| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 813960A4 | SWITCH ASSEMBLY | ACT |
|
$147.75 | $139.14 | 1 | ||
| 2 | 88075020 | SCREW (M3 x 20) | ACT |
|
$1.50 | $1.47 | 2 | ||
| 3 | 824923 | PLATE | ACT |
|
$9.90 | $9.66 | 1 | ||
| 4 | 12627 | STRAP | ACT |
|
$3.10 | $3.03 | 1 | ||
| 5 | 40011107 | SCREW (M5 x 16) Stainless | ACT |
|
$1.80 | $1.76 | 1 | ||
| 6 | 42161 | LINK INTERLOCK | ACT | $5.30 | $5.17 | 1 | |||
| 7 | 8236103 | LEVER Interlock Control | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 8M0204707 | SCREW (M6 x 25) | 4000330 | SS |
|
$4.00 | $3.91 | 1 | |
| 9 | 69056 | WASHER (.255 x .620 x .030) Stainless Steel | ACT | $1.80 | $1.76 | 1 | |||
| 10 | 823806 | BUSHING | ACT | $17.20 | $16.78 | 1 | |||
| 11 | 823862 | LEVER Backplate | ACT | $14.00 | $13.66 | 1 | |||
| 12 | 8238632 | LEVER Horizontal Shift Shaft Port | ACT | $15.81 | $15.41 | 1 | |||
| 13 | 8236011 | SHIFT SHAFT Horizontal | NLA |
|
$0.00 | $0.00 | 1 | ||
| 14 | 881228A2 | SHIFT LINK ASSEMBLY | ACT |
|
$44.25 | $43.45 | 1 | ||
| 15 | 817428 | ----SOCKET | ACT | $8.20 | $8.00 | 1 | |||
| 16 | 45076 | ----NUT (#10-32) Brass | ACT | $1.80 | $1.76 | 1 | |||
| 17 | 881227A1 | LINK ASSEMBLY Throttle | ACT |
|
$35.17 | $34.54 | 1 | ||
| 18 | 817428 | ----SOCKET | ACT | $8.20 | $8.00 | 2 | |||
| 19 | 45076 | ----NUT (#10-32) Brass | ACT | $1.80 | $1.76 | 1 | |||
| 20 | 8M0204707 | SCREW (M6 x 25) | 4000330 | SS |
|
$4.00 | $3.91 | 1 | |
| 21 | 65567 | WASHER (.265 x .750 x .04 | ACT | $2.90 | $2.83 | 1 | |||
| 22 | 99611 | WAVE WASHER | ACT | $1.90 | $1.86 | 1 | |||
| 23 | 823806 | BUSHING | ACT | $17.20 | $16.78 | 1 | |||
| 24 | 8319781 | CAM Throttle | ACT | $12.60 | $12.29 | 1 | |||
| 25 | 42164 | SPRING | ACT | $2.90 | $2.83 | 1 | |||
| 26 | 888191 | SPARK ARM | ACT | $13.50 | $13.17 | 1 | |||
| 27 | 8327471 | TIMING LINK | ACT | $4.80 | $4.69 | 1 | |||
| 28 | 8238083 | SECONDARY GEAR | ACT | $11.90 | $11.61 | 1 | |||
| 29 | 8238092 | PRIMARY GEAR | ACT | $17.83 | $17.52 | 1 | |||
| 30 | 823806 | BUSHING | ACT | $17.20 | $16.78 | 1 | |||
| 31 | 93008 | BALL | ACT | $1.79 | $1.76 | 1 | |||
| 32 | 8M0215005 | SPRING | 930061 | SS |
|
$3.70 | $3.61 | 1 | |
| 33 | 8M0206596 | SCREW (M6 x 20) | 4000329 | SS |
|
$0.60 | $0.59 | 1 | |
| 34 | 69056 | WASHER (.255 x .620 x .030) Stainless Steel | ACT | $1.80 | $1.76 | 2 | |||
| 35 | 4000331 | SCREW (M6 x 30) | ACT | $3.80 | $3.71 | 1 | |||
| 36 | 69056 | WASHER (.255 x .620 x .030) Stainless Steel | ACT | $1.80 | $1.76 | 1 | |||
| 37 | 823807 | BUSHING | ACT | $11.60 | $11.32 | 1 | |||
| 38 | 8238102 | CONTROL PLATFORM | ACT | $58.17 | $55.95 | 1 | |||
| 39 | 4006731 | SCREW (M6 x 16) | ACT | $2.90 | $2.83 | 3 |
