| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0219202 | BRACKET ASSY Drain | 862226A2 | SS |
|
$51.99 | $49.98 | 1 | |
| 2 | 862298 | ----BUSHING | ACT | $16.49 | $16.09 | 1 | |||
| 3 | 862230 | ----DECAL | ACT | $1.90 | $1.86 | 1 | |||
| 4 | 627021 | ----O-RING | ACT | $1.70 | $1.66 | 2 | |||
| 5 | 862257A1 | CABLE/HANDLE ASSY With Cable | ACT | $41.99 | $41.07 | 1 | |||
| 6 | 862225 | COUPLING ASSY Coupling | ACT | $19.09 | $18.63 | AR | |||
| 7 | 862229 | SLIDER | ACT | $9.89 | $9.66 | 1 | |||
| 8 | 8M0062585 | HOSE-21.5 INCH Blue Drain | 8622241 | SS |
|
$32.99 | $32.41 | 2 | |
| 9 | 862223 | FITTING | NLA |
|
$4.31 | $4.22 | 2 | ||
| 10 | 862605T1 | FITTING-T | 862329 | SS |
|
$9.49 | $9.27 | 1 | |
| 11 | 8M0180470 | ADAPTOR-QUICK CNT | 862603 | SS |
|
$8.19 | $8.00 | 2 | |
| 12 | 862605T1 | ADAPTOR ASSY Includes O-Rings | ACT |
|
$9.49 | $9.27 | 1 | ||
| 13 | 627021 | ----O-RING | ACT |
|
$1.70 | $1.66 | 2 | ||
| 14 | 627021 | O-RING | ACT |
|
$1.70 | $1.66 | 2 | ||
| 15 | 8M0062590 | HOSE | 8623175 | SS |
|
$34.99 | $34.24 | 1 | |
| 16 | 862325 | HOSE ASSY Transom to Thermostat Housing | ACT |
|
$88.49 | $84.88 | 1 | ||
| 17 | 862324 | HOSE ASSY Power Steering Cooler to Thermostat Housing | ACT |
|
$83.49 | $80.16 | 1 | ||
| 18 | 863840 | FITTING Flush | 862228 | SS |
|
$23.59 | $23.16 | 1 | |
| 19 | 815504216 | CLAMP Hose | ACT |
|
$18.69 | $18.24 | 2 | ||
| 20 | 815504212 | CLAMP Hose | ACT |
|
$5.89 | $5.76 | AR | ||
| 21 | 8M0188622 | CLAMP | 815504222 | SS |
|
$5.69 | $5.56 | AR | |
| NS | 8M0074364 | COVER-.375 Hose Clamp End | 8079923 | SS |
|
$3.29 | $3.21 | AR | |
| - | 861481A2 | POWER STEERING KT | ACT | $1,262.99 | $1,157.63 | 1 |
