .03 Coil Cover Screw | ACT | $2.49 | $2.43 | 5 | |||
| 20 | 813715A5 | LEAD ASSEMBLY Spark Plug | ACT |
|
$76.99 | $72.52 | 1 | ||
| 21 | 63709A1 | ----BOOT/TERMINAL KIT | ACT | $8.19 | $8.00 | 4 | |||
| 22 | 2854T01 | ----BOOT Ignition Coil | 2854 | SS |
|
$2.99 | $2.92 | 4 | |
| 23 | 896329833 | SPARK PLUG | 97182 | SS |
|
$14.49 | $14.14 | 4 | |
| 23 | 896329898 | SPARK PLUG (NGK-BUZHW) | 14103550 | REP |
|
$19.69 | $19.21 | 4 | |
| 24 | 5772A7 | SWITCHBOX ASSEMBLY | 5772A2 | SS |
|
$461.49 | $461.49 | 1 | |
| 25 | 20619 | SCREW (#12-24 x 1.25) Switch Box and "J" Clip to Plate | NLA |
|
$0.00 | $0.00 | 4 | ||
| 26 | 8M0024808 | J CLIP Switch Box Leads | 642351 | SS |
|
$8.19 | $8.00 | 1 | |
| 27 | 45076 | NUT (#10-32) Brass Switch Box Terminals | ACT | $1.80 | $1.76 | 13 | |||
| 28 | 88322 | PLATE Switch Box | NLA |
|
$0.00 | $0.00 | 1 | ||
| 29 | 54615 | SCREW (.250-20 x .625) Switch Box Plate to Cylinder Block | NLA |
|
$0.00 | $0.00 | 2 | ||
| 30 | 638131 | TERMINAL BLOCK | 63813 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 31 | 20568 | SCREW (.190-24 x .62) Terminal Block | ACT | $1.40 | $1.37 | 2 | |||
| 31 | 62568 | SCREW (#10-16 x .375) Terminal Block | ACT | $1.10 | $1.08 | 2 |
