Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 87956R1 CYLINDER BLOCK ASSEMBLY 2281 SS $0.00 $0.00 1
1 87956R1 CYLINDER BLOCK ASSEMBLY 3548 NLA $0.00 $0.00 1
2 34270 --PLUG,EXPANSION-CYLINDER BLOCK(1 5/8" DIA.) ACT $9.79 $9.56 2
2 34271 --PLUG,EXPANSION-CYLINDER BLOCK(2"DIA) ACT $22.49 $22.02 1
2 37531 --PLUG,OIL CHANNEL-CYLINDER BLOCK NLA $0.00 $0.00 1
3 72640 --PLUG,EXPANSION-CAMSHAFT BEARING HOLE 34488 NLA $14.19 $13.85 1
4 8M0204657 --PLUG,PIPE-CYLINDER BLOCK(3/8") 34487 SS $5.69 $5.56 1
5 36382 --PLUG,WATER DRAIN-CYLINDER BLOCK ACT $5.49 $5.37 1
6 35465 ,PIN,DOWEL-CYLINDER BLOCK TO CYLINDER HEAD ACT $6.99 $6.83 2
7 35168 ,BEARING,DISTRIBUTOR PILOT SHAFT NLA $0.00 $0.00 1
8 2343 --PISTON AND PISTON PIN ASSEMBLY(STANDARD) 2278 SS $0.00 $0.00 4
8 2343 --PISTON AND PISTON PIN ASSEMBLY(.001O.S.) NLA $0.00 $0.00 AR
8 2343 ,PISTON AN DPISTON PIN ASSEMBLY(.002O.S.) 2231 SS $0.00 $0.00 AR
8 2279 --PISTONAND PISTON PIN ASSEMBLY(.020O.S.) 2274 SS $0.00 $0.00 AR
8 2279 PISTON AND PISTON PIN ASSEMBLY(.030O.S.) NLA $0.00 $0.00 AR
9 67132 --RING,PISTON(STANDARD) 67119 SS $0.00 $0.00 4
9 67120 --RING,PISTON(.020O.S) NLA $0.00 $0.00 AR
9 67134 --RING,PISTON(.030O.S.) 67121 SS $0.00 $0.00 AR
10 85720T BEARING UNIT,CAMSHAFT(FRONT AND INTERMEDIATE 52483 NLA $0.00 $0.00 2
11 85720T --BEARING UNIT,CAMSHAFT(REAR) 52482 SS $0.00 $0.00 1
12 818469001 --BEARING UNIT,CRANKSHAFT MAIN(STANDARD) 49959 SS $256.49 $231.16 4
12 818470001 --BEARING UNIT,CRANKSHAFT MAIN(.001 U.S.) 49960 SS $0.00 $0.00 AR
12 52258 --BEARING UNIT,CRANKSHAFT MAIN(.002U.S.) 49961 SS $0.00 $0.00 AR
12 818471001 --BEARING UNIT,CRANKSHAFT MAIKN(.010U.S.) 49962 SS $205.49 $184.89 AR
13 818469001 --BEARING UNIT,CRANKSHAFT MAIN-REAR(STANDARD) 34464 SS $256.49 $231.16 1
13 818470001 --BEARING UNIT,CRAKSHAFT MAIN-REAR(.001U.S.) 34490 SS $0.00 $0.00 AR
13 85671 --BEARING UNIT,CRANKSHAFT MAIN-REAR(.002U.S.) 34491 SS $0.00 $0.00 AR
13 85672 --BEARING UNIT,CRANKSHAFT MAIN-REAR(.010U.S.) 34492 SS $0.00 $0.00 AR
13 85673 --BEARING UNIT,CRANKSHAFT MAIN-REAR(.020U.S.) 34493 SS $0.00 $0.00 AR
14 34498 --------REAR-CRANKSHAFT BEARING NLA $0.00 $0.00 1
14 49954 CAP,REAR-CRANKSHAFT BEARING NLA $0.00 $0.00 1
15 35310 --CAP,INTERMEDIATE AND FRONT-CRANKSHAFT BEARING NLA $0.00 $0.00 4
- 34533 --SHIM UNIT,BEARING CAP-FRONT AND INTERMEDIATE NLA $0.00 $0.00 AR
- 34534 --SHIM UNIT ,BEARING CAP-REAR NLA $0.00 $0.00 AR
16 34499 --BOLT,CRANKSHAFT BEARING CAP TO CYLINDER BLOCK(2 23/32") NLA $0.00 $0.00 10
16 46717 --BOLT,CRANKSHAFT BEARING CAP CYLINDER BLOCK (2 31/32") NLA $0.00 $0.00 10
17 34462 --OIL SEAL UNIT,CRANKSHAFT REAR BEARING NLA $0.00 $0.00 1
17 814622 --OIL SEAL UNTI,CRANKSHAFT REAR BEARING 49947 SS $132.49 $119.08 1
17 814622 --OIL SEAL UNIT,CRANKSHAFT REAR BEARING 58203 SS $132.49 $119.08 1
- 34543 --VALVE,BY PASS-OIL FILTER ACT $18.19 $17.75 1
18 2282 FLYWHEEL,CRANKSHAFT NLA $0.00 $0.00 1
19 98532A1 STUD,FLYWHEEL TO ENGINE COUPLING 32808 SS $19.09 $18.63 6
20 76850A2 ENGINE COUPLING ASSEMBLY 38965A1 SS $438.99 $406.34 1
21 8M0204655 WASHER,FLYWHEEL STUD 35935 SS $2.69 $2.62 6
22 8M0204653 NUT,FLYWHEEL STUD 34933 SS $5.29 $5.17 6
23 2277 CONNECTING ROD ASSEMBLY NLA $0.00 $0.00 4
24 75539 --BOLT,CONNECTING ROD BEARING CAP 34473 SS $0.00 $0.00 8
25 58099 --NUT,CONNECTING ROD CAP BOLT 34474 SS $0.00 $0.00 8
26 85677 EARING(PAIR),CONNECTING ROD (STANDARD) 52242 SS $17.29 $16.94 4
26 85678 BEARING(PAIR),CONNECTING ROD (.001U.S.) 52243 SS $0.00 $0.00 AR
26 85679 BEARING(PAIR),CONNECTING ROD (.002 U.S) 52244 SS $0.00 $0.00 AR
26 85680 BEARING (PAIR),CONNECTING ROD (.010U.S) 52245 SS $0.00 $0.00 AR
26 85681 BEARING(PAIR),CONNECTING ROD (.020U.S.) 52246 SS $0.00 $0.00 AR
27 2422 CAMSHAFT ACT $294.99 $265.57 1
28 8M0160608 LIFTER,HYDRAULIC-TAPPET 35583 SS $38.49 $37.62 8
28 8M0160608 LIFTER,HYDRAULIC-TAPPET 46472 SS $38.49 $37.62 8
29 8M0113733 WATER PUMP ASSEMBLY(SPECIAL MARINE) 37369 SS $158.49 $142.67 1
29 8M0113733 WATER PUMP ASSEMBLY(SPECIAL MARINE) 52353 SS $158.49 $142.67 1
30 879150138 --GASKET,WATER PUMP 33956 NLA $9.69 $9.46 1
31 8M0149724 SCREW,WATER PUMP TO CYLINDER BLOCK(1 1/2") 34471 SS $34.49 $33.80 2
32 8M0043993 SCREW,WATER PUMP TO CYLINDER BLOCK(3/4") 35339 SS $1.70 $1.66 1
32 34505 SCREW,WATER PUMP TO CYLINDER BLOCK(7/8") ACT $19.89 $19.41 1
33 34481 HUB,WATER PUMP PULLEY NLA $0.00 $0.00 1
33 37242 REINFORCEMENT,WATER PUMP PULLEY NLA $0.00 $0.00 1
33 47282 SUPPORT,WATER PUMP PULLEY NLA $0.00 $0.00 1
34 33864 PULLEY,WATER PUMP NLA $0.00 $0.00 1
34 52349 PULLEY,WATER PUMP NLA $0.00 $0.00 1
35 47277 SCREW,PULLEY AND HUB TO WATER PUMP(3/4") ACT $1.20 $1.18 4
36 39107 LOCKWASHER,PULLEY AND HUB SCREW ACT $1.50 $1.47 4
37 46471 NOZZLE,OIL-TIMING GEAR 34535 SS $0.00 $0.00 1
37 46471 NOZZLE,OIL-TIMING GEAR NLA $0.00 $0.00 1
38 34469 BEARING,CMASHAFT THRUST ACT $45.99 $45.09 1
39 34467 GEAR,TIMING(FIBER) NLA $0.00 $0.00 1
39 8M0171097 GEAR,TIMING(FIBER) 58283 SS $245.49 $221.17 1
40 21417A1 SCREW,TIMING GEAR TO CAMSHAFT(1/4") NLA $0.00 $0.00 2
41 64032Q1 BELT,ALTERNATOR,WATER PULLEY AND CRANKSHAFT PULLEY 32850 SS $27.69 $27.17 1
42 2275 CRANKSHAFT NLA $0.00 $0.00 1
43 34466 KEY,PULLEY AND GEAR LOCATING ACT $3.69 $3.59 2
44 8M0171097 GEAR,CRANKSHAFT9SERIAL#3253905 AND BELOW)(SERIAL #3331604 TH 46743 NLA $245.49 $221.17 1
44 8M0171097 GEAR,CRANKSHAFT(SERIAL #3253906 THRU#3331603)(SERIAL#3331897 46743 NLA $245.49 $221.17 1
45 34220 HUB,PULLEY-CRANKSHAFT NLA $0.00 $0.00 1
46 35602 PULLEY,CRANKSHAFT NLA $0.00 $0.00 1
47 34276 SCR EW,PULLEY TO CRANKCASE HUB(9/16") 1 NLA $0.00 $0.00
47 34276 SCREW,PULLEY TO CRANKCASE HUB(3/8") NLA $0.00 $0.00 2
- 34550 CLIP,FUEL FEED PIPE NLA $0.00 $0.00 1
