| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 806787A3 | SEPARATOR ASSY Vapor Separator | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 880331 | GROMMET | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 80568932 | HOSE-13.5 INCH Vent | NLA |
|
$0.00 | $0.00 | 1 | ||
| 4 | 805435A1 | HOSE KIT Fuel Rail to VST | NLA |
|
$0.00 | $0.00 | 2 | ||
| 5 | 805970 | ----O RING | ACT |
|
$3.59 | $3.50 | 2 | ||
| 6 | 805392 | SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 19064 | BUSHING | ACT | $19.59 | $19.23 | 2 | |||
| 8 | 88033 | GROMMET | NLA |
|
$0.00 | $0.00 | 2 | ||
| 9 | 805405T | RAIL ASSY-FUEL Fuel | NLA |
|
$0.00 | $0.00 | 1 | ||
| 10 | 805698 | SCREW | NLA |
|
$0.00 | $0.00 | 4 | ||
| 11 | 805437 | CLIP | NLA |
|
$0.00 | $0.00 | 1 | ||
| 12 | 805557 | SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 805408 | VALVE | ACT | $34.99 | $34.29 | 1 | |||
| 14 | 8M0046566 | ORD 8M0046566 | 805515 | REP |
|
$4.69 | $4.59 | 1 | |
| 15 | 805227A1 | REGULATOR KIT | ACT |
|
$147.99 | $139.14 | 1 | ||
| 16 | 805531 | ----O RING | ACT |
|
$5.59 | $5.47 | 1 | ||
| 17 | 805406 | ----FILTER-FUEL Pressure Regulator | ACT | $6.89 | $6.73 | 1 | |||
| 18 | 852368 | SCREW | 56682 | SS |
|
$1.70 | $1.66 | 2 | |
| 19 | 89302 | WASHER | ACT | $1.80 | $1.76 | 2 | |||
| 20 | 805562 | NUT | NLA |
|
$0.00 | $0.00 | 2 | ||
| 21 | 805514A1 | FITTING KIT Outlet | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 860348A2 | PLUG ASSY | ACT |
|
$13.19 | $12.88 | 1 | ||
| 22 | 805553 | ----O RING | ACT |
|
$5.19 | $5.08 | 1 | ||
| 23 | 805407 | ----O RING | ACT |
|
$3.19 | $3.11 | 1 | ||
| 24 | 8M0188618 | CLAMP | 815504105 | SS |
|
$4.09 | $4.00 | 2 | |
| 25 | 806689 | FITTING | ACT | $1.80 | $1.76 | 1 | |||
| 26 | 7381567 | TUBING-42 INCH | ACT | $30.99 | $30.36 | 2 | |||
| - | 805396A95 | GASKET SET Overhaul | NLA |
|
$0.00 | $0.00 | 1 |
