| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 803724T02 | HOUSING, Driveshaft | ACT |
|
$453.49 | $433.35 | 1 | ||
| 1 | 8M0192164 | HOUSING, Driveshaft | 803725T02 | SS |
|
$508.99 | $478.54 | 1 | |
| 2 | 8M0224584 | BOLT | 823042048 | SS |
|
$3.79 | $3.69 | 3 | |
| 3 | 16192 | WASHER | 895106001 | SS |
|
$3.59 | $3.50 | 9 | |
| 4 | 803593 | PLUG | ACT |
|
$10.29 | $10.05 | 1 | ||
| 5 | 8M0111615 | BOLT | 895136 | SS |
|
$18.09 | $17.65 | 1 | |
| 6 | 895146 | WASHER | ACT | $3.39 | $3.30 | 1 | |||
| 7 | 898103227 | BOLT | 823042047 | SS |
|
$12.79 | $12.49 | 6 | |
| 8 | 854617001 | GASKET | ACT | $13.89 | $13.56 | 1 | |||
| 9 | 853577001 | COVER, Drain | ACT | $15.09 | $14.73 | 1 | |||
| 10 | 898101953 | BOLT | 16830010 | SS |
|
$6.09 | $5.95 | 8 | |
| 11 | 16119 | PIN, Dowel | ACT | $8.19 | $8.00 | 4 | |||
| 12 | 896116T | SKIRT | ACT | $160.49 | $151.07 | 1 | |||
| 12 | 896116T01 | SKIRT, Camouflage | ACT | $347.99 | $327.40 | 1 | |||
| 13 | 898101192 | SCREW, Tapping | ACT | $5.79 | $5.66 | 2 | |||
| 14 | 16826 | WASHER, Stainless Steel | 895106 | SS |
|
$3.29 | $3.21 | 2 | |
| 15 | 898101003 | SEAL, Skirt | ACT | $5.89 | $5.76 | 2 | |||
| 16 | 898101002 | SEAL, Skirt | ACT | $7.29 | $7.12 | 1 | |||
| 17 | 896631 | GROMMET | ACT | $18.79 | $18.42 | 1 | |||
| 18 | 898101105 | COVER, Idle Exhaust | ACT | $21.59 | $21.20 | 1 | |||
| 19 | 167051 | BOLT, (M6 x 20) | ACT | $6.09 | $5.95 | 6 | |||
| 20 | 8M0099564 | GASKET, Idle Exhaust Port Cover | 898101106 | SS |
|
$12.89 | $12.58 | 1 | |
| 21 | 898101137 | PLATE | ACT | $18.69 | $18.33 | 1 | |||
| 22 | 895148001 | GASKET | ACT | $15.39 | $15.02 | 1 | |||
| 23 | 898101086 | GROMMET | ACT | $5.29 | $5.17 | 1 | |||
| 24 | 95275002 | PLATE | ACT | $5.49 | $5.37 | 1 | |||
| 25 | 803663T15 | GASKET | 803663015 | SS |
|
$95.49 | $91.86 | 1 | |
| 26 | 852432001 | SEAL, Rubber | ACT | $18.09 | $17.65 | 1 | |||
| 27 | 8M0097392 | ADAPTOR PLATE | 898101T61 | SS |
|
$218.49 | $205.69 | 1 | |
| 28 | 8537072 | SEAL, Oil | ACT | $14.19 | $13.85 | 1 | |||
| 29 | 835427T04 | GASKET | ACT | $69.49 | $66.61 | 1 | |||
| - | 8M0079064 | GASKET SET, Powerhead | 898101A06 | SS |
|
$266.49 | $250.73 | 1 |
