| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 87290A4 | HOUSING ASSEMBLY, Thermostat | ACT |
|
$547.49 | $498.48 | 1 | ||
| 2 | 47511 | --SLEEVE | ACT | $43.99 | $43.13 | 1 | |||
| 3 | 8M0180565 | --PLUG, Pipe (.375-18) Brass | 32803 | SS |
|
$7.99 | $7.81 | 2 | |
| 4 | 530451 | GASKET | ACT | $5.69 | $5.56 | 1 | |||
| 5 | 8M0089715 | THERMOSTAT (140 DEGREES) | 8072521 | SS |
|
$27.69 | $27.17 | 1 | |
| 6 | 47510 | GASKET | ACT | $3.39 | $3.30 | 1 | |||
| 7 | 47508T | SLEEVE | 47508 | SS |
|
$17.49 | $17.11 | 1 | |
| 8 | 41812 | GASKET | ACT | $9.49 | $9.27 | 1 | |||
| 10 | 47441A1 | COVER | ACT | $99.49 | $93.63 | 1 | |||
| 11 | 48130 | SCREW, (.375-16 x 4.500) | NLA |
|
$0.00 | $0.00 | 2 | ||
| 12 | 35048 | LOCKWASHER, (.375) | ACT | $1.20 | $1.18 | 2 | |||
| 13 | 98477A2 | VALVE ASSEMBLY | ACT | $108.99 | $97.97 | 1 | |||
| 14 | 8M0062614 | HOSE, (48.00 Inches Bulk) | 3322070 | SS |
|
$71.49 | $67.31 | 2 | |
| 15 | 815504220 | CLAMP, Worm Gear | ACT | $7.59 | $7.42 | AR | |||
| 16 | 160211 | HOSE (PORT) | ACT | $40.99 | $40.25 | 1 | |||
| 17 | 871171 | HOSE (STARBOARD) | ACT | $44.49 | $43.54 | 1 | |||
| 18 | 47715 | CLIP | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | 88794 | HOSE | ACT | $38.99 | $38.19 | 1 | |||
| 20 | 96246A4 | HOSE | ACT | $73.99 | $69.46 | 1 | |||
| 21 | 815504220 | CLAMP, Worm Gear | ACT | $7.59 | $7.42 | 4 | |||
| 22 | 8M0181740 | COOLER ASSEMBLY | 99356A2 | SS |
|
$565.99 | $515.14 | 1 | |
| 24 | 56328A1 | BRACKET (SHORT) | ACT |
|
$24.29 | $23.82 | 1 | ||
| 25 | 63820F3 | BRACKET (LONG) | 638203 | SS |
|
$25.09 | $24.63 | 1 | |
| 26 | 60300 | SCREW, (.250-28 x .750) | ACT |
|
$4.99 | $4.88 | 2 | ||
| 27 | 30506 | NUT, (.250-28) | ACT |
|
$3.19 | $3.11 | 2 | ||
| 28 | 65970T1 | BRACKET | ACT |
|
$17.89 | $17.46 | 1 | ||
| 29 | 41408 | SCREW, (#10-32 x 1.50) | ACT |
|
$3.39 | $3.30 | 1 | ||
| 30 | 861590A05 | HOSE | 806825 | SS |
|
$65.99 | $61.84 | 1 | |
| 31 | 815504232 | CLAMP, Worm Gear (2.50 Diameter) | ACT | $8.89 | $8.68 | 2 | |||
| 32 | 12552 | LIFTING EYE | ACT | $19.89 | $19.41 | 1 |
