Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 8M0185794 MANIFOLD ASSEMBLY, Exhaust 864308T01 SS $534.99 $503.13 2
2 8M0204679 --FITTING, Pipe - Brass (.750-14) 428611 SS $10.99 $10.73 4
3 390721 --PLUG, Pipe (.125-27) Brass ACT $9.29 $9.07 2
4 864689 --PLUG, Expansion, Expansion ACT $2.79 $2.72 3
5 33395 --GASKET, Manifold ACT $14.19 $13.85 2
6 8M0214937 SCREW, (.375-16 x 4.75) 53728 SS $5.09 $4.98 8
7 866725 FITTING, (.750-14) 863804 SS $18.29 $17.85 2
8 863786A1 FITTING ASSEMBLY, Drain ACT $53.49 $51.22 2
9 864701 --O-RING, (1.112 x .103) 47632 SS $3.59 $3.50 1
10 863129 --BALL, Check ACT $2.79 $2.72 1
11 862994T --FITTING ACT $9.49 $9.27 1
12 864850A02 GASKET, Elbow, Resitrictor 864850A1 SS $67.99 $65.37 2
12 864549A02 GASKET, Elbow, Block Off 864549A1 SS $56.49 $54.25 2
13 864309T02 ELBOW ASSEMBLY, Exhaust 864309T01 SS $414.99 $396.55 2
14 864689 --PLUG, Expansion, Expansion ACT $2.79 $2.72 3
15 8M0180564 --PLUG, (.250-18) 73379 SS $7.59 $7.42 1
16 8M0204679 --FITTING, Pipe - Brass (.750-14) 428611 SS $10.99 $10.73 2
17 866725 FITTING, (.750-14) 863804 SS $18.29 $17.85 1
17 865159 FITTING, (45 Degree) 92499T SS $25.39 $24.88 1
18 43749 SCREW, (.375-16 x 5.750), Exhaust Elbow ACT $5.89 $5.76 8
20 864306A3 RISER EXTENSION KIT, 3 Inch Cold Riser ACT $869.99 $818.43 1
20 864929A1 RISER EXTENSION KIT, 3 Inch Warm Riser ACT $1,012.99 $928.25 1
20 864306A2 RISER EXTENSION KIT, 3 Inch Cold Riser ACT $714.99 $672.34 1
20 864929A2 RISER EXTENSION KIT, 3 Inch Warm Riser ACT $763.99 $718.51 1
21 864850A02 --GASKET, Restrictor 864850A1 SS $67.99 $65.37 2
21 864549A02 --GASKET, Block Off 864549A1 SS $56.49 $54.25 2
21 864547A02 GASKET, Full Flow 864547A1 SS $66.99 $64.40 2
22 8M0204679 --FITTING, Pipe - Brass (.750-14) 428611 SS $10.99 $10.73 2
23 864378 --SCREW, (.250-20 x .375) Torx ACT $2.29 $2.24 1
25 863714T01 --BRACKET 863714T SS $28.99 $28.48 1
26 34714 --WASHER ACT $2.39 $2.33 8
27 860008 --SCREW, (.250-20 x .625) Torx ACT $3.19 $3.11 1
28 864908A07 RISER EXTENSION KIT, 6 Inch Cold Riser 864307A3 SS $0.00 $0.00 1
28 864908A1 RISER EXTENSION KIT, 6 Inch Warm Riser ACT $931.49 $876.36 1
28 864908A06 RISER EXTENSION KIT, 6 Inch Cold Riser 864307A2 SS $0.00 $0.00 1
28 864908A2 RISER EXTENSION KIT, 6 Inch Warm Riser ACT $885.49 $833.02 1
29 864850A02 --GASKET, Restrictor 864850A1 SS $67.99 $65.37 2
29 864549A02 --GASKET, Block Off 864549A1 SS $56.49 $54.25 2
29 864547A02 GASKET, Full Flow 864547A1 SS $66.99 $64.40 2
30 8M0204679 --FITTING, Pipe - Brass (.750-14) 428611 SS $10.99 $10.73 2
31 863715T01 --BRACKET ACT $35.49 $34.70 2
32 865982005 --SCREW, (.375-16 x 1.00) 12244 SS $2.59 $2.53 8
33 860008 --SCREW, (.250-20 x .625) Torx ACT $3.19 $3.11 6
34 864378 --SCREW, (.250-20 x .375) Torx ACT $2.29 $2.24 1
35 866725 FITTING, (.750-14) 863804 SS $18.29 $17.85 2
36 384071 PLUG, Pipe (.500) 37372 SS $14.99 $14.63 2
36 12524 PLUG, (.375-18 x .475) Brass ACT $5.09 $4.98 2
37 16604 FITTING, Straight (.125-27) ACT $11.49 $11.22 1
- 861246A05 GASKET SET, Engine Overhaul 861246A98 SS $826.99 $777.78 1
