| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0097162 | BRACKET KIT, Shift | ACT |
|
$93.49 | $89.69 | 1 | ||
| 2 | 865149A02 | --STUD, With Cotter Pin | ACT | $10.69 | $10.44 | 1 | |||
| 3 | 865433A02 | LEVER ASSEMBLY, Actuator, With Cotter Pin | ACT | $39.99 | $39.26 | 1 | |||
| 4 | 864907T | SPRING | ACT | $5.49 | $5.37 | 1 | |||
| 5 | 8M0207774 | SHOULDER SCREW, (.312-18 x 1.843) Stainless Steel | 865148 | SS |
|
$10.69 | $10.44 | 1 | |
| 6 | 8M0214922 | COTTER PIN | 328571 | SS |
|
$3.79 | $3.69 | 2 | |
| 7 | 8M0207784 | SPRING | 98880 | SS |
|
$8.29 | $8.10 | 2 | |
| 8 | 56720 | WASHER, (.330 x .750 x .060) Stainless Steel | ACT | $1.80 | $1.76 | 2 | |||
| 9 | 35462 | WASHER, (.2656 x .625 x .0625) Stainless Steel | ACT | $1.80 | $1.76 | 2 | |||
| 10 | 210711 | COTTER PIN | ACT | $3.69 | $3.59 | 3 | |||
| 11 | 8M0078904 | LEVER ASSEMBLY, Shift | ACT | $17.49 | $17.07 | 1 | |||
| 12 | 35462 | WASHER, (.2656 x .625 x .0625) Stainless Steel | ACT | $1.80 | $1.76 | 3 | |||
| 13 | 865393A02 | STUD KIT, (.250-28 x 1.90), With Cotter Pin | ACT | $8.39 | $8.20 | 1 | |||
| 14 | 63341 | TEE NUT | ACT | $2.79 | $2.72 | 1 | |||
| 15 | 814001 | PIN, Clevis | ACT | $13.89 | $13.56 | 1 | |||
| 16 | 210711 | COTTER PIN | ACT | $3.69 | $3.59 | 1 | |||
| 17 | 8M0207774 | SHOULDER SCREW, (.312-18 x 1.843) Stainless Steel | 865148 | SS |
|
$10.69 | $10.44 | 1 | |
| 18 | 808009T10 | SWITCH ASSEMBLY, Shift Interupt | ACT | $89.99 | $86.49 | 1 | |||
| 19 | 865147T01 | SCREW, (#6-32 x .750) Stainless Steel | 865147 | SS |
|
$2.39 | $2.33 | 2 | |
| 20 | 8M0095577 | SWITCH ASSEMBLY, Neutral | ACT | $44.99 | $44.19 | 1 | |||
| 21 | 865147T01 | SCREW, (#6-32 x .750) Stainless Steel | 865147 | SS |
|
$2.39 | $2.33 | 2 | |
| 22 | 813995A1 | GUIDE ASSEMBLY, Spring | ACT | $46.99 | $45.99 | 1 | |||
| 23 | 657461 | SCREW AND LOCKWASHER, (.250-20 x .625) | ACT | $1.70 | $1.66 | 3 | |||
| 24 | 8M0101621 | THROTTLE ARM ASSEMBLY | ACT | $34.99 | $34.36 | 1 | |||
| 25 | 8M0072630 | SPRING | ACT | $5.39 | $5.27 | 1 | |||
| 26 | 865154A02 | STUD KIT, (.250-20/.250-28 x 2.120) (Included in Bracket Kit) | ACT | $11.89 | $11.61 | 1 | |||
| 27 | 8M0095576 | HARNESS ASSEMBLY, Demand Sensor | ACT | $135.99 | $127.76 | 1 | |||
| 28 | 89302 | WASHER, (.203 x .406 x .040) | ACT | $1.80 | $1.76 | 2 | |||
| 29 | 852368 | SCREW, (#10-24 x .750) | ACT | $1.70 | $1.66 | 2 |
