| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 807951T | BRACKET-FUEL COOLER | ACT | $179.99 | $162.20 | 1 | |||
| 2 | 807685T | INSULATOR-BASE | ACT | $250.99 | $226.21 | 1 | |||
| 3 | 861156A1 | FUEL PUMP | 807949A1 | SS |
|
$0.00 | $0.00 | 1 | |
| 4 | 807783A1 | FITTING ASSEMBLY (90 DEG.) | ACT |
|
$42.99 | $42.14 | 1 | ||
| 5 | 8M0204683 | --O-RING | 805063 | SS |
|
$2.79 | $2.72 | 4 | |
| 6 | 808001A1 | FITTING ASSEMBLY | ACT |
|
$34.99 | $34.24 | 1 | ||
| 7 | 805062 | --O-RING | ACT | $4.19 | $4.10 | 1 | |||
| 8 | 8M0125843 | COOLER-FUEL | 807950A1 | SS |
|
$439.99 | $406.94 | 1 | |
| 9 | 8M0119211 | --PLUG-DRAIN | 806608A1 | SS |
|
$10.19 | $9.95 | 1 | |
| 10 | 32509 | ----QUAD RING | 806609 | SS |
|
$2.39 | $2.33 | 1 | |
| 11 | 807979T | PLATE | ACT | $114.49 | $103.00 | 1 | |||
| 12 | 29598 | NUT (1/4-28) | ACT | $2.89 | $2.82 | 2 | |||
| 13 | 807952A1 | REGULATOR-FUEL PRESSURE | ACT |
|
$205.99 | $185.56 | 1 | ||
| 14 | 805406 | --FILTER-FUEL PRESSURE REGULATOR | ACT | $6.89 | $6.73 | 1 | |||
| 15 | 852368 | SCREW (#10-24 X 3/4 IN.) | ACT | $1.70 | $1.66 | 2 | |||
| 16 | 89302 | WASHER | ACT | $1.80 | $1.76 | 2 | |||
| 17 | 808002A1 | FITTING ASSEMBLY | ACT |
|
$41.99 | $41.07 | 1 | ||
| 18 | 36533 | --WASHER | ACT | $1.50 | $1.47 | 1 | |||
| 19 | 8M0063567 | HOSE | 80617370 | SS |
|
$37.99 | $37.20 | 1 | |
| 20 | 860273 | CONNECTOR-HOSE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 808005 | SCREW (1/4-20 X 1/2 IN.) | ACT | $3.59 | $3.50 | 4 | |||
| 22 | 269011 | BUMPER-RUBBER | ACT | $3.99 | $3.91 | 8 | |||
| 23 | 807930T01 | INSULATOR-COVER | 807930T | SS |
|
$31.79 | $31.18 | 1 | |
| 24 | 8M0125849 | FUEL LINE-FUEL COOLER TO TBI | 860263T | SS |
|
$915.99 | $834.21 | 1 | |
| 25 | 805970 | --O-RING | ACT | $3.59 | $3.50 | 1 | |||
| 26 | 860069 | NUT (3/8-16) | ACT | $6.59 | $6.44 | 2 | |||
| 27 | 8M0063567 | HOSE | 80617377 | SS |
|
$37.99 | $37.20 | 1 | |
| - | 806988A96 | GASKET SET | NLA |
|
$0.00 | $0.00 | 1 |
