| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 3310-8M0047212 | CARBURETOR | 806969A1 | SS/ACT |
 |
$1,653.07 | $1,515.41 | 1 | |
| 1 | 3310-806755A2 | CARBURETOR | SS |
|
$0.00 | $0.00 | 1 | ||
| 2 | 24-897454 | SPRING, Throttle Return | 32817 | SS/ACT |
|
$11.80 | $11.51 | 1 | |
| 3 | 10-35386 | SCREW, (.312-18 x 1.00) | ACT | $1.10 | $1.08 | 2 | |||
| 4 | 13-39107 | LOCKWASHER, (.312-24) | ACT | $1.40 | $1.37 | 2 | |||
| 5 | 16-70237 | STUD, (.312-18/.312-24 x 2.620) | ACT | $4.00 | $3.91 | 2/4 | |||
| 6 | 805359T | BRACKET | ACT | $68.17 | $65.57 | 1 | |||
| 7 | 16-818192 | STUD, Anchor | ACT | $19.75 | $19.40 | 1 | |||
| 8 | 12-24664 | WASHER, (M4 x 20) | ACT | $1.30 | $1.27 | 2 | |||
| 9 | 11-826709109 | NUT, (.250-28) | 35045 | SS/ACT |
|
$3.50 | $3.42 | 2 | |
| 10 | 16-8M0113178 | STUD, (.250-28 x 2.00), Throttle Cable Anchor | 96112 | SS/ACT |
|
$3.00 | $2.93 | 1 | |
| 11 | 12-8M0204649 | WASHER, (.281 x .500 x .060) Stainless Steel | ACT | $1.20 | $1.18 | 2 | |||
| 12 | 11-8267089 | NUT, (.250-28) | 20361 | SS/ACT |
|
$1.40 | $1.37 | 1 | |
| 13 | 11-826709109 | NUT, (.250-28) | 35045 | SS/ACT |
|
$3.50 | $3.42 | 1 | |
| 14 | 12-20084 | WASHER, (.328 x .562 x .062) | ACT | $2.83 | $2.77 | 2 | |||
| 15 | 11-29250 | NUT, (.312-24) | ACT | $2.80 | $2.74 | 2/4 | |||
| 16 | 889338A1 | SPACER | SS |
|
$0.00 | $0.00 | 1 | ||
| 17 | 27-41609 | --GASKET | ACT |
|
$17.80 | $17.36 | 1 | ||
| 18 | 27-41610 | --GASKET | ACT |
|
$18.50 | $18.04 | 1 | ||
| 19 | 806177A3 | SPACER | SS |
|
$0.00 | $0.00 | 1 | ||
| 20 | 25-806237 | --QUAD RING | ACT |
|
$9.30 | $9.07 | 2 | ||
| 21 | 10-54523 | --SCREW, (.312-18 x 1.00) | ACT |
|
$0.40 | $0.40 | 4 | ||
| 22 | 18484A3 | COVER | SS |
|
$0.00 | $0.00 | 1 | ||
| 23 | 37-812776A43 | DECAL SET | SS |
|
$0.00 | $0.00 | 1 | ||
| 23 | 37-812776A44 | DECAL SET | SS |
|
$0.00 | $0.00 | 1 | ||
| 24 | 16-805296 | STUD, (4.50 Inch) | ACT |
|
$49.08 | $48.20 | 1 | ||
| 25 | 805298A1 | --FLAME ARRESTOR | ACT |
|
$204.67 | $192.74 | 1 | ||
| 26 | 805314 | --RETAINER, Breather Hose | ACT |
|
$6.40 | $6.25 | 1 | ||
| 24 | 16-805297 | STUD | ACT |
|
$9.90 | $9.66 | 1 | ||
| 25 | 805299A1 | --FLAME ARRESTOR | SS |
|
$0.00 | $0.00 | 1 | ||
| 26 | 805314 | --RETAINER, Breather Hose | ACT |
|
$6.40 | $6.25 | 1 | ||
| 27 | 12-86400 | WASHER | ACT | $1.60 | $1.57 | 1 | |||
| 28 | 11-826709109 | NUT, (.250-28) | 35045 | SS/ACT |
|
$3.50 | $3.42 | 1 | |
| - | 27-850470A96 | GASKET SET, Overhaul | ACT |
|
$1,006.93 | $923.08 | 1 | ||
| - | 27-850465A96 | GASKET SET, Overhaul | SS |
|
$0.00 | $0.00 | 1 |
