| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| - | 815822A53 | GEAR HSG ASSY-STD (COMPLETE) | 815822A43 | SS |
|
$3,164.29 | $2,942.99 | 1 | |
| - | 815822A55 | GEAR HSG ASSY-STD (COMPLETE) | 815822A45 | SS |
|
$3,164.29 | $2,942.99 | 1 | |
| 1 | 815822A36 | ----GC GENII -BASIC (BASIC) | ACT | $1,942.99 | $1,781.00 | 1 | |||
| 40 | 8M0226861 | ----CRANK-SHIFTER | 76865 | SS |
|
$43.49 | $42.72 | 1 | |
| 41 | 818349T1 | ----SPOOL/SHAFT ASSY Shift | 818349A1 | SS |
|
$136.99 | $128.63 | 1 | |
| 42 | 8M0063266 | ----ORD 15-8M0063266 | 44491A1 | REP |
|
$52.99 | $50.90 | AR | |
| 43 | 30894A1 | ----BEARING SET | ACT | $60.49 | $58.19 | 1 | |||
| 44 | 878087A2 | ----GEAR SET Forward With Pinion | 828072A3 | SS |
|
$609.49 | $573.29 | 1 | |
| 44 | 878617A2 | ----GEAR SET Forward With Pinion | 853592A2 | SS |
|
$802.49 | $754.73 | 1 | |
| 45 | 30895T | --------BEARING | 30895 | SS |
|
$20.79 | $20.38 | 1 | |
| 46 | 856823 | ----RING-RETAINING | ACT | $10.99 | $10.73 | 1 | |||
| 47 | 8M0100263 | ----PIN-CROSS | 30632 | SS |
|
$4.49 | $4.39 | 1 | |
| 48 | 30893 | ----SPRING | ACT | $2.69 | $2.62 | 1 | |||
| 49 | 8M0140445 | ----PROPSHAFT | 850308 | SS |
|
$641.99 | $603.80 | 1 | |
| 50 | 828073A1 | ----GEAR KIT-REVERSE Reverse | ACT |
|
$191.49 | $180.26 | 1 | ||
| 50 | 853593A1 | ----GEAR-REVERSE Reverese | ACT |
|
$252.99 | $238.02 | 1 | ||
| 51 | 824108 | --------SPACER-THRUST | ACT | $4.59 | $4.49 | 1 | |||
| 52 | 681001 | ----RING-THRUST | ACT | $18.79 | $18.34 | 1 | |||
| 53 | 88957T | ----BEARING-BALL | 88957 | SS |
|
$64.49 | $62.04 | 1 | |
| 54 | 818763A10 | ----CARRIER ASSY-BRG | ACT |
|
$253.49 | $238.65 | 1 | ||
| 55 | 8M0214920 | --------O RING | 31534 | SS |
|
$6.29 | $6.15 | 1 | |
| 56 | 30956T | --------BEARING | 30956 | SS |
|
$19.49 | $19.07 | 1 | |
| 57 | 14077 | --------SEAL (INSIDE) | ACT | $19.49 | $19.07 | 1 | |||
| 58 | 12224 | --------SEAL (OUTSIDE) | ACT | $22.99 | $22.51 | 1 | |||
| 59 | 806105Q1 | --------ANODE KIT | 806105A1 | SS |
|
$29.09 | $28.56 | 1 | |
| 60 | 806290 | ------------SCREW | ACT | $1.20 | $1.18 | 2 | |||
| 61 | 69432 | ------------LOCKWASHER | ACT | $1.00 | $0.98 | 2 | |||
| 62 | 18323 | ----WASHER-KEYED | ACT | $24.89 | $24.39 | 1 | |||
| 63 | 8M0168577 | ----RETAINER | 79448 | SS |
|
$43.49 | $42.72 | 1 | |
| 64 | 76214Q5 | ----ANODE KIT | 76214A5 | SS |
|
$29.99 | $29.38 | 1 | |
| 64 | 31640Q4 | ----ANODE/TRIM TAB | 316404 | SS |
|
$18.69 | $18.33 | 1 | |
| 65 | 8M0204686 | ----SCREW | 806327 | SS |
|
$6.99 | $6.83 | 1 | |
| 66 | 806210 | ----LOCKWASHER | ACT | $1.80 | $1.76 | 1 | |||
| 67 | 853594T | ----CLUTCH | 853594 | SS |
|
$299.49 | $281.97 | 1 | |
| 68 | 65210 | SCREW | ACT | $2.89 | $2.82 | 1 | |||
| 69 | 35479 | LOCKWASHER | ACT | $1.80 | $1.76 | 1 | |||
| 70 | 835467Q01 | THRUST WASHER | 8354671 | SS |
|
$41.60 | $40.85 | 1 | |
| 71 | 31211Q03 | THRUST WASHER KIT | 31211A2 | SS |
|
$14.82 | $14.55 | 1 | |
| 72 | 816629Q | TAB WASHER | 816629 | SS |
|
$5.90 | $5.80 | 1 | |
| 72 | 8M0204724 | TAB WASHER-.770 2 Pin Flo-Torq Drive Sleeve Adaptor | 8M0042130 | SS |
|
$5.90 | $5.80 | 1 | |
| 73 | 52707Q1 | NUT | 827614 | SS |
|
$16.41 | $16.12 | 1 | |
| 74 | 423511 | WASHER | ACT | $2.97 | $2.92 | 1 | |||
| 75 | 859135 | NUT | 817618 | SS |
|
$6.09 | $5.95 | 4 | |
| - | 816575A3 | SEAL KIT | ACT | $112.49 | $105.71 | - | |||
| - | 888756Q03 | ANODE KT-ALP GEN2 | 888756A1 | SS |
|
$121.49 | $114.19 | AR | |
| - | 888755Q03 | ANODE KT-ALP GEN2 | 888755A1 | SS |
|
$190.99 | $179.71 | AR |
