| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| - | 821468T4 | TILLER HANDLE | ACT |
|
$733.65 | $690.22 | 1 | ||
| - | 821468T2 | TILLER HANDLE | ACT |
|
$736.57 | $692.97 | 1 | ||
| 1 | 822148A4 | ----COVER KIT | ACT |
|
$90.25 | $86.81 | 1 | ||
| 1 | 822148A2 | ----COVER KIT | ACT |
|
$85.42 | $82.16 | 1 | ||
| 2 | 822150 | --------PULLEY | ACT | $35.25 | $34.62 | 1 | |||
| 3 | NSS | ----------------NOT SOLD SEPARATE Case |
|
$0.00 | $0.00 | 1 | |||
| 4 | 878608 | --------SCREW (#10-16 x .500) | ACT | $1.70 | $1.66 | 1 | |||
| 5 | 43242T03 | --------CABLE Throttle | 432423 | SS |
|
$27.58 | $27.09 | 1 | |
| 5 | 432426 | --------CABLE Throttle | ACT |
|
$32.25 | $31.67 | 1 | ||
| 6 | 43242T03 | --------CABLE Throttle | 432423 | SS |
|
$27.58 | $27.09 | 1 | |
| 6 | 432426 | --------CABLE Throttle | ACT |
|
$32.25 | $31.67 | 1 | ||
| 7 | 960099 | --------SLEEVE (12.00 Inches) | ACT | $1.70 | $1.66 | 1 | |||
| 8 | 821468A66 | ----ARM ASSEMBLY Steering Handle | ACT |
|
$192.33 | $181.13 | 1 | ||
| 9 | 4010516 | --------SCREW (M5 x 16) Stainless | ACT | $1.80 | $1.76 | 2 | |||
| 10 | 40011107 | ----SCREW (M5 x 16) Stainless | ACT | $1.80 | $1.76 | 1 | |||
| 11 | 821972T | ----KNOB Throttle | 821972 | SS |
|
$18.60 | $18.14 | 1 | |
| 12 | 96203 | ----SPRING | ACT | $4.20 | $4.10 | 1 | |||
| 13 | 892995 | ----LOCK Throttle | 821971 | SS |
|
$7.80 | $7.61 | 1 | |
| 14 | 8M0204707 | ----SCREW (M6 x 25) | 4000330 | SS |
|
$4.00 | $3.91 | 1 | |
| 15 | 821463T01 | ----TILLER TUBE | 821463A1 | SS |
|
$97.50 | $93.78 | 1 | |
| 16 | 8242002 | ----DECAL | ACT |
|
$13.80 | $13.46 | 1 | ||
| 16 | 8242004 | ----DECAL | ACT |
|
$13.80 | $13.46 | 1 | ||
| 17 | 822429 | ----HANDLE Throttle | ACT |
|
$16.60 | $16.19 | 1 | ||
| 17 | 821465 | ----HANDLE Throttle | ACT |
|
$26.50 | $26.03 | 1 | ||
| 18 | 8M0221732 | ----GRIP | 99589 | SS |
|
$22.42 | $22.02 | 1 | |
| 19 | 8M0104615 | ----SWITCH ASSEMBLY Stop | 823609A17 | SS |
|
$59.83 | $57.55 | 1 | |
| 19 | 823609A18 | ----SWITCH ASSEMBLY Start/Stop | ACT |
|
$43.00 | $42.23 | 1 | ||
| 20 | 822441 | ----RETAINER | ACT | $3.60 | $3.52 | 1 | |||
| 21 | 8221471 | PLATE | ACT | $11.00 | $10.73 | 1 | |||
| 22 | 823939 | BUSHING | ACT | $16.75 | $16.45 | 1 | |||
| 23 | 4000384 | SCREW (M10 x 80) | ACT | $14.20 | $13.85 | 2 | |||
| 24 | 822841F1 | BRACKET | ACT |
|
$176.17 | $165.90 | 1 | ||
| 25 | 823939 | BUSHING | ACT | $16.75 | $16.45 | 1 | |||
| 26 | 822145 | WASHER | ACT | $2.50 | $2.44 | 1 | |||
| 27 | 826792 | WAVE WASHER | ACT | $8.80 | $8.59 | 1 | |||
| 28 | 822145 | WASHER | ACT | $2.50 | $2.44 | 1 | |||
| 29 | 822146 | WASHER | ACT | $17.99 | $17.56 | 1 |
