Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
- 8866A80 GEAR HOUSING ASSEMBLY, (17/18) (1.26:1 Ratio) NLA $0.00 $0.00 1
- 8866A81 GEAR HOUSING ASSEMBLY, (15/17) (1.35:1 Ratio) NLA $0.00 $0.00 1
- 8866A61 GEAR HOUSING ASSEMBLY, (15/19) (1.50:1 Ratio) NLA $0.00 $0.00 1
- 8866A82 GEAR HOUSING ASSEMBLY, (17/18) (1.26:1 Ratio) ACT $7,368.57 $6,754.92 1
- 8866A83 GEAR HOUSING ASSEMBLY, (15/17) (1.35:1 Ratio) ACT $7,368.57 $6,754.92 1
- 8866A62 GEAR HOUSING ASSEMBLY, (15/19) (1.50:1 Ratio) ACT $7,368.57 $6,754.92 1
1 8866A64 --GEAR HOUSING ASSEMBLY 8866A17 SS $3,636.93 $3,334.05 1
1 8866A54 --GEAR HOUSING ASSEMBLY NLA $0.00 $0.00 1
1 8866A64 --GEAR HOUSING ASSEMBLY ACT $3,636.93 $3,334.05 1
2 8M0133358 ----STUD, (.437-14/.437-20 x 2.060) 579203 SS $17.29 $16.94 2
3 8M0214925 ----O-RING 33465 SS $5.29 $5.17 1
4 8M0204680 ----SEAL 455771 SS $4.29 $4.20 1
5 805344 ----SEAL, (.625 Outside Diameter) ACT $4.19 $4.10 1
6 86754T ----BEARING ASSEMBLY, Roller ACT $81.99 $78.55 1
7 76214Q5 ----ANODE KIT ACT $29.99 $29.38 1
8 806210 ----LOCKWASHER, (.437) ACT $1.80 $1.76 1
9 8M0204686 ----SCREW, (.437-14 x 1.750) 806327 SS $6.99 $6.83 1
10 92914A1 --SHIM KIT ACT $48.49 $47.57 AR
11 8M0103470 --BEARING ASSEMBLY, Tapered Roller 66668A1 SS $45.99 $45.17 1
12 858517A3 --DRIVESHAFT ASSEMBLY, (16.085 Long) ACT $792.99 $745.66 1
13 815901 ----RACE, Bearing ACT $63.49 $61.08 1
14 8M0103473 --BEARING ASSEMBLY, Tapered Roller 86748A1 SS $53.99 $51.83 1
15 86739 --TAB WASHER ACT $18.19 $17.75 1
16 86749A1 --SHIM KIT ACT $45.99 $45.09 AR
17 8M0240070 --SPACER 92916 SS $21.99 $21.57 1
18 20826 --O-RING, (2.230 x .139) ACT $5.29 $5.17 1
19 88243A3 --COUPLING ASSEMBLY ACT $116.49 $109.71 1
20 88242 ----RING, Retaining ACT $1.10 $1.08 1
21 818928A2 --GEAR SET, (15/19) ACT $1,063.49 $974.54 1
21 8M0104360 --GEAR SET, (15/17) 840872A1 SS $1,670.99 $1,531.65 1
21 8M0104359 --GEAR SET, (17/18) 840870A1 SS $1,395.49 $1,279.03 1
22 805068 --WASHER ACT $17.69 $17.26 1
23 808027 --SCREW ACT $5.39 $5.27 1
24 87157A1 --SHIM KIT ACT $64.99 $62.55 AR
25 8M0103471 --BEARING ASSEMBLY, Tapered Roller 86752A1 SS $70.99 $68.21 1
26 840377T --PROPELLER SHAFT ACT $1,185.99 $1,086.97 1
27 8M0103476 --BEARING ASSEMBLY, Tapered Roller 812767A1 SS $52.99 $50.74 1
28 67440T --LOAD RING ACT $41.99 $41.24 1
29 42256 --THRUST WASHER, (.105 Inch Thick) ACT $33.99 $33.25 1
30 840372A2 --CARRIER ASSEMBLY, Bearing ACT $546.54 $514.03 1
31 8M0214920 ----O-RING 31534 SS $6.29 $6.15 1
32 815565 ----SEAL, Oil ACT $35.99 $35.27 2
33 8M0058389 PLUG KIT, Drain - Magnetic 67892A06 SS $11.69 $11.41 1
34 8M0204693 SEAL, Sealing 830749 SS $5.19 $5.08 1
35 806188Q01 ----ANODE ASSEMBLY 806188A1 SS $36.99 $36.34 1
36 806290 ------SCREW, (#10-32 x .625) ACT $1.20 $1.18 2
37 69432 ------LOCKWASHER, External (#10) ACT $1.00 $0.98 2
38 18323 --TAB WASHER, Keyed ACT $24.89 $24.39 1
39 8M0168577 --RETAINER, Bearing Carrier 79448 SS $43.49 $42.72 1
40 8M0183487 HUB ASSEMBLY, Propeller 840389A5 SS $205.54 $195.97 1
41 NSS --NOT SOLD SEPARATE, HUB-Propeller $0.00 $0.00 1
42 840383A2 --WASHER/NUT KIT 840383A1 SS $53.29 $51.64 1
43 52707Q1 ----PROP NUT KIT, (.750-16) ACT $16.41 $16.12 1
44 840382A02 --SNUBBER STRIP KIT 840382A1 SS $24.36 $23.99 1
45 90084 SCREW, (.437-14 x 1.500) ACT $4.59 $4.49 1
46 861854 WASHER, (.453 x .750 x .032) Stainless Steel ACT $4.19 $4.10 2
47 8M0143423 NUT, (.437-20) 35053 SS $9.49 $9.27 2
- 815565A02 SEAL KIT, Gear Housing 815565A1 SS $84.99 $81.76 AR
- 888758Q02 ANODE KIT, Aluminum 888758A1 SS $96.99 $93.30 AR
- 888757Q02 ANODE KIT, Magnesium 888757A1 SS $137.99 $129.72 AR
