| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 8M0113734 | PUMP ASSEMBLY, Water | 850399 | SS |
|
$180.99 | $170.37 | 1 | |
| 2 | 34897 | --GASKET | ACT | $13.89 | $13.56 | 2 | |||
| 3 | 32132 | SCREW, (.375-16 x 1.750) | ACT | $2.99 | $2.92 | 1 | |||
| 3 | 47688 | SCREW, (.375-16 x 2.750) | ACT | $3.59 | $3.50 | 1 | |||
| 3 | 8M0076418 | STUD, (.312-24/.375-16 x 2.5625) | 35342 | SS |
|
$9.69 | $9.46 | 2 | |
| 4 | 8M0153706 | PULLEY | 807729T | SS |
|
$63.49 | $60.84 | 1 | |
| 5 | 47277 | SCREW, (.312-24 x .750) | ACT | $1.20 | $1.18 | 4 | |||
| 6 | 852946001 | BALANCER, Harmonic | 852946 | SS |
|
$0.00 | $0.00 | 1 | |
| 7 | 807730T | PULLEY | ACT | $110.49 | $103.91 | 1 | |||
| 8 | 8M0150824 | BELT, Serpentine | 8077552 | SS |
|
$155.49 | $146.28 | 1 | |
| 8 | 8M0175082 | BELT, Serpentine | 8077551 | SS |
|
$197.99 | $186.38 | 1 | |
| 8 | 8M0150823 | BELT, Serpentine | 8077553 | SS |
|
$143.99 | $135.53 | 1 | |
| 9 | 8M2021674 | SCREW, (.437-20 x 2.50) | 32515 | SS |
|
$3.19 | $3.11 | 1 | |
| 10 | 39131 | LOCKWASHER, (.437) | ACT | $1.00 | $0.98 | 1 | |||
| 11 | 35332001 | WASHER | 35332 | SS |
|
$11.29 | $11.02 | 1 | |
| 12 | 34352 | SCREW, (.375-24 x .875) | ACT | $1.20 | $1.18 | 3 | |||
| 13 | 835005 | COVER ASSEMBLY, Timing | ACT |
|
$182.99 | $171.94 | 1 | ||
| 14 | 852940 | HOUSING ASSEMBLY, With Studs, Oil Seal (REAR) | ACT | $231.99 | $218.24 | 1 | |||
| 15 | 881715 | GASKET | 14241 | SS |
|
$19.89 | $19.41 | 1 | |
| 16 | 852941 | SEAL, Oil (REAR) | ACT | $149.49 | $140.55 | 1 | |||
| 17 | 8M0064241 | BOLT, (.250-20 x 1.750) | 14243 | SS |
|
$9.09 | $8.88 | 1 | |
| 18 | 14242 | BOLT, (.250-20 x .875) | ACT | $23.59 | $23.16 | 2 | |||
| 19 | 14263 | PIN, Dowel | ACT | $6.79 | $6.64 | 1 | |||
| 20 | 8M0098315 | NUT, (.250-20) | 816730 | SS |
|
$4.19 | $4.10 | 1 | |
| 21 | 14827 | STUD, (.250-20 x 2.180) | ACT | $17.89 | $17.52 | 1 | |||
| - | 75611A98 | GASKET SET, Engine Overhaul | ACT | $944.99 | $888.86 | 1 |
