| Ref # | Current Part Nbr | Description | Superceded From | Status | Notes | List Price | Online Price | Quan Used | Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0176311 | FUEL PUMP ASSEMBLY | ACT | $1,114.78 | $1,021.64 | 1 | |||
| 2 | 8M0172100 | HARNESS Foot Throttle | ACT | $174.00 | $165.91 | 1 | |||
| - | 893359K03 | DTS HOT FOOT AND HAND THROTTLE SWITCH KIT | NLA |  | $710.34 | $654.66 | 1 | ||
| 3 | 8M0172101 | HARNESS EXTENSION Fuel Pump | ACT | $25.15 | $24.79 | 1 | |||
| 4 | 8M0172102 | HARNESS Start/Stop | ACT | $35.00 | $34.51 | 1 | |||
| 5 | 8M0179744 | EXPANSION BOTTLE KIT Gearcase | ACT | | $1,347.31 | $1,234.75 | 1 | ||
| 6 | 8M0087451 | ----PLUG (18MM) | ACT | $7.50 | $7.32 | 1 | |||
| 7 | 8M0204693 | ----SEAL | 830749 | SS | | $4.99 | $4.88 | 2 | |
| 8 | 86036Q | ----HOSE | ACT | $49.49 | $48.41 | 1 | |||
| 9 | 818611A2 | PUMP KIT Hydraulic Trim | ACT | | $1,463.45 | $1,341.18 | 1 | ||
| 9 | 818377A2 | PUMP KIT Hydraulic Trim | ACT | | $1,399.37 | $1,282.46 | 1 | ||
| 10 | 818567 | ----BRACKET | ACT | $36.17 | $35.52 | 1 | |||
| 11 | 38837 | ----SCREW (.312-18 x 1.12) | ACT | $3.10 | $3.03 | 1 | |||
| 12 | 57792 | ----WASHER | ACT | $1.30 | $1.27 | 2 | |||
| 13 | 34948 | ----SPACER | ACT | $11.80 | $11.51 | 2 | |||
| 14 | 65999A12 | ----CABLE ASSEMBLY Ground | ACT | $5.10 | $4.98 | 1 | |||
| 15 | 79138A9 | ----CABLE ASSEMBLY (6.00 Feet) Black-Negative | ACT | $70.00 | $67.33 | 1 | |||
| 16 | 92051 | ----SCREW (10-16 x .75) | ACT | $1.70 | $1.66 | 1 | |||
| 17 | 853654T02 | ----SOLENOID | ACT | $96.41 | $93.59 | 2 | |||
| 18 | 41508 | ----SCREW (.250-20 x .500) Stainless Steel | ACT | $3.70 | $3.61 | 4 | |||
| 19 | 20110 | ----NUT (#10-32) | ACT | $1.60 | $1.57 | 4 | |||
| 20 | 22753 | ----WASHER | ACT | $3.30 | $3.22 | 4 | |||
| 21 | 8M0204646 | ----NUT (.312-18) | 26484 | SS | | $4.80 | $4.69 | 4 | |
| 22 | 65999A11 | ----CABLE ASSEMBLY | ACT | $3.90 | $3.81 | 1 | |||
| 23 | 79139A27 | ----CABLE ASSEMBLY Battery | ACT | $19.86 | $19.58 | 1 | |||
| 24 | 79139A26 | ----CABLE ASSEMBLY Red | ACT | $4.90 | $4.78 | 1 | |||
| 25 | 46265 | ----BOOT | ACT | $4.00 | $3.91 | 3 | |||
| 26 | 77366 | ----FITTING | ACT | $12.30 | $12.00 | 2 | |||
| 27 | 38609 | ----PLUG | ACT | $17.90 | $17.46 | 1 | |||
| - | 87762A04 | ----BRACKET ASSEMBLY Trim Pump Mounting | ACT | | $149.50 | $140.79 | 1 | ||
| 28 | 87762 | --------BRACKET | ACT | $144.17 | $135.77 | 1 | |||
| 29 | 87760T | --------MOUNTING PLATE | ACT | $78.58 | $75.59 | 1 | |||
| 30 | 39349 | --------SCREW (.312-18 x .750) St | ACT | $1.70 | $1.66 | 1 | |||
| 31 | 8M0204647 | --------LOCKWASHER (.312) | 26993 | SS | | $1.70 | $1.66 | 1 | |
| 32 | 90271 | ----SCREW (.375-16 x .62) | ACT | $1.70 | $1.66 | 2 | |||
| 33 | 63826 | ----SCREW (.375-16 x 2.50) | ACT | $3.60 | $3.52 | 2 | |||
| 34 | 82670912 | ----NUT (.375-16) Stainless S | ACT | $6.50 | $6.34 | 2 | |||
| 35 | 58643 | ----LOCKWASHER (.375) | ACT | $1.70 | $1.66 | 2 | |||
| 36 | 8M0214963 | ----WASHER (.406 x .750 x .10 | 856774 | SS | | $2.50 | $2.44 | 4 | |
| 37 | NSS | --------NOT SOLD SEPARATE Trim Harness Assembly | | $0.00 | $0.00 | 1 | |||
| 38 | 61691 | ----SWITCH | NLA | | $192.34 | $183.80 | 1 | ||
| - | 893359K01 | DTS HOT FOOT THROTTLE KIT | ACT | $537.67 | $495.52 | 1 | |||
| - | 8M0183111 | ROLLOVER VALVE KIT | ACT | $891.07 | $838.07 | 1 | |||
| - | 8M0225356 | CLAMP KIT Clamp Kit-Complete | ACT | $201.58 | $189.84 | 1 |
