| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 42213A24 | SWIVEL HEAD | ACT |
|
$360.08 | $339.10 | 1 | ||
| 1 | 42213A25 | SWIVEL HEAD | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 823939 | BUSHING | ACT | $16.75 | $16.45 | 2 | |||
| 3 | 822147 | PLATE Tiller Handle | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 8221471 | PLATE | ACT |
|
$11.00 | $10.73 | 1 | ||
| 4 | 40011107 | SCREW (M5 x 16) Stainless | ACT | $1.80 | $1.76 | 2 | |||
| 4 | 4006731 | SCREW (M6 x 16) | ACT | $2.90 | $2.83 | 2 | |||
| 5 | 822145 | WASHER | ACT | $2.50 | $2.44 | 2 | |||
| 6 | 826792 | WAVE WASHER | ACT | $8.80 | $8.59 | 1 | |||
| 7 | 822146 | WASHER | ACT | $17.99 | $17.56 | 1 | |||
| 8 | 821468A66 | ARM ASSEMBLY Steering Handle | 821468A8 | SS |
|
$192.33 | $181.13 | 1 | |
| 8 | 821468A66 | ARM ASSEMBLY Steering Handle | 821468A9 | SS |
|
$192.33 | $181.13 | 1 | |
| 9 | 822441 | RETAINER | ACT | $3.60 | $3.52 | 1 | |||
| 10 | 40011107 | SCREW (M5 x 16) Stainless | ACT | $1.80 | $1.76 | 1 | |||
| 11 | 822148A3 | COVER KIT | ACT |
|
$109.83 | $103.44 | 1 | ||
| 11 | 822148A2 | COVER KIT | ACT |
|
$85.42 | $82.16 | 1 | ||
| 12 | 822150 | ----PULLEY | ACT | $35.25 | $34.62 | 1 | |||
| 13 | NSS | --------NOT SOLD SEPARATE Pulley Case (PART OF REF. #11) |
|
$0.00 | $0.00 | 1 | |||
| 14 | 878608 | ----SCREW (#10-16 x .500) | 812832 | SS |
|
$1.70 | $1.66 | 1 | |
| 15 | 43242T09 | ----CABLE Throttle | 432429 | SS |
|
$46.42 | $45.58 | 2 | |
| 15 | 432426 | ----CABLE Throttle | ACT |
|
$32.25 | $31.67 | 2 | ||
| 16 | 9600910 | ----SLEEVE | ACT |
|
$1.60 | $1.57 | 1 | ||
| 16 | 960099 | ----SLEEVE (12.00 Inches) | ACT |
|
$1.70 | $1.66 | 1 | ||
| 17 | 8242002 | DECAL | ACT |
|
$13.80 | $13.46 | 1 | ||
| 17 | 8242004 | DECAL | 8242001 | SS |
|
$13.80 | $13.46 | 1 | |
| 18 | 8M0221732 | GRIP | 99589 | SS |
|
$22.42 | $22.02 | 1 | |
| 19 | 8M0104615 | SWITCH ASSEMBLY Stop | 823609A1 | SS |
|
$59.83 | $57.55 | 1 | |
| 20 | 821972T | KNOB Throttle | 821972 | SS |
|
$18.60 | $18.14 | 1 | |
| 21 | 892995 | LOCK Throttle | 821971 | SS |
|
$7.80 | $7.61 | 1 | |
| 22 | 8M0204707 | SCREW (M6 x 25) | 4000330 | SS |
|
$4.00 | $3.91 | 1 | |
| 23 | 822429 | HANDLE Throttle | ACT |
|
$16.60 | $16.19 | 1 | ||
| 23 | 821465 | HANDLE Throttle | ACT |
|
$26.50 | $26.03 | 1 | ||
| 24 | 821463T01 | TILLER TUBE | 821463A1 | SS |
|
$97.50 | $93.78 | 1 | |
| 25 | 96203 | SPRING | ACT | $4.20 | $4.10 | 1 |
