| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 863422T1 | BRACKET, Fuel Cooler | ACT |
|
$44.99 | $44.04 | 1 | ||
| 1 | 863936T | BRACKET, Fuel Cooler | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 807685T | INSULATOR, Base | ACT | $250.99 | $226.21 | 1 | |||
| 3 | 861156A1 | PUMP ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 4 | 807783A1 | FITTING ASSEMBLY, 90 Degree | ACT |
|
$42.99 | $42.14 | 1 | ||
| 5 | 8M0204683 | --O-RING, (.301 x .070) | 805063 | SS |
|
$2.79 | $2.72 | 4 | |
| 6 | 808001A1 | FITTING ASSEMBLY | ACT |
|
$34.99 | $34.24 | 1 | ||
| 7 | 805062 | --O-RING, (.530 x .082) | ACT | $4.19 | $4.10 | 1 | |||
| 8 | 8M0125853 | COOLER, Fuel | 863413T | SS |
|
$362.49 | $335.52 | 1 | |
| 9 | 866114 | --SCREW, (.250-28) Special | 861303 | SS |
|
$6.89 | $6.73 | 1 | |
| 10 | 861414 | --RING, Retaining | ACT | $1.10 | $1.08 | 1 | |||
| 11 | 807979T | BRACKET | ACT | $114.49 | $103.00 | 1 | |||
| 12 | 29598 | NUT, (.250-28) Stainless Steel | ACT | $2.89 | $2.82 | 2 | |||
| 13 | 861126A1 | REGULATOR KIT, (43 PSI) | ACT |
|
$202.49 | $182.18 | 1 | ||
| 14 | 805406 | --FILTER | ACT | $6.89 | $6.73 | 1 | |||
| 15 | 805531 | --O-RING, (.476 x .075) | ACT | $5.59 | $5.47 | 1 | |||
| 16 | 89302 | WASHER, (.203 x .406 x .040) | ACT | $1.80 | $1.76 | 2 | |||
| 17 | 808002A1 | FITTING KIT | ACT |
|
$41.99 | $41.07 | 1 | ||
| 18 | 36533 | --WASHER, (.328 x .562 x .0312) Copper | ACT | $1.50 | $1.47 | 1 | |||
| 19 | 8M0063567 | HOSE, (52.00 Inches Bulk) | 80617379 | SS |
|
$37.99 | $37.20 | 1 | |
| 20 | 860273 | CONNECTOR, Hose | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 808005 | SCREW, (.250-20 x .500) | ACT | $3.59 | $3.50 | 4 | |||
| 22 | 269011 | BUMPER, Rubber | ACT | $3.99 | $3.91 | 8 | |||
| 23 | 807930T01 | INSULATOR, Cover | 807930 | SS |
|
$31.79 | $31.18 | 1 | |
| 24 | 8M0122042 | LINE, Fuel, Fuel Cooler To Fuel Rail | 863438 | SS |
|
$128.49 | $115.62 | 1 | |
| 25 | 8M0214975 | --SEAL, Quad Ring | 863151 | SS |
|
$2.69 | $2.62 | 1 | |
| 26 | 860069 | NUT, (.375-16) | ACT | $6.59 | $6.44 | 2 | |||
| 27 | 8M0214996 | HOSE, (54.00 Inches Bulk), Fuel Pressure Regulator To Intake Manifold | 1940971 | SS |
|
$30.79 | $30.20 | 1 | |
| 28 | 8M0045997 | HOSE ASSEMBLY, Fuel Pressure Regulator To Fuel Filter | 807954T | SS |
|
$238.99 | $215.24 | 1 | |
| 29 | 8M0046000 | LINE, Fuel, Fuel Filter To Fuel Pump | 864152 | SS |
|
$173.49 | $156.19 | 1 | |
| 29 | 8M0168646 | LINE, Fuel, Fuel Filter To Fuel Pump | 864267 | NLA |
|
$252.99 | $227.78 | 1 | |
| 30 | 852368 | SCREW, (#10-24 x .750) | ACT | $1.70 | $1.66 | 2 | |||
| - | 861246A05 | GASKET SET, Engine Overhaul | 861246A98 | SS |
|
$826.99 | $752.89 | 1 |
