| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| - | 8M0213278 | TIE BAR KIT Plus One (26 Inch) | 8M0096320 | SS |
|
$1,022.21 | $909.21 | 1 | |
| - | 8M0213284 | TIE BAR KIT Plus One (28 Inch) | 8M0096321 | SS |
|
$994.08 | $916.15 | 1 | |
| - | 8M0213294 | TIE BAR KIT Plus One (30 Inch) | 8M0096322 | SS |
|
$1,011.56 | $899.70 | 1 | |
| - | 8M0213293 | TIE BAR KIT Plus One (32 Inch) | 8M0096323 | SS |
|
$1,012.80 | $900.83 | 1 | |
| - | 8M0213297 | TIE BAR KIT Plus One (34 Inch) | 8M0096324 | SS |
|
$1,017.20 | $904.74 | 1 | |
| - | 8M0097268 | TIE BAR KIT Plus One (36 Inch) | ACT |
|
$1,072.96 | $954.34 | 1 | ||
| - | 8M0099104 | ----HARDWARE KIT Coupler and Tierod | ACT |
|
$46.30 | $45.42 | 1 | ||
| 1 | 8M0099090 | ----EXTENSION ARM KIT | ACT |
|
$214.35 | $201.84 | 1 | ||
| - | 8M0213285 | --------HARDWARE KIT Extension Arm | 8M0099091 | SS |
|
$84.52 | $81.31 | 1 | |
| 2 | NSS | ------------------------NOT SOLD SEPARATE Screw (M10 x 1.5 HEX HD) |
|
$0.00 | $0.00 | 1 | |||
| 3 | NSS | ------------------------NOT SOLD SEPARATE Tab Washer (10 mm) |
|
$0.00 | $0.00 | 2 | |||
| 4 | NSS | ------------------------NOT SOLD SEPARATE Washer (10 mm) |
|
$0.00 | $0.00 | 2 | |||
| 5 | NSS | ------------------------NOT SOLD SEPARATE Screw (M10 x 1.5 HEX HD CAP, SS) |
|
$0.00 | $0.00 | 2 | |||
| 6 | NSS | ------------------------NOT SOLD SEPARATE Nut (JAM M10 HEX) |
|
$0.00 | $0.00 | 3 | |||
| 7 | 8M0215008 | ------------LOCTITE 271 THREADLOCKER .5 ml | 95812 | SS |
|
$4.99 | $4.88 | 1 | |
| 8 | 8M0099094 | ----CLEVIS ASSEMBLY KIT Triple Includes Hardware and Bushing | ACT |
|
$305.57 | $287.73 | 1 | ||
| 9 | 8M0099105 | --------BUSHING KIT | ACT | $57.55 | $55.36 | 1 | |||
| 10 | NSS | ----------------NOT SOLD SEPARATE Shoulder Screw (M10 x 1.5 HEX HD) |
|
$0.00 | $0.00 | 1 | |||
| 11 | 8M0099092 | ----TIEROD KIT Includes Hardware and Bushing | ACT |
|
$87.72 | $84.39 | 1 | ||
| 12 | NSS | ----------------NOT SOLD SEPARATE Nut (JAM M20 HEX) |
|
$0.00 | $0.00 | 1 | |||
| 13 | 8M0099084 | ----COUPLER ASSEMBLY KIT 26 Inch | ACT |
|
$208.54 | $196.37 | 1 | ||
| 13 | 8M0099085 | ----COUPLER ASSEMBLY KIT 28 Inch | ACT |
|
$214.69 | $202.17 | 1 | ||
| 13 | 8M0099086 | ----COUPLER ASSEMBLY KIT 30 Inch | ACT |
|
$231.29 | $217.80 | 1 | ||
| 13 | 8M0099087 | ----COUPLER ASSEMBLY KIT 32 Inch | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 8M0099088 | ----COUPLER ASSEMBLY KIT 34 Inch | ACT |
|
$241.81 | $227.71 | 1 | ||
| 13 | 8M0099089 | ----COUPLER ASSEMBLY KIT 36 Inch | ACT |
|
$283.05 | $266.57 | 1 |
