| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 807962A15 | BRACKET ASSEMBLY, Shift | 807962A3 | SS |
|
$166.99 | $156.88 | 1 | |
| 2 | 865149A02 | --STUD, (.250 x 2.870) | 8140021 | SS |
|
$10.69 | $10.44 | 1 | |
| 3 | 13051A4 | LEVER ASSEMBLY, Actuating | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 865433A02 | LEVER ASSEMBLY, Actuating | 13051A8 | SS |
|
$39.99 | $39.26 | 1 | |
| 4 | 862850 | --SPRING | 45599 | SS |
|
$19.69 | $19.21 | 1 | |
| 5 | 8M0207774 | --SCREW, (.312-18 x 1.843) | 13743 | SS |
|
$10.69 | $10.44 | 1 | |
| 6 | 8M0214922 | COTTER PIN | 32857 | SS |
|
$3.79 | $3.69 | 1 | |
| 7 | 8M0207784 | SPRING | 98880 | SS |
|
$8.29 | $8.10 | 1 | |
| 8 | 56720 | WASHER, (.330 x .750 x .060) Stainless Steel | ACT | $1.80 | $1.76 | 1 | |||
| 9 | 35462 | WASHER, (.2656 x .625 x .0625) Stainless Steel | ACT | $1.80 | $1.76 | 3 | |||
| 10 | 8267119 | NUT, (.250-28) | 13438 | SS |
|
$2.59 | $2.53 | 2 | |
| 11 | 8M0113178 | STUD, (.250-28 x 2.00), Throttle Cable Anchor | 96112 | SS |
|
$3.09 | $3.01 | 1 | |
| 12 | 63341 | TEE NUT | ACT | $2.79 | $2.72 | 1 | |||
| 13 | 13898T06 | LEVER ASSEMBLY, Shift | 13898A3 | SS |
|
$58.99 | $56.51 | 1 | |
| 14 | 8M0207774 | --SCREW, (.312-18 x 1.843) | 13743 | SS |
|
$10.69 | $10.44 | 1 | |
| 15 | 814001 | --PIN, Clevis | ACT | $13.89 | $13.56 | 1 | |||
| 16 | 210711 | --COTTER PIN | 21071 | SS |
|
$3.69 | $3.59 | 1 | |
| 17 | 19752A6 | SWITCH ASSEMBLY, Cut Out | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 30902 | SCREW, (#6-32 x .750) | NLA |
|
$1.21 | $1.18 | 1 | ||
| 19 | 814281A5 | SWITCH ASSEMBLY | ACT |
|
$80.99 | $77.83 | 1 | ||
| 20 | 860077 | SCREW, (#6-32 x 1.00) | ACT |
|
$1.70 | $1.66 | 2 | ||
| 21 | 11303 | WASHER | ACT |
|
$4.09 | $4.00 | 2 | ||
| 22 | 8M0207777 | NUT, (#6-32) | F1669 | SS |
|
$6.59 | $6.44 | 2 | |
| 23 | 813995A1 | GUIDE ASSEMBLY, Spring | ACT | $46.99 | $45.99 | 1 | |||
| 24 | 657461 | SCREW AND LOCKWASHER, (.250-20 x .625) | ACT |
|
$1.70 | $1.66 | 3 | ||
| 25 | 657461 | STUD, (.250-28 x 1.00) | 66357 | SS |
|
$1.70 | $1.66 | 2 | |
| 26 | 69057 | WASHER, (.281 x .734 x .063) | ACT |
|
$1.80 | $1.76 | 2 | ||
| 27 | 826709109 | NUT, (.250-28) | 35045 | SS |
|
$3.59 | $3.50 | 2 |
