| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 807078T10 | MANIFOLD ASSEMBLY, Exhaust | 89011A8 | SS |
|
$565.99 | $565.99 | 2 | |
| 2 | 416223 | --PLUG, (3/4-14), Pipe | 33198A1 | SS |
|
$3.49 | $3.40 | AR | |
| 3 | 46820 | GASKET | ACT | $24.29 | $23.82 | 2 | |||
| 4 | 37612 | SCREW, (.375-16 x 1.250) | ACT | $2.49 | $2.43 | 16 | |||
| 5 | 863724 | GASKET | 860233 | SS |
|
$18.29 | $17.85 | 2 | |
| 6 | 816900A5 | ELBOW ASSEMBLY, Exhaust | NLA |
|
$0.00 | $0.00 | 1 | ||
| 6 | 816900A9 | ELBOW ASSEMBLY, Exhaust | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 865982005 | SCREW, (.375-16 x 1.00) | 12244 | SS |
|
$2.59 | $2.53 | 6 | |
| 7 | 98534 | SCREW, (.375-16 x 2.30) | NLA |
|
$0.00 | $0.00 | 2 | ||
| 8 | 862210A01 | ELBOW KIT, Drain | 806926A1 | SS |
|
$29.09 | $28.56 | 2 | |
| 9 | 8M0119211 | --PLUG KIT, (.500-13) Royal Blue, Drain | 806608A1 | SS |
|
$10.19 | $9.95 | 2 | |
| 10 | 32509 | ----QUAD RING | 806609 | SS |
|
$2.39 | $2.33 | 2 | |
| 11 | 805727001 | CAP, Rubber | 805727 | SS |
|
$4.79 | $4.69 | 2 | |
| 12 | 815504220 | CLAMP, Worm Gear | ACT | $7.59 | $7.42 | 2 | |||
| 13 | 93320A14 | RISER KIT, Exhaust (3.00 Inch) | 93320A7 | SS |
|
$404.49 | $374.07 | 1 | |
| 13 | 807477A5 | RISER KIT, Exhaust (6.00 Inch) | 93322A5 | SS |
|
$805.99 | $733.90 | 1 | |
| 14 | 416223 | --PLUG, (3/4-14), Pipe | 33198A1 | SS |
|
$3.49 | $3.40 | 2/4 | |
| 15 | 328022 | --PLUG, Pipe (.125-27) | 328021 | SS |
|
$7.59 | $7.42 | 2/4 | |
| 16 | 863726 | --GASKET | 818832 | SS |
|
$21.59 | $21.20 | 2 | |
| 17 | 97520 | --STUD, (.375 x 5.0) | ACT |
|
$18.69 | $18.33 | 6 | ||
| 17 | 34713 | --STUD, (.375 x 6.5) | ACT |
|
$28.99 | $28.40 | 2 | ||
| 17 | 821738 | --STUD, (3/8 x 8 In.) | NLA |
|
$0.00 | $0.00 | 6 | ||
| 17 | 8M0214991 | --STUD, (.375 x 9.56) | 11375 | SS |
|
$19.89 | $19.41 | 2 | |
| 18 | 46132 | --WASHER | ACT | $3.19 | $3.11 | 10 | |||
| 19 | 46335 | --NUT, (.375-24) | ACT | $2.97 | $2.92 | 8 | |||
| - | 850465A96 | GASKET SET, Overhaul | NLA |
|
$0.00 | $0.00 | 1 |
