| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 803530 | MANIFOLD Inlet | ACT | $53.42 | $51.38 | 1 | |||
| 2 | 8035133 | O-RING | ACT |
|
$7.20 | $7.03 | 1 | ||
| 3 | 8150684 | BOLT (M6 x 25) | ACT | $2.39 | $2.33 | 2 | |||
| 4 | 80350810 | GASKET Insulator | ACT | $7.59 | $7.42 | 1 | |||
| 5 | 803508013 | GASKET | 8035085 | SS |
|
$5.10 | $4.98 | 2 | |
| 6 | 8M0057113 | LINE Fuel (1000 mm) | 953949 | SS |
|
$27.75 | $27.25 | 1 | |
| 7 | 95395 | CLIP Stainless Steel | ACT | $3.10 | $3.03 | 1 | |||
| 8 | 803529T06 | PUMP Fuel | 803529T1 | SS |
|
$147.67 | $139.06 | 1 | |
| 8 | 803529T06 | PUMP Fuel | 803529T02 | SS |
|
$147.67 | $139.06 | 1 | |
| 9 | 803513 | O-RING | ACT | $4.10 | $4.00 | 1 | |||
| 10 | 8555448 | SCREW (M6 x 30) | ACT | $3.20 | $3.13 | 2 | |||
| 11 | 8M0155131 | ROD Choke | 804646 | SS |
|
$15.70 | $15.31 | 1 | |
| 12 | 8M0047187 | BUSHING | 804647 | SS |
|
$8.01 | $7.81 | 1 | |
| 13 | 16223 | BOLT (M6 x 14) | ACT | $4.20 | $4.10 | 1 | |||
| 14 | 161404 | WASHER | ACT | $4.29 | $4.20 | 1 | |||
| 15 | 953951 | CLAMP | ACT | $9.30 | $9.07 | 1 | |||
| 16 | 8276225 | LINK WIRE Choke | ACT | $21.17 | $20.79 | 1 | |||
| 17 | 16832 | BOLT (M6 x 16) | ACT | $4.50 | $4.39 | 1 | |||
| 18 | 803528 | BRACKET | ACT | $4.60 | $4.49 | 1 | |||
| 19 | 804371001 | COLLAR | 804371 | SS |
|
$3.20 | $3.13 | 1 | |
| 20 | 952868 | COLLAR | ACT | $3.70 | $3.61 | 2 | |||
| 21 | 400212 | NUT (M6) Stainless Steel | ACT | $2.90 | $2.83 | 1 | |||
| 22 | 803526T | SILENCER Air | ACT | $13.70 | $13.36 | 1 | |||
| 23 | 803527 | FLAME ARRESTOR | ACT | $8.80 | $8.59 | 1 | |||
| 24 | 855809003 | BOLT (M6 x 85) | 16329 | SS |
|
$5.20 | $5.08 | 2 | |
| 25 | 16826 | WASHER Stainless Steel | ACT | $3.30 | $3.22 | 2 | |||
| 26 | 95395 | CLIP Stainless Steel | ACT | $3.10 | $3.03 | 4 | |||
| 27 | 8M0057113 | TUBING (170 mm) | 8780541 | SS |
|
$27.75 | $27.25 | 1 | |
| 28 | 8M0157133 | FILTER Fuel | 16248 | SS |
|
$21.49 | $21.07 | 1 | |
| 29 | 878054 | TUBING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 30 | 8M0182334 | CONNECTOR Fuel - Brass | 15781A5 | SS |
|
$31.08 | $30.53 | 1 | |
| 31 | 4000333 | SCREW (M6 x 40) | ACT | $4.10 | $4.00 | 1 | |||
| 32 | 16826 | WASHER Stainless Steel | ACT | $3.30 | $3.22 | 1 | |||
| 33 | 878311 | CAP | ACT | $22.50 | $22.10 | 1 | |||
| - | 8M0114820 | GASKET SET Powerhead | 803508A99 | REP |
|
$116.00 | $109.24 | 1 | |
| - | 803508A05 | GASKET SET Powerhead | ACT |
|
$156.92 | $147.77 | 1 |
