| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 887623T03 | PICKUP ASSY-OIL | ACT | $91.49 | $87.61 | 1 | |||
| 2 | 8M0092943 | O RING | 846594 | SS |
|
$3.59 | $3.50 | 1 | |
| 3 | 8M0103807 | SCREW | 88552525 | SS |
|
$2.39 | $2.33 | 3 | |
| 4 | 889618001 | GASKET Oil Sump | ACT | $19.89 | $19.41 | 1 | |||
| 5 | 880626T01 | TUBE-EXHAUST | NLA |
|
$0.00 | $0.00 | 1 | ||
| 6 | 8M0103814 | SCREW | 88552635 | SS |
|
$4.19 | $4.10 | 4 | |
| 7 | 880629 | SEAL Exhaust Tube | ACT | $13.79 | $13.46 | 1 | |||
| 8 | 880639T | SUMP-OIL | ACT | $269.99 | $254.19 | 1 | |||
| 9 | 8M0103808 | SCREW | 88552530 | SS |
|
$2.79 | $2.72 | 12 | |
| 10 | 887753A02 | TUBE-OIL DRAIN | ACT |
|
$55.99 | $53.63 | 1 | ||
| 10 | 8M0082193 | TUBE-OIL DRAIN | 888513A02 | SS |
|
$63.49 | $61.00 | 1 | |
| 11 | 892446 | ----O RING | ACT | $1.50 | $1.47 | 2 | |||
| 12 | 892228 | ----PIN-DOWEL | ACT | $4.49 | $4.39 | 1 | |||
| 13 | 888592005 | PLUG-OIL DRAIN | ACT | $17.09 | $16.78 | 1 | |||
| 14 | 8M0188614 | SEAL Drain Plug | 888593 | SS |
|
$9.79 | $9.56 | 1 | |
| 15 | 8M0103808 | SCREW | 88552530 | SS |
|
$2.79 | $2.72 | 1 | |
| 16 | 885541A01 | TUBE-WATER | ACT |
|
$63.49 | $61.10 | 1 | ||
| 16 | 885541A02 | TUBE-WATER XL | ACT |
|
$70.49 | $67.57 | 1 | ||
| 16 | 885541A03 | TUBE-WATER XXL | ACT |
|
$68.99 | $66.37 | 1 | ||
| 17 | 892445 | ----O RING | ACT | $9.69 | $9.46 | 1 | |||
| 18 | 8M0214983 | COUPLING ASSY | 887987A1 | SS |
|
$6.39 | $6.25 | 1 | |
| 19 | 8M0204673 | ----O RING | 90196 | SS |
|
$4.99 | $4.88 | 1 | |
| 20 | 8M0204645 | ----O RING | 21836 | SS |
|
$2.39 | $2.33 | 1 | |
| 21 | 8M0114707 | POPPET VALVE ASSY | 888913A01 | SS |
|
$74.99 | $72.06 | 1 | |
| 22 | 64878 | ----SPRING | ACT | $6.79 | $6.64 | 1 | |||
| 23 | 893385001 | ----RETAINER | ACT | $48.49 | $47.38 | 1 | |||
| 24 | 648771 | ----DIAPHRAGM | ACT | $11.79 | $11.51 | 1 | |||
| 25 | 889706 | ----WASHER | ACT | $11.09 | $10.83 | 1 | |||
| 26 | 69570 | ----SCREW | ACT | $1.80 | $1.76 | 1 | |||
| 27 | 893384001 | COVER-POPPET Poppet | ACT | $17.89 | $17.52 | 1 | |||
| 28 | 889561 | GASKET Poppet | ACT | $33.29 | $32.65 | 1 | |||
| 29 | 88552535 | SCREW | ACT | $4.69 | $4.59 | 2 | |||
| - | 880552A07 | GASKET SET | 880552A06 | SS |
|
$383.49 | $360.91 | 1 | |
| - | 895247R06 | ORD 895247R06 | 895247A06 | NLA |
|
$0.00 | $0.00 | 1 |
