Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 98423A14 HARNESS ASSEMBLY NLA $0.00 $0.00 1
1 98423A13 HARNESS ASSEMBLY NLA $0.00 $0.00 1
1 98423A18 HARNESS ASSEMBLY NLA $0.00 $0.00 1
1 98423A15 HARNESS ASSEMBLY NLA $0.00 $0.00 1
2 26079A2 PLATE 26079 SS $29.99 $29.38 1
3 34696 SCREW, (#8-32 x .750) NLA $0.00 $0.00 4
2 26079A2 PLATE KIT, Wire Harness Mount ACT $29.99 $29.38 1
3 15001 --SCREW, (#8-16 x .875) ACT $3.29 $3.21 4
4 98493A2 BRACKET NLA $0.00 $0.00 1
5 65746 SCREW, (.250-20 x .750) ACT $1.10 $1.08 3
7 15899A1 IGNITION AMPLIFIER NLA $0.00 $0.00 1
7 15899A1 IGNITION MODULE ASSEMBLY 814295A1 SS $0.00 $0.00 1
7 821125T02 IGNITION MODULE 821125A1 NLA $0.00 $0.00 1
7 15899A1 IGNITION MODULE ASSEMBLY 814295A1 SS $0.00 $0.00 1
7 821125T02 IGNITION MODULE 821125A1 NLA $0.00 $0.00 1
7 15899A1 IGNITION MODULE ASSEMBLY 814295A1 SS $0.00 $0.00 1
7 821125T02 IGNITION MODULE 821125A1 NLA $0.00 $0.00 1
8 15275A1 --HARNESS ASSEMBLY NLA $0.00 $0.00 1
9 8M0214943 SCREW, (.250-20 x 1.00) 76630 SS $1.80 $1.76 3
10 26992 LOCKWASHER, (.250) Stainless Steel ACT $1.20 $1.18 3
10A 64015 NUT, (.250-20) ACT $2.79 $2.72 6
11 92152T SPACER, (.27 x .75 x .38) 92152 SS $6.89 $6.73 3
12 97258A1 SENDER ASSEMBLY (1/2-14) ACT $57.99 $54.62 1
12 806490T SENDER ASSEMBLY, Water Temperature (3/8-18) 97257A1 SS $41.49 $40.58 1
12 49734 SENDER ASSEMBLY, Water Temperature (DUAL) 49734A1 SS $90.49 $85.15 OPT.
13 8M0068784 SENDER ASSEMBLY, Oil Pressure 815425 SS $133.49 $120.13 1
13 37293T SENDER ASSEMBLY, Oil Pressure (DUAL) 37293 SS $205.99 $185.41 OPT.
14 26996 --LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 2
15 68219 --NUT, (#10-32) Stainless Steel ACT $2.99 $2.92 2
16 46932 ELBOW NLA $0.00 $0.00 1
17 885153 NIPPLE 42554 SS $23.59 $23.16 1
18 41170T BRACKET NLA $0.00 $0.00 1
19 37612 SCREW, (.375-16 x 1.250) ACT $2.49 $2.43 1
20 35048 LOCKWASHER, (.375) ACT $1.20 $1.18 2
21 78945 J CLAMP, Harness Support ACT $5.19 $5.08 1
22 26486 SCREW, (.375-16 x 2.375) ACT $3.79 $3.69 1
24 15895 SPACER, (.38 x 1.00 x 1.44) NLA $0.00 $0.00 1
24 91034 SPACER, (.380 x 1.00 x .530) ACT $23.29 $22.83 1
25 11178A01 BREAKER, Circuit - 50 Ampere 11178 SS $121.49 $109.31 1
26 26996 LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 2
27 68219 NUT, (#10-32) Stainless Steel ACT $2.99 $2.92 2
28 45862 SCREW, (#10-32 x .875) ACT $1.40 $1.37 2
29 45218 SCREW, (#10-32 x .380) NLA $0.73 $0.72 1
30 8M0204666 WASHER, (.203 x .500 x .032) 56681 SS $1.80 $1.76 2
31 46438 NUT, (#10-32) ACT $5.79 $5.66
32 96819T INSULATOR NLA $0.00 $0.00 1
33 8M0185149 SOLENOID ASSEMBLY, Starter 96054 SS $38.99 $38.14 1
34 96138 SCREW, (1/4-28 x 5/8) (5/8 IN.) 47910 SS $0.00 $0.00 2
35 20088 NUT NLA $0.00 $0.00 2
36 26992 LOCKWASHER, (.250) Stainless Steel ACT $1.20 $1.18 2
37 26419 NUT, (#8-32) Brass ACT $1.70 $1.66 2
39 45915 TERMINAL BLOCK ACT $0.90 $0.88 1
40 62568 SCREW, (#10-16 x .375) ACT $1.10 $1.08 1
41 22028 SCREW, (#10-32 x .50) NLA $0.88 $0.86 1
42 46438 NUT, (#10-32) ACT $5.79 $5.66 1
43 95084A9 CABLE ASSEMBLY, (91.00 Inches) Red/Purple Strip ACT $30.49 $29.95 1
44 8M0207796 FUSE, 20 Ampere 79091 SS $9.09 $8.88 1
45 8M0207788 CABLE ASSEMBLY, (5.00 Inches) Red 95084A10 SS $9.49 $9.27 1
- 11149A5 HARNESS ASSEMBLY, Adapter (USED TO ADAPT RING TERMINAL & BULLET CONNECTOR WIRING HARNESS NLA $0.00 $0.00 1
