| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 822154A1 | HOUSING ASSEMBLY (SHORT) (BLACK) | ACT | $418.93 | $400.44 | 1 | |||
| 1 | 822155A1 | HOUSING ASSEMBLY (LONG) (BLACK) | ACT | $514.14 | $483.71 | 1 | |||
| 1 | 822154A2 | HOUSING ASSEMBLY (SHORT) (GRAY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 1 | 822155A2 | HOUSING ASSEMBLY (LONG) (GRAY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 195992 | ----GASKET Driveshaft Housing | ACT |
|
$9.70 | $9.46 | 1 | ||
| 3 | 8M0039074 | MOUNT | 421892 | SS |
|
$24.42 | $23.98 | 4 | |
| 4 | 42374F6 | COVER Mount (BLACK) | ACT | $120.17 | $113.17 | 2 | |||
| 4 | 42374F6 | COVER Mount (GRAY) | 42374F5 | REP |
|
$120.17 | $113.17 | 2 | |
| 5 | 4009238 | SCREW (M6 x 80) Mount Cover | ACT | $4.60 | $4.49 | 2 | |||
| 6 | 400256 | LOCKWASHER (M6) | ACT | $1.80 | $1.76 | 2 | |||
| 7 | 400212 | NUT (M6) Stainless Steel Cover Screw | ACT | $2.90 | $2.83 | 2 | |||
| 8 | 445551 | BLOCK Bearing (LONG) | ACT | $7.80 | $7.61 | 1 | |||
| 9 | 4010775 | SCREW (M8 x 75) | ACT | $12.90 | $12.58 | 2 | |||
| 10 | 401386 | NUT (M6) | 400634 | SS |
|
$5.10 | $4.98 | 2 | |
| 11 | 40011131 | SCREW (M6 x 35) Stainless Steel | ACT | $7.59 | $7.42 | 2 | |||
| 12 | 421233 | TUBE Water (SHORT) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 12 | 421222 | TUBE Water (LONG) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 42380001 | SEAL Water Tube | 42380 | SS |
|
$11.50 | $11.22 | 1 | |
| 14 | 8215752 | ADAPTER PLATE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 41670006 | GASKET Adaptor Plate | 416705 | SS |
|
$20.92 | $20.54 | 1 | |
| 16 | 158664 | SEAL Adaptor Plate | ACT | $23.58 | $23.15 | 1 | |||
| 17 | 8221531 | GASKET Exhaust Tube | 822153 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 18 | 822152 | PLATE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | 878608 | SCREW (#10-16 x .500) | 812832 | SS |
|
$1.70 | $1.66 | 3 | |
| 20 | 8240717 | SCREW (M8 x 30) | ACT | $5.20 | $5.08 | 4 | |||
| 21 | 8161949 | STUD (M6 x 1 x 40) | 42984 | SS |
|
$12.20 | $11.90 | 2 | |
| 22 | 8161411 | PLATE Trim Cover | NLA |
|
$0.00 | $0.00 | 2 | ||
| 23 | 821863F2 | TRIM COVER (BLACK) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 23 | 821863F3 | TRIM COVER (GRAY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | 40011130 | SCREW (M6 x 30) Stainless Steel | ACT | $3.20 | $3.13 | 4 | |||
| - | 41670A94 | GASKET SET | NLA |
|
$0.00 | $0.00 | 1 |
