| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| - | 5321A5 | GEAR HOUSING ASSEMBLY COMPLETE (LEFT HAND ROTATION) | NLA |
|
$0.00 | $0.00 | 1 | ||
| - | 5321A4 | GEAR HOUSING ASSEMBLY COMPLETE (RIGHT HAND ROTATION) | NLA |
|
$0.00 | $0.00 | 1 | ||
| - | 5321A14 | GEAR HOUSING ASSEMBLY COMPLETE (LEFT HAND ROTATION) | NLA |
|
$0.00 | $0.00 | 1 | ||
| - | 5321A13 | GEAR HOUSING ASSEMBLY COMPLETE RIGHT HAND ROTATION) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 1 | 5321A6 | ----GEAR HOUSING ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 8M0041668 | --------STUD (.437-14/.437-20 x 1.875) GEAR HOUSING TO DRIVE SHAFT HOUSING (1 7/8") | 57982 | SS |
|
$15.50 | $15.12 | 1 | |
| 3 | 68290A1 | --------BEARING Roller DRIVE SHAFT | 68290 | SS |
|
$217.08 | $204.43 | 1 | |
| 4 | 79953Q04 | ----SCREW (.375-16) VENT - GEAR HOUSING | 28634 | SS |
|
$7.49 | $7.31 | 1 | |
| 5 | 191833 | ----WASHER SEAL - VENT SCREW | 20260 | SS/NLA |
|
$1.45 | $1.42 | 1 | |
| 6 | 66665 | ----GEAR PINION - MERCRUISER 255 TRS | NLA |
|
$0.00 | $0.00 | 1 | ||
| 6 | 70934T1 | ----GEAR PINION - MERCRUISER 280 TRS | 70934 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 7 | 54048 | ----WASHER PINION GEAR TO DRIVE SHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 55819 | ----NUT PINION GEAR TO DRIVE SHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 9 | 66666 | ----DRIVESHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 10 | 66672A1 | ----SHIM ASSEMBLY ROLLER BEARING TO GEAR HOUSING (.002-3-5-10-20) | NLA |
|
$11.03 | $10.78 | AR | ||
| 11 | 68266A1 | ----BEARING ASSEMBLY Tapered Roller DRIVE SHAFT | ACT | $106.58 | $100.37 | 1 | |||
| 12 | 66670A1 | ----BEARING ASSEMBLY Roller DRIVE SHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 54030 | ----O-RING (2.987 x .103) GEAR HOUSING TO DRIVE SHAFT HOUSING | ACT | $5.90 | $5.76 | 1 | |||
| 14 | 31640Q4 | ----TRIM TAB ASSEMBLY GEAR HOUSING | 31640A1 | SS |
|
$18.49 | $18.17 | 1 | |
| 15 | 41350 | ----SCREW TRIM TAB TO GEAR HOUSING (2 1/2") | 49354 | SS |
|
$27.42 | $26.93 | 1 | |
| 16 | 47397A1 | ----SHIM SET ROLLER BEARING TO GEAR HSG. (.002-3-5-10-20) | ACT |
|
$16.75 | $16.45 | AR | ||
| 17 | 35928T1 | ----BEARING ASSEMBLY Tapered Roller PROPELLER GEAR | 35928A1 | SS |
|
$91.42 | $87.93 | 1 | |
| 18 | 92327T1 | ----PROPELLER SHAFT | 66661 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 19 | 8M0103470 | ----BEARING ASSEMBLY Tapered Roller | 66668A1 | SS |
|
$46.00 | $45.17 | 1 | |
| 16 | 47397A1 | ----SHIM SET ROLLER BEARING TO GEAR HSG. (.002-3-5-10) | ACT |
|
$16.75 | $16.45 | AR | ||
| 17 | 68266A1 | ----BEARING ASSEMBLY Tapered Roller PROPELLER GEAR | ACT |
|
$106.58 | $100.37 | 1 | ||
| 18 | 92328 | ----PROPELLER SHAFT | 66662 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 19 | 35928T1 | ----BEARING ASSEMBLY Tapered Roller | 35928A1 | SS |
|
$91.42 | $87.93 | 1 | |
| 20 | 66664 | ----GEAR DRIVE - MERCRUISER 255 TRS | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | 70933 | ----GEAR DRIVE - MERCRUISER 280 TRS | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 66667 | ----THRUST RING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 22 | 67440T | ----RING LOAD - THRUST RING | 67440 | SS |
|
$41.75 | $41.00 | 1 | |
| 23 | 8M0214920 | ----O-RING BEARING CARRIER TO THRUST RING | 31534 | SS |
|
$6.30 | $6.15 | 1 | |
| 24 | 66663A1 | ----CARRIER ASSEMBLY Bearing | NLA |
|
$0.00 | $0.00 | 1 | ||
| 25 | 30956T | --------BEARING Needle ROLLER - BEARING CARRIER | 30956 | SS |
|
$19.23 | $18.85 | 1 | |
| 26 | 8M0204670 | --------SEAL BEARING CARRIER | 76868 | SS |
|
$19.20 | $18.73 | 2 | |
| 27 | 30281 | ----KEY LOCATING - BEARING CARRIER | ACT | $3.00 | $2.93 | 1 | |||
| 28 | 79447 | ----TAB WASHER GEAR HOUSING COVER | 52833 | SS |
|
$13.70 | $13.36 | 1 | |
| 29 | 8M0168577 | ----COVER GEAR HOUSING | 52834 | SS |
|
$43.15 | $42.23 | 1 | |
| 30 | 56292Q04 | THRUST HUB AND WASHER ASSEMBLY | 56292A1 | SS/NLA |
|
$87.24 | $83.91 | 1 | |
| 31 | 35965 | ----WASHER THRUST - THRUST HUB | NLA |
|
$0.00 | $0.00 | 1 | ||
| 32 | 31211Q03 | ----WASHER THRUST HUB | 31211 | SS |
|
$14.11 | $13.87 | 1 | |
| 33 | 816629Q | TAB WASHER PROPELLER NUT | 31210 | SS |
|
$5.62 | $5.52 | 1 | |
| 34 | 52707Q1 | NUT PROPELLER | 52707 | SS |
|
$15.63 | $15.36 | 1 | |
| 35 | 54029 | O-RING (2.800 x .103) GEAR HOUSING TO DRIVE SHAFT HOUSING | ACT | $4.20 | $4.10 | 1 | |||
| 36 | 47557 | SCREW (.500-13 x 1.500) GEAR HOUSING TO DRIVE SHAFT HOUSING (1 1/2") | NLA |
|
$0.00 | $0.00 | 1 | ||
| 37 | 8M0204653 | NUT (.437-20) Stainless S DRIVE SHAFT HOUSING TO GEAR HOUSING STUD | 34933 | SS |
|
$5.29 | $5.17 | 1 |
