| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 99510A13 | HARNESS ASSEMBLY | ACT | $432.49 | $413.41 | 1 | |||
| 2 | 26079A2 | PLATE KIT, Wire Harness Mount | ACT |
|
$29.99 | $29.38 | 1 | ||
| 3 | 15001 | --SCREW, (#8-16 x .875) | ACT | $3.29 | $3.21 | 4 | |||
| 4 | 98493A2 | BRACKET | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5 | 65746 | SCREW, (.250-20 x .750) | ACT | $1.10 | $1.08 | 3 | |||
| 6 | 806490T | SENDER ASSEMBLY, Water Temperature | 97257A1 | SS |
|
$41.49 | $40.58 | 1 | |
| 6 | 49734 | SENDER ASSEMBLY, Water Temperature (DUAL) | 49734A1 | SS |
|
$90.49 | $86.97 | OPT | |
| 7 | 8M0068784 | SENDER, Oil Pressure | 90806 | SS |
|
$133.49 | $125.49 | 1 | |
| 7 | 37293T | SENDER ASSEMBLY, Oil Pressure (DUAL) | 37293 | SS |
|
$205.99 | $193.68 | OPT | |
| 8 | 26996 | --LOCKWASHER, (#10) Stainless Steel | ACT | $1.20 | $1.18 | 2 | |||
| 9 | 68219 | --NUT, (#10-32) Stainless Steel | ACT | $2.99 | $2.92 | 2 | |||
| 10 | 46932 | ELBOW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 11 | 885153 | NIPPLE | 42554 | SS |
|
$23.59 | $23.16 | 1 | |
| 12 | 8M0210755 | SWITCH, Oil Pressure | 805024 | SS |
|
$58.99 | $56.75 | 1 | |
| 13 | 18021 | FITTING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 14 | 41170T | BRACKET | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 98261 | SCREW, (.375-16 x .750) | ACT | $1.20 | $1.18 | 1 | |||
| 16 | 35048 | LOCKWASHER, (.375) | ACT | $1.20 | $1.18 | 1 | |||
| 17 | 37612 | SCREW, (.375-16 x 1.250) | ACT | $2.49 | $2.43 | 1 | |||
| 18 | 35048 | LOCKWASHER, (.375) | ACT | $1.20 | $1.18 | 1 | |||
| 19 | 20572 | WASHER, (.390 x .750 x .093) | ACT | $1.60 | $1.57 | 1 | |||
| 20 | 57369 | SPACER | ACT | $19.79 | $19.40 | 1 | |||
| 21 | 11178A01 | BREAKER, Circuit - 50 Ampere | 11178 | SS |
|
$121.49 | $114.19 | 1 | |
| 22 | 26996 | LOCKWASHER, (#10) Stainless Steel | ACT | $1.20 | $1.18 | 2 | |||
| 23 | 68219 | NUT, (#10-32) Stainless Steel | ACT | $2.99 | $2.92 | 2 | |||
| 24 | 45862 | SCREW, (#10-32 x .875) | ACT | $1.40 | $1.37 | 2 | |||
| 25 | 71405 | SCREW, (#10-32 x .440) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 26 | 8M0204666 | WASHER, (.203 x .500 x .032) | 56681 | SS |
|
$1.80 | $1.76 | 2 | |
| 27 | 61356 | NUT, (#10-32) Reduced Hex | ACT | $3.29 | $3.21 | 3 | |||
| 28 | 96819T | INSULATOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 29 | 8M0185149 | SOLENOID ASSEMBLY, Starter | 96054 | SS |
|
$38.99 | $38.14 | 1 | |
| 30 | 96138 | SCREW, (1/4-28 x 5/8) (5/8") | 47910 | SS |
|
$0.00 | $0.00 | 2 | |
| 31 | 20088 | NUT | NLA |
|
$0.00 | $0.00 | 2 | ||
| 32 | 26992 | LOCKWASHER, (.250) Stainless Steel | ACT | $1.20 | $1.18 | 2 | |||
| 33 | 26419 | NUT, (#8-32) Brass | ACT | $1.70 | $1.66 | 2 | |||
| 34 | 94330 | NUT, (.250-20) Brass | ACT | $1.70 | $1.66 | 2 | |||
| 35 | 15247A1 | IGNITION AMPLIFIER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 36 | 15275A1 | --HARNESS ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 37 | 8M0214943 | SCREW, (.250-20 x 1.00) | 76630 | SS |
|
$1.80 | $1.76 | 3 | |
| 38 | 26992 | LOCKWASHER, (.250) Stainless Steel | ACT | $1.20 | $1.18 | 3 | |||
| 39 | 92152T | SPACER, (.27 x .75 x .38) | 92152 | SS |
|
$6.89 | $6.73 | 3 |
