| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 67245T | BRACKET COWL MOUNTING - UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 67272 | GROMMET COWL MOUNTING BRACKET | NLA |
|
$0.00 | $0.00 | 2 | ||
| 3 | 90435 | MOUNT COWL MOUNTING BRACKET BLACK/GRAY | ACT | $60.00 | $57.71 | 2 | |||
| 4 | 8M0204649 | WASHER (.281 x .500 x .06 MOUNT ATTACHING | 29245 | SS |
|
$1.20 | $1.18 | 4 | |
| 5 | 35888 | NUT (.250-28) Stainless S MOUNT ATTACHING | ACT |
|
$6.90 | $6.73 | 4 | ||
| 6 | 87076A4 | IDLE SPEED CONTROL ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 799831 | PLATE CHOKE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 672741 | GASKET CHOKE PLATE TO CARBURETOR | 67274 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 9 | 68000 | SCREW (.250-28 x 1.00) CHOKE PLATE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 6 | ||
| 10 | 20583 | WASHER CHOKE PLATE SCREW | ACT | $1.50 | $1.47 | 6 | |||
| 11 | 672751 | GASKET COVER | 67275 | SS |
|
$15.70 | $15.31 | 1 | |
| 12 | 67246T | COVER INDUCTION SILENCER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 13 | 30720 | SCREW (.250-20 x 2.25) COVER TO CHOKE PLATE | NLA |
|
$8.12 | $7.94 | 2 | ||
| 14 | 8M0204649 | WASHER (.281 x .500 x .06 COVER SCREW | 29245 | SS |
|
$1.20 | $1.18 | 2 | |
| 15 | 26992 | LOCKWASHER (.250) Stainle COVER SCREW | ACT | $1.20 | $1.18 | 2 | |||
| 16 | 90585 | PLUG INDUCTION SILENCER COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 17 | 67760 | LINK Throttle | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 67759 | LEVER Throttle UPPER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | 41049 | LEVER Throttle CENTER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | 67749 | LEVER Throttle LOWER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 15124 | SCREW (#10-32 x .750) THROTTLE LEVERS TO THROTTLE LINK | ACT | $1.10 | $1.08 | 3 | |||
| 22 | 26996 | LOCKWASHER (#10) Stainles THROTTLE LEVERS SCREW | ACT | $1.20 | $1.18 | 3 | |||
| 23 | 8M0204666 | WASHER (.203 x .500 x .03 THROTTLE LEVERS SCREW | 56681 | SS |
|
$1.80 | $1.76 | 3 | |
| 24 | 67297 | PIN Clevis THROTTLE LEVERS TO THROTTLE LINK | ACT | $12.20 | $11.90 | 3 | |||
| 25 | 89302 | WASHER (.203 x .406 x .04 CLEVIS PIN | ACT | $1.80 | $1.76 | 3 | |||
| 26 | 26953 | COTTER PIN CLEVIS PIN | ACT | $4.20 | $4.10 | 3 | |||
| 27 | 67748 | ROLLER LOWER THROTTLE LEVER | ACT | $7.00 | $6.83 | 1 | |||
| 28 | 690201 | SCREW (#10-32 x .875) IDLE SPEED CONTROL | 69020 | SS |
|
$2.90 | $2.83 | 2 | |
| 29 | 38833 | WASHER IDLE SPEED CONTROL SCREW | ACT | $3.80 | $3.71 | 2 | |||
| - | 90484A88 | GASKET SET | NLA |
|
$0.00 | $0.00 |
