| Ref # | Current Part Nbr | Description | Superceded From | Status | Notes | List Price | Online Price | Quan Used | Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0057416 | STEERING ACTUATOR ASSEMBLY Starboard | 8M2008525 | SS/NLA |  | $12,566.83 | $11,255.49 | 1 | |
| 1 | 8M0057416 | STEERING ACTUATOR ASSEMBLY Port | 8M2008524 | SS/NLA | | $12,566.83 | $11,255.49 | 1 | |
| 1 | 8M0057413 | STEERING ACTUATOR ASSEMBLY Starboard | 8M2016016 | SS/NLA | | $5,923.25 | $5,429.96 | 1 | |
| 1 | 8M0057413 | STEERING ACTUATOR ASSEMBLY Port | 8M2016017 | SS/NLA | | $5,923.25 | $5,429.96 | 1 | |
| 2 | NSS | --------NOT SOLD SEPARATE CLEVIS PIN | | $0.00 | $0.00 | 1 | |||
| 3 | 8M2010043 | ----RETAINER | ACT | $36.17 | $35.52 | 1 | |||
| 4 | 8M0214928 | ----SCREW (M6 x 16) | 4000328 | SS | | $3.90 | $3.81 | 1 | |
| 5 | 8M0007568 | ----TRANSDUCER 500 PSI | ACT | $255.83 | $240.92 | 1 | |||
| 6 | 897345T14 | ----SENSOR Position, Secondary-Decreasing | ACT | $821.79 | $773.14 | 1 | |||
| 7 | 897345T15 | ----SENSOR Position, Primary-Increasing | ACT | $788.36 | $741.69 | 1 | |||
| 8 | 897345T13 | ----HARNESS | ACT | $479.36 | $458.20 | 1 | |||
| 9 | 8M0142542 | ----SENSOR | 8M0010146 | SS | | $30.58 | $30.03 | 1 | |
| 10 | 8M6001284 | ----TRANSDUCER | 8M0007569 | SS | | $318.83 | $300.25 | 3 | |
| 11 | NSS | --------NOT SOLD SEPARATE ELBOW | | $0.00 | $0.00 | 1 | |||
| 12 | NSS | --------NOT SOLD SEPARATE RELAY | | $0.00 | $0.00 | 1 | |||
| 13 | NSS | --------NOT SOLD SEPARATE GROMMET | | $0.00 | $0.00 | 1 | |||
| 14 | NSS | --------NOT SOLD SEPARATE SCREW | | $0.00 | $0.00 | 1 | |||
| 15 | NSS | --------NOT SOLD SEPARATE BRACKET | | $0.00 | $0.00 | 1 | |||
| 16 | NSS | --------NOT SOLD SEPARATE SCREW | | $0.00 | $0.00 | 3 | |||
| 17 | 804352 | ----CLIP | ACT | $1.70 | $1.66 | 3 | |||
| 18 | NSS | --------NOT SOLD SEPARATE THRUST VECTOR MODULE | | $0.00 | $0.00 | 1 | |||
| 19 | 856954 | ----BUSHING | ACT | $6.70 | $6.54 | 3 | |||
| 20 | 8M0190980 | ----GROMMET | 834985 | SS | | $3.50 | $3.42 | 3 | |
| 21 | 65567 | ----WASHER (.265 x .750 x .04 | ACT | $2.80 | $2.74 | 3 | |||
| 22 | NSS | --------NOT SOLD SEPARATE NUT | | $0.00 | $0.00 | 3 | |||
| 23 | 8M2007090 | ----FITTING (-6) ORF TO ( -8) ORB, Straight | ACT | | $54.92 | $52.82 | 1 | ||
| 23 | 8M2008375 | ----FITTING Adapter (-6ORF TO -8ORB), 90 Degree | ACT | | $89.50 | $86.09 | 1 | ||
| 24 | 8M2015982 | ----FITTING Adapter (-6ORF TO -8ORB) | ACT | $64.92 | $62.44 | 1 | |||
| 25 | 8M2013299 | ----CAP | ACT | $13.80 | $13.46 | 1 | |||
| 26 | 8M2013298 | ----CAP | ACT | $16.80 | $16.39 | 1 | |||
| 27 | 8M2013313 | ----NUT | ACT | $9.00 | $8.78 | 3 | |||
| 28 | 8M2013312 | ----O-RING | NLA | | $1.58 | $1.55 | 3 | ||
| 29 | 8M2001117 | ----O-RING (.489 X .070) | ACT | $5.10 | $4.98 | 10 | |||
| 30 | 8M2004603 | ----O-RING | ACT | $9.40 | $9.17 | 10 | |||
| - | 879172A19 | DUST CAP KIT | NLA | | $75.70 | $72.81 | 1 |
