| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 806235A1 | HOUSING ASSEMBLY, Thermostat | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 8M0180565 | --PLUG, Pipe (.375-18) Brass | 32803 | SS |
|
$7.99 | $7.81 | 2 | |
| 3 | 8M0204687 | --GASKET, Thermostat | 806871 | SS |
|
$10.19 | $9.95 | 1 | |
| 4 | 530451 | GASKET, Thermostat Housing | ACT | $5.69 | $5.56 | 1 | |||
| 5 | 8M0109441 | THERMOSTAT, 71°C (160°F) | 8072522 | SS |
|
$34.49 | $33.72 | 1 | |
| 6 | 8M0214947 | SLEEVE | 806922 | SS |
|
$17.89 | $17.46 | 1 | |
| 7 | 8M0113180 | SCREW, (.375-16 x 1.00) | 98794 | SS |
|
$5.09 | $4.98 | 2 | |
| 8 | 807407 | HOSE, Thermostat Housing to Engine Oil Cooler | ACT | $27.29 | $26.76 | 1 | |||
| 9 | 807405 | HOSE, Engine Oil Cooler to P/S Oil Cooler | 808052 | SS |
|
$32.09 | $31.51 | 1 | |
| 10 | 807404 | HOSE | ACT | $63.99 | $60.21 | 1 | |||
| 11 | 8M0062666 | HOSE, (96.00 Inches Bulk), Seawater Pump to Drive Unit | 1743579 | SS |
|
$220.99 | $199.09 | 1 | |
| 12 | 8M0188622 | CLAMP, Worm Gear (1.98 DIameter) | 815504222 | SS |
|
$5.69 | $5.56 | 8 | |
| 13 | 897181 | HOSE, Thermostat Housing to Water Pump | ACT | $78.99 | $74.09 | 1 | |||
| 14 | 815504232 | CLAMP, Worm Gear (2.50 Diameter) | ACT | $8.89 | $8.68 | 2 | |||
| 15 | 897491 | HOSE, Thermostat Housing to Port Exhaust Manifold | ACT | $70.49 | $66.16 | 1 | |||
| 16 | 807201 | HOSE, Thermostat Housing to Starboard Exhaust Manifold | ACT | $58.49 | $54.94 | 1 | |||
| 17 | 815504220 | CLAMP, Worm Gear | ACT | $7.59 | $7.42 | 4 | |||
| 18 | 806616 | CLAMP | ACT | $3.09 | $3.01 | 1 | |||
| 19 | 77054 | TIE STRAP, (14.50 Inches) | ACT | $1.70 | $1.66 | 1 | |||
| 20 | 8M0181740 | COOLER ASSEMBLY, Power Steering Oil | 99356A2 | SS |
|
$565.99 | $515.14 | 1 | |
| 21 | 807402T | BRACKET, Oil Cooler | NLA |
|
$0.00 | $0.00 | 1 | ||
| 22 | 807445T | CLAMP | ACT | $21.89 | $21.44 | 1 | |||
| 23 | 35462 | WASHER, (.2656 x .625 x .0625) Stainless Steel | ACT | $1.80 | $1.76 | 1 | |||
| 24 | 8267088 | NUT, (.250-20) | 72008 | SS |
|
$1.70 | $1.66 | 1 | |
| 25 | 86750 | SCREW, (.312-18 x .620) | ACT | $1.00 | $0.98 | 1 | |||
| 26 | 39107 | LOCKWASHER, (.312-24) | ACT | $1.50 | $1.47 | 1 | |||
| - | 805396A95 | GASKET SET, Overhaul | NLA |
|
$0.00 | $0.00 | 1 |
