| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 847722A2 | HARNESS ASSEMBLY-Wiring | 847722A1 | SS |
|
$612.11 | $575.71 | 1 | |
| 2 | 26079A2 | PLATE KIT | ACT |
|
$29.99 | $29.38 | 1 | ||
| 3 | 15001 | --SCREW (#8-16 x .875) | ACT | $3.29 | $3.21 | 4 | |||
| 4 | 8476761 | BRACKET- Mount (.375 Holes) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 4 | 8481311 | BRACKET- Mount (.437 Holes) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5 | 11178A01 | BREAKER-Circuit (50 AMP) | 11178 | SS |
|
$121.49 | $114.19 | 1 | |
| 6 | 26996 | LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 2 | |||
| 7 | 68219 | NUT (#10-32) | ACT | $2.99 | $2.92 | 2 | |||
| 8 | 45862 | SCREW (#10-32 x .875) | ACT | $1.40 | $1.37 | 2 | |||
| 9 | 61356 | NUT (#10-32) | ACT | $3.29 | $3.21 | 2 | |||
| 10 | 818999A2 | SOLENOID ASSEMBLY-Starter | ACT |
|
$65.49 | $62.68 | 1 | ||
| 11 | 818967 | --GROMMET | ACT | $3.19 | $3.11 | 2 | |||
| 12 | 8M0214955 | --BUSHING | 818968 | SS |
|
$2.89 | $2.82 | 2 | |
| 13 | 8M0204649 | WASHER | 29245 | SS |
|
$1.20 | $1.18 | 2 | |
| 14 | 26992 | LOCKWASHER (.250) | ACT | $1.20 | $1.18 | 2 | |||
| 15 | 8M0214943 | SCREW (.250-20 x 1.00) | 76630 | SS |
|
$1.80 | $1.76 | 2 | |
| 16 | 26995 | LOCKWASHER (#8) | ACT | $1.10 | $1.08 | 2 | |||
| 17 | 26419 | NUT (#8-32) | ACT | $1.70 | $1.66 | 2 | |||
| 18 | 26992 | LOCKWASHER (.250) | ACT | $1.20 | $1.18 | 2 | |||
| 19 | 94330 | NUT (.250-20) | ACT | $1.70 | $1.66 | 2 | |||
| 20 | 13611 | SENDER UNIT-Oil Temperature | ACT |
|
$95.69 | $92.88 | 1 | ||
| 21 | 26996 | --LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 1 | |||
| 22 | 45076 | --NUT (#10-32) | ACT | $1.80 | $1.76 | 1 | |||
| 23 | 36492 | REDUCER | ACT | $24.49 | $23.98 | 1 | |||
| 24 | 806490T | SENDER ASSEMBLY-Water Temperature | 97257A1 | SS |
|
$41.49 | $40.58 | 1 | |
| 24 | 49734 | SENDER ASSEMBLY-Water Temperature (Dual) | 49734A1 | SS |
|
$90.49 | $86.97 | OPT | |
| 25 | 26996 | --LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 1 | |||
| 26 | 45076 | --NUT (#10-32) | ACT | $1.80 | $1.76 | 1 | |||
| 27 | 8M0068784 | SENDER ASSEMBLY-Oil Pressure | 815425 | SS |
|
$133.49 | $125.49 | 1 | |
| 27 | 37293T | SENDER ASSEMBLY-Oil Pressure (Dual) | 37293 | SS |
|
$205.99 | $193.68 | OPT | |
| 28 | 26996 | --LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 1 | |||
| 29 | 45076 | --NUT (#10-32) | ACT | $1.80 | $1.76 | 1 | |||
| 30 | 64013 | REDUCER | ACT | $14.69 | $14.34 | 1 | |||
| 31 | 42600A09 | CONTROLLER ASSEMBLY | 42600A3 | SS |
|
$164.99 | $154.99 | 1 | |
| 32 | 30164 | WASHER | ACT | $2.49 | $2.43 | 2 | |||
| 33 | 26996 | LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 7 | |||
| 34 | 41771 | SCREW (#10-24 x .875) | ACT | $0.70 | $0.69 | 2 | |||
| 35 | 62568 | SCREW (#10-16 x .375) | ACT | $1.10 | $1.08 | 1 | |||
| 36 | 68219 | NUT (#10-32) | ACT | $2.99 | $2.92 | 4 | |||
| 37 | 86322A17 | CABLE ASSEMBLY (Black) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 38 | 15899A1 | IGNITION MODULE ASSEMBLY | 814295A1 | SS |
|
$0.00 | $0.00 | 1 | |
| 39 | 8M0204649 | WASHER | 29245 | SS |
|
$1.20 | $1.18 | 2 | |
| 40 | 8267098 | NUT (.250-20) | 56374 | SS |
|
$6.89 | $6.73 | 3 | |
| 41 | 62826T06 | CABLE ASSEMBLY (Black) | 62826A6 | SS |
|
$16.99 | $16.62 | 1 | |
| 42 | 21272 | LOCKWASHER (.250 Internal) | ACT | $1.10 | $1.08 | 1 | |||
| 43 | 823755T1 | OVERSPEED ASSEMBLY | 823755A1 | SS |
|
$0.00 | $0.00 | 1 | |
| 44 | 30164 | WASHER | ACT | $2.49 | $2.43 | 2 | |||
| 45 | 26996 | LOCKWASHER (#10) | ACT | $1.20 | $1.18 | 2 | |||
| 46 | 41069 | SCREW (#10-24 x .750) | ACT | $1.99 | $1.95 | 2 | |||
| 47 | 847738 | STUD-Electrical Bracket Mount | NLA |
|
$0.00 | $0.00 | 3 | ||
| 48 | 35048 | LOCKWASHER (.375) | ACT | $1.20 | $1.18 | 3 | |||
| 48 | 32993 | LOCKWASHER (.437) | ACT | $1.70 | $1.66 | 3 | |||
| 49 | 37612 | SCREW (.375-16 x 1.250)-Bracket Mount | ACT | $2.49 | $2.43 | 3 | |||
| 49 | 47462 | SCREW (.437-14 x 1.250)-Bracket Mount | ACT | $1.80 | $1.76 | 3 | |||
| 50 | 848183 | J CLIP-Electrical Harness | ACT | $18.69 | $18.24 | 1 |
