Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 60187A1 GIMBAL HOUSING ASSEMBLY (STANDARD) 45514A1 SS $0.00 $0.00 1
1 60188A1 GIMBAL HOUSING ASSEMBLY (POWER TILT) 45637A1 SS $0.00 $0.00 1
1 60189A1 GIMBAL HOUSING ASSEMBLY (POWER TRIM) 45702A1 SS $0.00 $0.00 1
2 56296 --STUD, GIMBAL HOUSING TO TRANSON PLATE (4 3/4") 37270 SS $0.00 $0.00 2
3 32536 --BEARING, ROLLER - GIMBAL HOUSING (LOWER) ACT $5.98 $5.84 1
4 32911 --OIL SEAL, LOWER GIMBAL HOUSING ROLLER BEARING ACT $15.59 $15.22 2
5 38634 --BUSHING, SYNTHANE - GIMBAL HOUSING (UPPER) NLA $0.00 $0.00 1
6 32540 --OIL SEAL, UPPER GIMBAL HOUSING BUSHING NLA $0.00 $0.00 1
7 390721 --PLUG, PIPE - GIMBAL HOUSING 21290 SS $9.29 $9.07 1
8 8M0169589 --FITTING, GREASE - GIMBAL HOUSING 31345 SS $4.79 $4.69 1
9 77633Q --LUBRICAP, GIMBAL HOUSING GREASE FITTING 29359 SS $6.99 $6.83 1
10 88416 --SEAL, GREASE - GIMBAL HOUSING 36143 SS $0.00 $0.00 1
11 35130 --ADAPTOR, BEARING CARRIER NLA $0.00 $0.00 1
12 36418 --BEARING, BALL - GIMBAL HOUSING NLA $174.99 $157.69 1
13 35128 --RING, RETAINING - BEARING CARRIER (LARGE) ACT $20.69 $20.30 1
14 35244A1 --SHIM, GIMBAL HOUSING BEARING (.002-3-4-5-6-7-8-10) NLA $0.00 $0.00 AR
15 25612 --SCREW, DRIVE-GIMBAL HOUSING EXHAUST FLANGE NLA $0.00 $0.00 13
16 20863 --"O" RING, GIMBAL HOUSING ACT $4.59 $4.49 1
-- 1368211 --EMBLEM, GIMBAL HOUSING 46443 SS $0.00 $0.00 1
17 34762A1 PLATE ASSEMBLY, INHIBITOR - GIMBAL HOUSING ACT $25.39 $24.88 1
18 34763 --SCREW, INDIBITOR PLATE TO GIMBAL HOUSING (3/4") ACT $7.79 $7.61 2
19 8M0073409 PIN, SWIVEL - GIMBAL HOUSING TO GIMBAL RING (LOWER) 45212 ACT $59.99 $57.55 1
20 54929 COTTER PIN, RETAINING - LOWER SWIVEL PIN 34159 SS $7.89 $7.71 1
21 32518 WASHER, GIMBAL HOUSING TO LOWER SWIVEL ACT $3.79 $3.69 1
22 43691 BOLT, GIMBAL HOUSING TO TRANSOM PLATE (4") 35624 SS $17.49 $17.07 2
23 32620 WASHER, GIMBAL HOUSING BOLT ACT $1.50 $1.47 2
24 74639A2 BELLOWS, SHIFT ACTUATING CABLE 31659 SS $34.99 $34.29 1
25 8M0204733 CLAMP,ACTUATING CABLE BELLOWS TO SHIFT ACTUATING CABLE 38863 SS $7.49 $7.32 1
26 8M0204716 CLAMP, SHIFT ACTUATING CABLE BELLOWS TO GIMBAL HOUSING 31766 SS $11.49 $11.22 1
27 22248 WASHER, GIMBAL HOUSING STUD ACT $1.50 $1.47 2
28 8M0204653 NUT, GIMBAL HOUSING STUD 34933 SS $5.29 $5.17 2
29 8M0171251 TUBE, WATER - GIMBAL HOUSING 32631 SS $44.99 $44.12 1
30 28055 BUSHING, RUBBER - WATER TUBE SEALING NLA $0.00 $0.00 1
31 32517 COVER, WATER TUBE SEALING BUSHING - GIMBAL HOUSING NLA $0.00 $0.00 1
32 28635 SCREW, WATER TUBE SEALING COVER TO GIMBAL HOUSING (5/8") ACT $1.80 $1.76 2
33 53272A5 ELBOW ASSEMBLY, EXHAUST (MERCRUISER 120 AND 160 - EARLY MODE 45530A2 SS $0.00 $0.00 1
33 53272A5 ELBOW ASSEMBLY, EXHAUST (MERCRUISER 120 AND 160 - LATER MODE 53272A1 SS $0.00 $0.00 1
33 53113A7 ELBOW ASSEMBLY, EXHAUST (MERCRUISER 140) 53113A2 SS $0.00 $0.00 1
34 45798 --BRACKET,SUPPORT - WATER SHUTTER NLA $0.00 $0.00 (1) 2
35 37655 --SCREW, SUPPORT BRACKET TO EXHAUST ELBOW (1/2") 45813 SS $1.80 $1.76 (2) 4
36 859124 --NUT, SUPPORT BRACKET SCREW 45812 SS $18.69 $18.33 (2) 4
37 60410 SCREW, EXHAUST ELBOW TO GIMBAL HOUSING (4 1/4") 33389 SS $5.89 $5.76 1
38 37612 SCREW, EXHAUST ELBOW TO GIMBAL HOUSING (1 1/4") 26632 SS $2.49 $2.43 2
38 35787 SCREW, EXHAUST ELBOW TO GIMBAL HOUSING (2 1/4") ACT $2.79 $2.72 3
39 35048 LOCKWASHER, EXHAUST ELBOW SCREW ACT $1.20 $1.18 3
40 70974 GASKET, GIMBAL HOUSING TO TRANSOM 45832 SS $54.49 $52.26 1
41 45586 SHUTTER, WATER - EXHAUST ELBOW ACT $51.49 $49.54 1
42 45597A1 BELLOWS, EXHAUST ELBOW TO ENGINE (MERCRUISER 120 AND 160) 45597 SS $106.99 $100.69 1
42 53114A1 BELLOWS, EXHAUST ELBOW TO ENGINE (MERCRUISER 140) 53114 SS $77.99 $74.95 1
43 815504352 CLAMP, BELLOWS TO EXHAUST ELBOW AND ENGINE 32739 SS $20.79 $20.38 4
