| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 62092T | FUEL PUMP ASSEMBLEY | 54552 | SS |
|
$0.00 | $0.00 | 1 | |
| 1 | 62092T | FUEL PUMP ASSEMBLEY | 62092 | SS |
|
$0.00 | $0.00 | 1 | |
| 2 | 56882 | SCREW, FUEL PUMP TO CYLINDER BLOCK (1 1/2") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 3 | 34213 | GASKET, FUEL PUMP | 56883 | SS |
|
$7.09 | $6.93 | 1 | |
| 4 | 32876 | NIPPLE, SIGHT GLASS TO FUEL PUMP | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5 | 39072A1 | SIGHT GLASS | 47816 | SS |
|
$0.00 | $0.00 | 1 | |
| 6 | 47721 | FUEL LINE, FUEL TANK TO FUEL FILTER (12") | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 33755 | ELBOW, FUEL LINE TO FUEL FILTER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 807172 | FUEL FILTER | 60494 | SS |
|
$0.00 | $0.00 | 1 | |
| 9 | 89876A3 | BASE, FUEL FILTER | 55481 | SS |
|
$67.49 | $64.77 | 1 | |
| 10 | 36382 | PLUG, PIPE - FUEL FILTER | ACT | $5.49 | $5.37 | 2 | |||
| 11 | 77453 | BRACKET, MOUNTING - FUEL FILTER | 54646 | SS |
|
$0.00 | $0.00 | 1 | |
| 12 | 20639 | SCREW, FUEL FILTER TO MOUNTING BRACKET (1/2") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 13 | 20084 | WASHER, FUEL FILTER SCREW | ACT | $2.97 | $2.92 | 2 | |||
| 14 | 82670911 | NUT, FUEL FILTER SCREW | 35814 | SS |
|
$4.99 | $4.88 | 2 | |
| 15 | 47716 | ELBOW, FUEL LINE TO FUEL PUMP AND FUEL FILTER | NLA |
|
$0.00 | $0.00 | 3 | ||
| 16 | 54551 | FUEL LINE, FUEL FILTER TO FUEL PUMP (STEEL TUBING) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 17 | 55242 | FUEL LINE, FUEL PUMP TO CARBURETOR (STEEL TUBING) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 33821 | ELBOW, FUEL LINE TO FUEL PUMP AND FUEL FILTER | ACT |
|
$9.69 | $9.46 | 3 | ||
| 16 | 62373T | FUEL LINE, FUEL FILTER TO FUEL PUMP (STEEL TUBING) | 62373 | SS |
|
$0.00 | $0.00 | 1 | |
| 17 | 64977 | FUEL LINE, FUEL PUMP TO CARB. (STEEL TUBING) | 62400 | SS |
|
$0.00 | $0.00 | 1 | |
| 17 | 64977 | FUEL LINE, FUEL PUMP TO CARB. (STEEL TUBING) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 60102 | BRACKET, MOUNTING - THROTTLE CABLE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | 35897 | STUD, THROTTLE CABLE TO MOUNTING BRACKET (11/16") | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | 69056 | WASHER, THROTTLE CABLE STUD | 21631 | SS |
|
$1.80 | $1.76 | 2 | |
| 21 | 31866 | SPACER, THROTTLE CABLE STUD | ACT | $5.69 | $5.56 | 1 | |||
| 22 | 8267089 | NUT, THROTTLE CABLE STUD | 20361 | SS |
|
$1.50 | $1.47 | 1 | |
| 23 | 5659A2 | CARBURETOR ASSEMBLY | 4642 | SS |
|
$0.00 | $0.00 | 1 | |
| 24 | 58264 | STUD, CARBURETOR TO INTAKE MANIFOLD (2 1/2") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 24 | 26324 | STUD, CARBURETOR TO INTAKE MANIFOLD (3 1/4") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 25 | 20084 | WASHER, CARBURETOR STUD | ACT |
|
$2.97 | $2.92 | 4 | ||
| 26 | 862902 | NUT, CARBURETOR STUD | 25594 | SS |
|
$2.39 | $2.33 | 4 | |
| 24 | 63004 | STUD, CARBURETOR TO INTAKE MANIFOLD (2 5/8") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 24 | 26324 | STUD, CARBURETOR TO INTAKE MANIFOLD (3 1/4") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 24 | 63004 | STUD, CARBURETOR MOUNTING - FRONT (2 5/8") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 24 | 64943 | STUD, CARBURETOR MOUNTING - REAR (2 7/8") | NLA |
|
$0.00 | $0.00 | 2 | ||
| 25 | 20084 | WASHER, CARBURETOR STUD S | ACT |
|
$2.97 | $2.92 | 4 | ||
| 26 | 862902 | NUT, CARBURETOR STUD | 25594 | SS |
|
$2.39 | $2.33 | 1 | |
| 26 | 29250 | NUT, CARBURETOR STUD | 46793 | SS |
|
$2.89 | $2.82 | 3 | |
| 27 | 60716 | SPACER, CARBURETOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 28 | 60715 | GASKET, CARBURETOR | NLA |
|
$31.04 | $30.48 | 3 | ||
| 29 | 87419 | HOSE, CARBURETOR | 54681 | SS |
|
$0.00 | $0.00 | 1 | |
| 30 | 815504310 | CLAMP, HOSE ATTACHING | 32523 | SS |
|
$17.99 | $17.56 | 2 | |
| 31 | 56863 | VALVE, HOSE TO ROCKER COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 32 | 56877 | GROMMET, ROCKER COVER TO HOSE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 33 | 79661 | STUD, FLAME ARRESTOR MOUNTING - CARBURETOR | 47360 | SS |
|
$0.00 | $0.00 | 1 | |
| 34 | 8267139 | NUT, JAM - FLAME ARRESTOR MOUNTING STUD (BOTTOM) | 28941 | SS |
|
$2.59 | $2.53 | 1 | |
| 35 | 55054 | FLAME ARRESTOR, CARBURETOR (NOT AS SHOWN) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 36 | 22937 | WASHER, FLAME ARRESTOR STUD | ACT | $3.79 | $3.69 | 1 | |||
| 37 | 826709109 | NUT, FLAME ARRESTOR STUD | 20586 | SS |
|
$3.59 | $3.50 | 1 | |
| 38 | 37892 | SCREW, THROTTLE CABLE TO CARBURETOR (1") | NLA |
|
$1.32 | $1.29 | 1 | ||
| 39 | 26907 | WASHER, THROTTLE CABLE SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 40 | 847883 | WASHER, THROTTLE CABLE SCREW | 20128 | SS |
|
$5.20 | $5.08 | 2 | |
| 41 | 57938 | BUSHING, THROTTLE CABLE SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 42 | 859124 | NUT, THROTTLE CABLE SCREW | 45812 | SS |
|
$18.69 | $18.33 | 1 | |
| 43 | 63421A1 | BAFFLE, CARBURETOR | NLA |
|
$0.00 | $0.00 | 1 |
