| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M4502084 | THROTTLE BODY ASSEMBLY | 885170001 | SS |
|
$699.99 | $658.50 | 1 | |
| 2 | 8M0221731 | --SENSOR, TPS | 853678T | SS |
|
$128.99 | $121.33 | 1 | |
| 3 | NSS | --NOT SOLD SEPARATE, O-Ring |
|
$0.00 | $0.00 | 1 | |||
| 4 | NSS | --NOT SOLD SEPARATE, SCREW |
|
$0.00 | $0.00 | 2 | |||
| 5 | NSS | --NOT SOLD SEPARATE, Washer |
|
$0.00 | $0.00 | 1 | |||
| 6 | 8M0188224 | --MUFFLER, Intake Air Control | 863829 | SS |
|
$6.79 | $6.64 | 1 | |
| 7 | 8M0162949 | --GASKET, Throttle Body | 885172 | SS |
|
$83.99 | $80.56 | 1 | |
| 8 | 866295A02 | IAC ADAPTOR KIT | ACT |
|
$259.99 | $244.77 | 1 | ||
| 9 | 863006 | --O-RING | ACT | $2.59 | $2.53 | 1 | |||
| 10 | 808547 | --O-RING | ACT | $1.70 | $1.66 | 1 | |||
| 11 | 8M0188226 | --FILTER | 8M2001030 | SS |
|
$11.79 | $11.51 | 1 | |
| 12 | NSS | --NOT SOLD SEPARATE, GASKET |
|
$0.00 | $0.00 | 1 | |||
| 13 | 4008612 | SCREW, (M4 x 12) | ACT | $1.80 | $1.76 | 2 | |||
| 14 | 8M0181068 | VALVE, Idle Air | 862998 | SS |
|
$231.49 | $217.85 | 1 | |
| 15 | 4008820 | SCREW, (M6 x 20) | ACT | $2.89 | $2.82 | 2 | |||
| 16 | 8M2020112 | BRACKET, Throttle | ACT | $20.89 | $20.46 | 1 | |||
| 17 | 8267138 | NUT, (.25-20) | ACT | $2.79 | $2.72 | 1 | |||
| 18 | 97477A3 | STUD KIT, Throttle Anchor | ACT |
|
$33.19 | $32.57 | 1 | ||
| 19 | NSS | --NOT SOLD SEPARATE, Spacer |
|
$0.00 | $0.00 | 1 | |||
| 20 | 8267139 | --NUT, (.250-28) | ACT | $2.59 | $2.53 | 2 | |||
| 21 | 20533 | --WASHER | ACT | $1.50 | $1.47 | 1 | |||
| 22 | 31866 | --SPACER, (.256 x .313 x .625) | ACT | $5.69 | $5.56 | 2 | |||
| 22 | 11284 | --SPACER, (.62 Diameter) | ACT | $4.19 | $4.10 | 1 | |||
| 23 | 864338 | STUD, Special | ACT | $12.69 | $12.39 | 3 | |||
| 24 | 863416T | FLAME ARRESTOR | ACT | $245.49 | $230.88 | 1 | |||
| 25 | 8M2020419 | BRACKET, Cover Mount | ACT | $21.09 | $20.71 | 1 | |||
| 26 | 401386 | NUT, (M6) Stainless Steel | ACT | $5.09 | $4.98 | 3 | |||
| 27 | 8M0053840 | COVER, Engine | ACT | $496.49 | $474.38 | 1 | |||
| 28 | 897445501 | SCREW, (M6 x 20 MM), Flame Arrestor Bracket to Oil Fill Tube | ACT | $5.49 | $5.37 | 1 | |||
| 29 | 8M0086022 | TUBING, (20.00 Inches Bulk), Breather | 1589431 | SS |
|
$36.49 | $35.68 | 1 | |
| 30 | 8M0088142 | STUD | 885171 | SS |
|
$45.99 | $45.17 | 1 | |
| 31 | 8M2001671 | GROMMET | ACT | $5.49 | $5.37 | 4 | |||
| 32 | 8M0043702 | DECAL, M-Icon, 53mm Black | ACT | $11.49 | $11.22 | 1 | |||
| 33 | 8M0053016 | DECAL, Center 4.3L EC | ACT | $16.99 | $16.58 | 1 | |||
| 33 | 8M0053017 | DECAL, Center 4.3L EC (SeaCore) | ACT | $70.99 | $68.21 | 1 | |||
| 34 | 8M0054510 | STUD | ACT | $10.39 | $10.15 | 2 |
