| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 87214A1 | COVER ASSEMBLY (SIDE MOUNT ONLY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 21273 | WASHER (SIDE MOUNT ONLY) | ACT | $8.99 | $8.78 | 3 | |||
| 3 | 8267096 | NUT (SIDE MOUNT ONLY) | 34059 | SS |
|
$3.69 | $3.59 | 3 | |
| 3 | 42290 | WELNUT 4 (SIDE MOUNT ONLY) | ACT | $2.29 | $2.25 | ||||
| 4 | 86287 | RETAINER | ACT | $7.13 | $6.98 | 1 | |||
| 5 | 41228 | SCREW (1/2") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 6 | 85867 | COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 41228 | SCREW (1/2") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 8 | 92474A8 | BEARING PLATE ASSEMBLY (USE W/REF #28) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 92474A11 | BEARING PLATE ASSEMBLY (USE W/REF #28A) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 92474A9 | BEARING PLATE ASSEMBLY (175 SKI ONLY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 9 | 19829A1 | THROTTLE LEVER ASSEMBLY (175 SKI ONLY) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 9 | 85875A1 | THROTTLE LEVER ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 10 | NSS | SPRING |
|
$0.00 | $0.00 | 1 | |||
| 11 | 8M0183681 | CLIP ASSEMBLY | 85885A1 | SS |
|
$4.85 | $4.77 | 1 | |
| 12 | 20110 | NUT | ACT | $1.70 | $1.66 | 1 | |||
| 13 | 41228 | SCREW (1/2") | NLA |
|
$0.00 | $0.00 | 3 | ||
| 14 | 24832 | NUT | NLA |
|
$0.00 | $0.00 | 2 | ||
| 15 | 19827A1 | SHIFT LEVER AND PINION ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 16 | 85999 | BUSHING | ACT | $4.74 | $4.65 | 1 | |||
| 17 | 85899A1 | CLIP ASSEMBLY | ACT | $4.74 | $4.65 | 1 | |||
| 18 | 20110 | NUT | ACT | $1.70 | $1.66 | 1 | |||
| 19 | NSS | PIN |
|
$0.00 | $0.00 | 1 | |||
| 20 | 85877 | STEP WASHER | ACT | $3.24 | $3.18 | 1 | |||
| 21 | 85870 | GEAR | ACT | $13.30 | $13.06 | 1 | |||
| 21 | 858701 | GEAR (175 SKI) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 22 | NSS | BALL |
|
$0.00 | $0.00 | 1 | |||
| 23 | NSS | PIN |
|
$0.00 | $0.00 | 1 | |||
| 24 | NSS | PLUG |
|
$0.00 | $0.00 | 1 | |||
| 25 | NSS | SPRING |
|
$0.00 | $0.00 | 1 | |||
| 26 | 25184 | RETAINING RING | NLA |
|
$0.00 | $0.00 | 2 | ||
| 27 | 817253A1 | SHAFT (USE W/REF #28) | 42651A1 | SS |
|
$13.54 | $13.35 | 1 | |
| 27 | 817253A1 | SHAFT (USE W/REF #28A) | ACT | $13.54 | $13.35 | 1 | |||
| 28 | 85872 | BUSHING | ACT | $2.40 | $2.36 | 1 | |||
| 28 | 74647 | BUSHING | ACT | $2.29 | $2.25 | 1 | |||
| 29 | 85879 | GROMMET | ACT | $3.15 | $3.09 | 2 | |||
| 30 | 95700 | SCREW (1/2") | 70332 | SS |
|
$6.63 | $6.52 | 3 | |
| 31 | NSS | BALL |
|
$0.00 | $0.00 | 1 | |||
| 32 | NSS | FOLLOWER |
|
$0.00 | $0.00 | 1 | |||
| 33 | NSS | SPRING (INNER) |
|
$0.00 | $0.00 | 1 | |||
| 34 | 85886 | CLIP | NLA |
|
$0.00 | $0.00 | 1 | ||
| 35 | 86025 | SCREW (5/8") | NLA |
|
$0.00 | $0.00 | 1 | ||
| 36 | NSS | SPRING |
|
$0.00 | $0.00 | 1 | |||
| 37 | NSS | PAD |
|
$0.00 | $0.00 | 1 | |||
| 38 | 86245 | SET SCREW (PLASTIC) | NLA |
|
$0.00 | $0.00 | 2 | ||
| 39 | 86087 | SCREW (3-1/2") | NLA |
|
$0.00 | $0.00 | 3 | ||
| 40 | NSS | SPRING (OUTER) |
|
$0.00 | $0.00 | 1 | |||
| 41 | 86288 | COVER | ACT | $7.76 | $7.62 | 1 | |||
| - | 85882A1 | REPAIR KIT | NLA |
|
$0.00 | $0.00 | 1 |
