Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
- 815822A53 GEAR HSG ASSY-STD (COMPLETE) 815822A43 SS $3,164.29 $2,900.77 1
- 815822A55 GEAR HSG ASSY-STD (COMPLETE) 815822A45 SS $3,164.29 $2,900.77 1
1 815822A36 ----GC GENII -BASIC ACT $1,942.99 $1,781.00 1
2 821526001 --------FILLER BLOCK 821526 SS $18.99 $18.53 1
3 379721 --------PIN ACT $3.59 $3.50 1
4 57984 --------STUD ACT $19.49 $19.07 1
4 8M0204686 --------SCREW 806327 SS $6.99 $6.83 1
5 8M0058389 --------PLUG KIT-DRAIN 67892A1 SS $11.69 $11.41 1
6 8M0187157 ------------WASHER-BLK 19183 $1.49 $1.46 1
7 8M0204680 --------SEAL 455771 SS $4.29 $4.20 1
8 43044 --------PIN-DOWEL-SOLID ACT $2.49 $2.43 2
9 42647A1 --------BEARING ASSY ACT $65.99 $63.48 1
10 859135 --------NUT 817618 SS $6.09 $5.95 1
11 8M0140449 ----DRIVESHAFT 853648 SS $742.49 $698.28 1
11 8M0140449 ----DRIVESHAFT 853647 SS $742.49 $698.28 1
12 8M0063267 ----ORD 8M0063267 42637A1 REP $27.79 $27.25 AR
13 33138A1 ----BEARING SET ACT $73.49 $70.70 1
14 853651 ----RETAINER-BEARING ACT $13.99 $13.66 1
15 NSS --------NOT SOLD SEPARATE GEAR-Pinion $0.00 $0.00 1
15 NSS --------NOT SOLD SEPARATE GEAR-Pinion $0.00 $0.00 1
16 92721 ----WASHER ACT $1.50 $1.47 1
17 35921 ----NUT ACT $7.99 $7.81 1
18 8M0204709 ----FACEPLATE-W/P 8172761 SS $14.59 $14.24 1
19 8M0214948 ----CARRIER ASSY 821759A4 SS $47.99 $47.16 1
20 8M0214939 --------SEAL 66302 SS $16.99 $16.62 2
20 864319 --------SEAL-DOUBLE ACT $9.99 $9.76 1
21 8M0142854 --------O RING 90011 SS $1.10 $1.08 1
22 817275A1 ----HOUSING KIT-W/P ACT $102.99 $96.61 1
23 8M0142616 --------GASKET Nitrile Coated Stainless Steel 8M0050720 SS $9.59 $9.37 1
23 430331 --------GASKET Fiber ACT $11.09 $10.83 1
24 8172771 --------GASKET 817277 SS $5.69 $5.56 1
25 816575A2 --------SEAL KIT-OBM ACT $10.89 $10.63 1
26 816928 ----SCREW ACT $2.39 $2.33 4
27 43026T2 ----IMPELLER-W/P 430262 SS $36.49 $35.81 1
28 8M0204723 ----KEY 43037 SS $4.39 $4.30 1
29 816597A1 ----COUPLING ASSY ACT $19.49 $19.15 1
30 8M0204645 --------O RING 21836 SS $2.39 $2.33 2
31 816583 ----SLEEVE ACT $11.09 $10.83 1
32 8M0127949 ----SHAFT KIT-SHIFT 815919A1 SS $93.49 $89.69 1
33 29641 --------E RING ACT $1.80 $1.76 1
34 77674 ----WASHER ACT $1.80 $1.76 1
35 815921A20 ----BUSHING ASSY 815921A13 SS $29.09 $28.56 1
36 892361 --------SEAL 89236 SS $17.69 $17.26 1
37 8M0214927 --------O RING 36318 SS $1.70 $1.66 2
38 627021 --------O RING 62702 SS $1.70 $1.66 1
39 816928 ----SCREW ACT $2.39 $2.33 2
-- 817275Q05 REBUILT KIT-W/P 817275A4 SS $198.49 $186.85 AR
- 8M0100526 REPAIR KIT-W/P ACT $66.99 $64.29 1
-- 816575A3 SEAL KIT ACT $112.49 $105.71 AR
-- 88397A1 SEAL KIT ACT $50.49 $48.50 AR
