Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 842054 BRACKET, Electrical Mounting ACT $243.50 $225.36 1
2 8M0185146 SOLENOID ASSEMBLY 850187T1 SS $62.49 $58.63 1
3 818967 --GROMMET ACT $3.19 $3.11 1
4 8M0214955 --BUSHING 818968 SS $2.89 $2.82 1
5 26992 LOCKWASHER, (.250) Stainless Steel ACT $1.20 $1.18 2
6 94330 NUT, (.250-20) Brass ACT $1.70 $1.66 2
7 8M0207773 RELAY ASSEMBLY 882751A1 SS $22.69 $22.26 4
8 828102 --BRACKET, Relay Mounting SS $0.00 $0.00 4
9 818967 --GROMMET ACT $3.19 $3.11 4
10 8M0214955 --BUSHING 818968 SS $2.89 $2.82 4
11 846673 WASHER, (.265 x .500 x .060) Stainless Steel ACT $1.10 $1.08 2
12 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 2
13 26995 LOCKWASHER, (#8) Stainless Steel ACT $1.10 $1.08 2
14 26419 NUT, (#8-32) Brass ACT $1.70 $1.66 2
15 880786 BOOT, Insulator - Red ACT $3.09 $3.01 1
16 880787 BOOT, Insulator - Yellow ACT $1.90 $1.86 1
17 816311T TIE STRAP, (8.00 Inches) ACT $0.60 $0.59 AR
18 95084A10 CABLE ASSEMBLY, (5.00 Inches) Red SS $9.49 $9.27 1
19 8M0207796 FUSE, 20 Ampere 79091 SS $9.09 $8.88 1
20 95084A9 CABLE ASSEMBLY, (91.00 Inches) Red/Purple Strip ACT $30.49 $29.95 1
21 86606 --BOOT, Insulator - Black ACT $1.50 $1.47 1
22 89919 BOOT, Insulator - Black ACT $2.49 $2.43 2
23 61356 NUT, (#10-32) Reduced Hex ACT $3.29 $3.21 2
24 8M0204718 NUT, (#10-32) Stainless Steel 826709106 SS $4.69 $4.59 2
25 11178A01 BREAKER, Circuit - 50 Ampere 11178 SS $121.49 $109.31 1
26 842103 BRACKET, Circuit Breaker Mounting ACT $38.52 $37.98 1
27 817505 SCREW, (.250-20 x .620) Stainless Steel ACT $2.89 $2.82 1
28 879962 CLIP, Fuse Cover Holder ACT $1.99 $1.95 2
29 18124 SCREW, (#10-32 x .750) NLA $0.00 $0.00 2
30 72554 DECAL, Circuit Breaker ACT $1.00 $0.98 1
31 8M0046836 PCM, Propulsion Control Module 840947T11 SS $3,453.04 $3,091.79 1
31 8M0046836 PCM, Propulsion Control Module 840947T13 SS $3,453.04 $3,091.79 1
32 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 3
33 65567 WASHER, (.265 x .750 x .048) Stainless Steel ACT $2.89 $2.82 3
34 8M0190980 GROMMET 834985 SS $3.89 $3.79 3
35 856954 BUSHING ACT $6.99 $6.83 3
36 858951 J CLIP ACT $6.79 $6.64 1
37 826709108 NUT, (.250-20) Stainless Steel ACT $0.90 $0.88 6
38 42600A09 MERCATHODE ASSEMBLY ACT $164.99 $148.38 1
39 26996 LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 1
40 62568 SCREW, (#10-16 x .375) ACT $1.10 $1.08 1
41 65208 BOOT, Insulator - Black NLA $0.00 $0.00 3
42 865181T01 HARNESS ASSEMBLY, Mercathode ACT $43.49 $42.55 1
43 8M0062940 SEAL, 6 Inches ACT $22.72 $22.40 1
44 8M0133358 STUD, (.437-14/.437-20 x 2.060) 579203 SS $17.29 $16.94 1
44 57984 STUD, (.437-14/.437-20 x 2.380) ACT $19.49 $19.07 1
45 45176 WASHER, (.453 x .812 x .105) Stainless Steel ACT $1.50 $1.47 2
46 859135 NUT, (.437-20) Brass/Nickel Plated ACT $6.09 $5.95 2
47 8M0000179 LABEL SET, Electrical Components ACT $13.12 $12.94 1
48 8M0114747 SPARK PLUG 810883 SS $8.89 $8.68 8
49 843075A09 CABLE SET, Ignition, Set Of Eight ACT $107.85 $99.81 1
50 843137A01 --MARKER SET, Ignition Cables, Two Per - Numbers 1 Thru 8 ACT $32.36 $31.89 1
51 54676 RETAINER, Two Wire ACT $5.19 $5.08 2
52 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 2
53 846673 WASHER, (.265 x .500 x .060) Stainless Steel ACT $1.10 $1.08 2
54 8M0053613 RETAINER, Ignition Cable Support 844367 SS $44.28 $43.65 1
55 841203T COIL, Ignition ACT $363.49 $336.32 2
56 8M0204718 NUT, (#10-32) Stainless Steel 826709106 SS $4.69 $4.59 6
57 858951 J CLIP ACT $6.79 $6.64 1
58 879962 CLIP, Wire Harness Support ACT $1.99 $1.95 2
- 843073A06 GASKET/SEAL SET, Engine Overhaul ACT $1,787.87 $1,600.83 1
- 841178A05 PARTIAL ENGINE ASSEMBLY NLA $0.00 $0.00 1
